4.4 Secondary Display Interface

4.4.1.1 HDMI mode
Name Pin # Description
HDMI_D2+ P92 HDMI port, differential pair data lines
HDMI_D2- P93
HDMI_D1+ P95
HDMI_D1- P96
HDMI_D0+ P98
HDMI_D0- P99
HDMI_CK+ P101 HDMI port, differential pair clock lines
HDMI_CK- P102
HDMI_CTRL_CK P105 I2C_CLK line dedicated to HDMI
HDMI_CTRL_DAT P106 I2C_DAT line dedicated to HDMI
Page 27
I/O I/O Power
Type Level Domain
O TMDS Runtime
HDMI
O TMDS Runtime
HDMI
O OD 1.8V Runtime
COMS
I/O OD 1.8V Runtime
CMOS
copyright © 2023 ADLINK Technology Inc.
PU / Comments
PD
AC coupled off module
AC coupled off module
PU Level shifter FET and 5V PU resistor shall be placed
100K between the Module and the HDMI connector.
Stronger pull-up is demanded to the carrier board.
The pull-ups may be part of an integrated HDMI ESD
protection and control-line level shift device, such as the
Texas Instruments TPD12S016.
If discrete Carrier pull-ups are used, the value depends on
the individual carrier board implementation.
PU Level shifter FET and 5V PU resistor shall be placed
100K between the Module and the HDMI connector.
Stronger pull-up is demanded to the carrier board.
The pull-ups may be part of an integrated HDMI ESD
protection and control-line level shift device, such as the
Texas Instruments TPD12S016.
If discrete Carrier pull-ups are used, the value depends on
the individual carrier board implementation.
SGET SMARC Rev 2.1
