Lenovo Flex System x440 Compute Node
Installation and Service Guide
Machine Types: 7167, 2590

Advertisement

Table of Contents
loading

Related Manuals for Lenovo Flex System x440 Compute Node

Summary of Contents for Lenovo Flex System x440 Compute Node

  • Page 1 Lenovo Flex System x440 Compute Node Installation and Service Guide Machine Types: 7167, 2590...
  • Page 2 Appendix B “Notices” on page 949, the Warranty Information document, and the Safety Information and the Environmental Notices and User Guide documents on the Lenovo Documentation CD. Fourth Edition (December 2018) © Copyright Lenovo 2014, 2018. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant a General Services Administration “GSA”...

  • Page 3: Table Of Contents

    Brocade documentation ... . 3 Accessing the IMM2 remotely ..The Lenovo Documentation CD ..3 Viewing the network access tag..
  • Page 4 Index ....957 Removing the hard disk drive cage ..925 Installing the hard disk drive cage ..925 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 5: Safety

    Avant d'installer ce produit, lisez les consignes de sécurité. Vor der Installation dieses Produkts die Sicherheitshinweise lesen. Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza. Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet. © Copyright Lenovo 2014, 2018...

  • Page 6: Guidelines For Trained Service Technicians

    • Make sure that the third-wire ground connector is in good condition. Use a meter to measure third- wire ground continuity for 0.1 ohm or less between the external ground pin and the frame ground. • Make sure that the power cords are the correct type. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 7: Guidelines For Servicing Electrical Equipment

    • Use extreme care when you measure high voltages. • To ensure proper grounding of components such as power supplies, pumps, blowers, fans, and motor generators, do not service these components outside of their normal operating locations. © Copyright Lenovo 2014, 2018...

  • Page 8: Safety Statements

    2. First, remove power cords from outlet. 3. Attach signal cables to connectors. 3. Remove signal cables from connectors. 4. Attach power cords to outlet. 4. Remove all cables from devices. 5. Turn device ON. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 9 CAUTION: Hazardous energy is present when the blade is connected to the power source. Always replace the blade cover before installing the blade. UL regulatory information This device is for use only with Listed chassis. © Copyright Lenovo 2014, 2018...
  • Page 10 Lenovo Flex System x440 Compute NodeInstallation and Service Guide viii...

  • Page 11: Chapter 1. Introduction

    Chapter 1. Introduction The Lenovo Flex System x440 Compute Node Types 7167 and 2590 is a high-availability, scalable compute node that is optimized to support the next-generation microprocessor technology and is ideally suited for medium and large businesses. The x440 Compute Node Types 7167 and 2590 is supported in the Flex System Enterprise Chassis only.

  • Page 12: Related Documentation

    Safety Information document. • Lenovo Warranty Information This printed document contains the warranty terms and a pointer to the Lenovo Statement of Limited Warranty. • Environmental Notices and User Guide This document is in PDF.

  • Page 13: Brocade Documentation

    You can run the documentation CD on any computer that meets the hardware and software requirements. Hardware and software requirements Use this information to determine the minimum hardware and software requirements. The Lenovo Documentation CD requires the following minimum hardware and software: • MicrosoftWindows • 100 MHz microprocessor •...

  • Page 14: Notices And Statements In This Document

    • Danger: These statements indicate situations that can be potentially lethal or hazardous to you. A danger statement is placed just before the description of a potentially lethal or hazardous procedure step or situation. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 15: Features And Specifications

    Features and specifications Use this information to view specific information about the compute node, such as compute node hardware features and the dimensions of the compute node. Notes: 1. Power, cooling, and chassis systems management are provided by the Flex System chassis. 2.
  • Page 16 For information about the limits for particulates and gases, see “Particulate contamination” on page 951. 1. Compute Node powered on. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 17: What Your Compute Node Offers

    For information about Features on Demand, see https://fod.lenovo.com/lkms • Dynamic System Analysis (DSA) Dynamic System Analysis (DSA) collects and analyzes system information to aid in diagnosing compute node problems.
  • Page 18 DSA log as a file to a support representative or view the information as a text file or HTML file. For more information, see “Lenovo Dynamic System Analysis Preboot diagnostic program ” on page • Flexible network support The compute node provides flexible network capabilities: –...
  • Page 19 – The Lenovo XClarity Administrator is a virtual appliance that you can use to manage Flex System chassis in a secure environment. The Lenovo XClarity Administrator provides a central interface to perform the following functions for all managed endpoints: –...
  • Page 20 Fsetup.html – Free 90-day trial Lenovo XClarity Administrator offers a free, 90-day trial license that enables you to use all available features (including operating-system deployment, firmware maintenance, and configuration management) for a limited time. After 90 days, you can continue to use Lenovo XClarity Administrator to manage and monitor your hardware for free;...

