ADLINK Technology SMARC LEC-MTK-I1200 User Manual page 54

LEC-MTK-i1200 User's Guide
SMARC
Signal Name
S108 LVDS1_CK+ / eDP1_AUX+ /
DSI1_CLK+
S109 LVDS1_CK- / eDP1_AUX- /
DSI1_CLK-
S110
GND
S111 LVDS1_0+ / eDP1_TX0+ /
DSI1_D0+
S112 LVDS1_0- / eDP1_TX0- /
DSI1_D0-
S113
eDP1_HPD / DSI1_TE
S114 LVDS1_1+ / eDP1_TX1+ /
DSI1_D1+
S115 LVDS1_1- / eDP1_TX1- /
DSI1_D1-
S116
LCD1_VDD_EN
S117 LVDS1_2+ / eDP1_TX2+ /
DSI1_D2+
S118 LVDS1_2- / eDP1_TX2- /
DSI1_D2-
S119
GND
S120 LVDS1_3+ / eDP1_TX3+ /
DSI1_D3+
S121 LVDS1_3- / eDP1_TX3- /
DSI1_D3-
S122
LCD1_BKLT_PWM
S123
GPIO13
S124
GND
S125 LVDS0_0+ / eDP0_TX0+ /
DSI0_D0+
S126 LVDS0_0- / eDP0_TX0- /
DSI0_D0-
S127
LCD0_BKLT_EN
S128 LVDS0_1+ / eDP0_TX1+ /
DSI0_D1+
Page 54
Module Termination Type/Tolerance
- DSI
- DSI
- -
- DSI
- DSI
- DSI
- DSI
- DSI
- GPIO / 1.8V
- DSI
- DSI
- -
- DSI
- DSI
- PWM / 1.8V
PU-470K GPIO / 1.8V
- -
- eDP/DSI
- eDP/DSI
- GPIO / 1.8V
- eDP/DSI
copyright © 2023 ADLINK Technology Inc.
Controller Controller Pin Name
MT8395 DSI1_CKP_T1B
MT8395 DSI1_CKN_T1C
- -
MT8395 DSI1_D0P_T0C
MT8395 DSI1_D0N_T1A
MT8395 DSI1_TE
MT8395 DSI1_D1P_T2A
MT8395 DSI1_D1N_T2B
MT8395 GPIO
MT8395 DSI1_D2P_T0A
MT8395 DSI1_D2N_T0B
- -
MT8395 DSI1_D3P_T2C
MT8395 DSI1_D3N
MT8395 DISP_PWM1
SX1509BIULTRT I/O15
- -
TMUXHS4212IRKSR A1P
TMUXHS4212IRKSR A1N
MT8395 GPIO
TMUXHS4212IRKSR A0P
SGET SMARC Rev 2.1
I/O Mux default
ALT2
ALT0
ALT2
ALT0
