ADLINK Technology SMARC LEC-MTK-I1200 User Manual page 19

LEC-MTK-i1200 User's Guide
P-Pin Primary (Top) Side
P1 SMB_ALERT_1V8#
P2 GND
P3 CSI1_CK+
P4 CSI1_CK-
P5 GBE1_SDP
P6 GBE0_SDP
P7 CSI1_RX0+
P8 CSI1_RX0-
P9 GND
P10 CSI1_RX1+
P11 CSI1_RX1-
P12 GND
P13 CSI1_RX2+
P14 CSI1_RX2-
P15 GND
P16 CSI1_RX3+
P17 CSI1_RX3-
P18 GND
P19 GBE0_MDI3-
P20 GBE0_MDI3+
P21 GBE0_LINK100#
P22 GBE0_LINK1000#
P23 GBE0_MDI2-
P24 GBE0_MDI2+
P25 GBE0_LINK_ACT#
P26 GBE0_MDI1-
P27 GBE0_MDI1+
P28 GBE0_CTREF
P29 GBE0_MDI0-
P30 GBE0_MDI0+
P31 SPI0_CS1#
P32 GND
P33 SDIO_WP
P34 SDIO_CMD
P35 SDIO_CD#
Page 19
S-Pin Secondary (Bottom) Side
S1 CSI1_TX+ / I2C_CAM1_CK
S2 CSI1_TX- / I2C_CAM1_DAT
S3 GND
S4 RSVD
S5 CSI0_TX- / I2C_CAM0_CK
S6 CAM_MCK
S7 CSI0_TX+ / I2C_CAM0_DAT
S8 CSI0_CK+
S9 CSI0_CK-
S10 GND
S11 CSI0_RX0+
S12 CSI0_RX0-
S13 GND
S14 CSI0_RX1+
S15 CSI0_RX1-
S16 GND
S17 GBE1_MDI0+
S18 GBE1_MDI0-
S19 GBE1_LINK100#
S20 GBE1_MDI1+
S21 GBE1_MDI1-
S22 GBE1_LINK1000#
S23 GBE1_MDI2+
S24 GBE1_MDI2-
S25 GND
S26 GBE1_MDI3+
S27 GBE1_MDI3-
S28 GBE1_CTREF
S29 PCIE_D_TX+ /
S30 PCIE_D_TX- / SERDES_1_TX-
S31 GBE1_LINK_ACT#
S32 PCIE_D_RX+ /
S33 PCIE_D_RX- /
S34 GND
S35 USB4+
copyright © 2023 ADLINK Technology Inc.
P-Pin Primary (Top) Side
P36 SDIO_CK
P37 SDIO_PWR_EN
P38 GND
P39 SDIO_D0
P40 SDIO_D1
P41 SDIO_D2
P42 SDIO_D3
P43 SPI0_CS0#
P44 SPI0_CK
P45 SPI0_DIN
P46 SPI0_DO
P47 GND
P48 SATA_TX+
P49 SATA_TX-
P50 GND
P51 SATA_RX+
P52 SATA_RX-
P53 GND
P54 ESPI_CS0# / SPI1_CS0#
P55 ESPI_CS1# / SPI1_CS1#
P56 ESPI_CK / SPI1_CK
P57 ESPI_IO_1 / SPI1_DIN
P58 ESPI_IO_0 / SPI1_DO
P59 GND
P60 USB0+
P61 USB0-
P62 USB0_EN_OC#
P63 USB0_VBUS_DET
P64 USB0_OTG_ID
P65 USB1+
P66 USB1-
P67 USB1_EN_OC#
P68 GND
P69 USB2+
P70 USB2-
SGET SMARC Rev 2.1
S-Pin Secondary (Bottom) Side
S36 USB4-
S37 USB3_VBUS_DET
S38 AUDIO_MCK
S39 I2S0_LRCK
S40 I2S0_SDOUT
S41 I2S0_SDIN
S42 I2S0_CK
S43 ESPI_ALERT0#
S44 ESPI_ALERT1#
S45 MDIO_CLK
S46 MDIO_DAT
S47 GND
S48 I2C_GP_CK
S49 I2C_GP_DAT
S50 HDA_SYNC / I2S2_LRCK
S51 HDA_SDO / I2S2_SDOUT
S52 HDA_SDI / I2S2_SDIN
S53 HDA_CK / I2S2_CK
S54 SATA_ACT#
S55 USB5_EN_OC#
S56 ESPI_IO_2
S57 ESPI_IO_3
S58 ESPI_RESET#
S59 USB5+
S60 USB5-
S61 GND
S62 USB3_SSTX+
S63 USB3_SSTX-
S64 GND
S65 USB3_SSRX+
S66 USB3_SSRX-
S67 GND
S68 USB3+
S69 USB3-
S70 GND
