3.41 I2C GP (CN70)

Table 3-48 lists the pin signals of the I2C GP header, which provides 3 pins in a single row with
2.00mm pitch.
Pin #
1
I2C_GP_CK_3V
2
I2C_GP_DAT_3V
3
Ground
NOTE: Shaded table cell denotes ground.

3.42 I2C LCD (CN71)

Table 3-49 lists the pin signals of the I2C LCD header, which provides 3 pins in a single row with
2.00mm pitch.
Pin #
1
I2C_LCD_CK_3V
2
I2C_LCD_DAT_3V
3
Ground
NOTE: Shaded table cell denotes ground.

3.43 I2C PM (CN72)

Table 3-50 lists the pin signals of the I2C PM header, which provides 3 pins in a single row with
2.00mm pitch.
Pin #
1
I2C_PM_CK_3V
2
I2C_PM_DAT_3V
3
Ground
NOTE: Shaded table cell denotes ground.

3.44 Camera, PCAM / CSI (CN80)

Table 3-51 lists the pin signals of the Camera, PCAM / CSI board-to-board connector, which pro-
vides 64-pins, 2 rows, odd/even pin sequence (1, 2) with 0.50mm pitch. These signals are con-
nected directly to the MIPI CSI camera interface at the SMARC connector.
Pin#
1
GND
3
PCAMD9_CSI1D3N_R
PCAMD8_CSI1D3P_R
5
7
GND
9
PCAMD7_CSI1D2N_R
PCAMD6_CSI1D2P_R
11
13
GND
Interfaces
Table 3-48: I2C GP (CN70)
Table 3-49: I2C LCD (CN71)
Table 3-50: I2C PM (CN72)
Table 3-51: Camera, PCAM / CSI Signals (CN80)
Signal
2
4
6
8
10
12
14
Signal
Signal
Signal
Pin#
GND
CAM1_2V8
CAM1_2V8
CAM0_2V8
CAM0_2V8
GND
PCAM_MCK_R
LEC-BASE MINI