  • Page 21: Lenovo Xclarity Administrator

    Lenovo XClarity Administrator provides a centralized view of all events and alerts that are generated from the managed endpoints. When a CMM or IMM detects an issue, an alert or event is passed to the Lenovo XClarity Administrator and is displayed in the events or alerts log. A summary of all alerts and events is visible from the Dashboard and the Status bar.

  • Page 22: Reliability, Availability, And Serviceability Features

    Lenovo XClarity Administrator and the managed endpoints. You can choose to send diagnostic files to Lenovo Support using call home or to another service provider using SFTP. You can also manually collect diagnostic files, open a problem record, and send diagnostic files to the Lenovo Support Center.

  • Page 23: Major Components Of The Compute Node

    • Microprocessor serial number access • PCI bus even parity checking • POST • Power policy • Processor presence detection • Rank-sparing mode support • ROM-resident diagnostics • System-error logging • Vital product data (VPD) on memory • Wake on LAN capability •...

  • Page 24: Compute Node Controls, Connectors, And Leds

    “IMM event log” on page 65 The check log LED can be turned off through the CMM led command, the CMM web interface, the Lenovo XClarity Administrator (if available), or the Flex System Manager management software (if available). • For more information about the CMM led command, see the "Flex System Chassis Management...
  • Page 25 When this LED is lit, the identify LED on the Flex System chassis is also lit. The identify LED can be lit and turned off through the CMM led command, the CMM web interface, the Lenovo XClarity Administrator (if available), or the Flex System Manager management software (if available).

  • Page 26: Console Breakout Cable

    • You can press the power button on the front of the compute node (see “Compute node controls, connectors, and LEDs” on page 14) to start the compute node. The power button works only if local Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 27: Turning Off The Compute Node

    CMM web interface online help. • You can turn on the compute node through the CMM power command, the CMM web interface, the Lenovo XClarity Administrator (if available), or the Flex System Manager management software (if available).

  • Page 28: System-Board Layouts

    Data loss is possible. • You can turn off the compute node through the CMM power command, the CMM web interface, the Lenovo XClarity Administrator (if available), or the Flex System Manager management software (if available). – For more information about the CMM power command, see the "Flex System Chassis Management...

  • Page 29: System-Board Jumpers

    System-board jumpers Use this information to locate the system-board jumpers. The following illustration shows the locations of the jumpers on the system board. Chapter 1 Introduction...

  • Page 30: System-Board Leds

    Two-pin jumper. The dwfault is no jumper. Place a jumper on pins 1 and 2 to physical presence (J6) indicate a physical presence to the IMM2 TPM chip. System-board LEDs The following illustration shows the location of the LEDs on the system board. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 31: System-Board Switches

    DIMM DIMM Microprocessor 3 Microprocessor 1 error error error error Storage backplane 1 error DIMM DIMM error error Storage backplane 2 error Battery error DIMM DIMM Microprocessor 4 Microprocessor 2 error error error error System-board switches Use this information to locate the system-board switches. The following illustration shows the location of the switch block on the system board.
  • Page 32 Changing this switch to the Closed position resets the RTC. A momentary toggle is all that is required. To avoid excessive CMOS battery drain, do not leave this switch in the Closed position. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 33 Switch setting Description Switch number Definition U52-4 Boot backup IMM2 The default position is Open. When the switch is in the default Open position, the compute node will boot by using the primary IMM2 firmware. When the switch is in the Closed position, the compute node will boot by using a backup of the IMM2 firmware.
  • Page 34 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 35: Chapter 2. Configuring

    • Lenovo ToolsCenter Bootable Media Creator You can use Lenovo ToolsCenter Bootable Media Creator to create bootable media that is suitable for applying firmware updates and running preboot diagnostics. Using Lenovo ToolsCenter Bootable Media Creator, you can create a single bootable image on supported media (such as CD, DVD, ISO image, USB flash drive, or set of PXE files) that bundles multiple Flex System tools and updates from UpdateXpress System Packs, which contain Windows and Linux®...

  • Page 36: Recovering A Uefi Image

    The backup page version might not be the same as the primary page version. You can then recover or restore the original primary page UEFI. Note: Changes are made periodically to the Lenovo website. The actual procedure might vary slightly from what is described in this document.

  • Page 37: Configuring The Compute Node

    Note: To configure a compute node, you configure the IP address of the IMM through the CMM Web interface. For more information, see the the "Flex System Chassis Management Module: User's Guide" at http:// pic.dhe.ibm.com/infocenter/flexsys/information/topic/com.lenovo.acc.cmm.doc/ cmm_user_ guide.html Step 1. Configure the Unified Extensible Firmware Interface (UEFI) firmware for the compute node by using the Setup utility (see “Using the Setup utility”...

  • Page 38: Using The Setup Utility

    The following menu items are on the Setup utility main menu. Depending on the version of the Unified Extensible Firmware Interface (UEFI), some menu items might differ slightly from these descriptions. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 39 • System Information Select this choice to view information about the compute node. When you make changes through other choices in the Setup utility, some of those changes are reflected in the system information; you cannot change settings directly in the system information. This choice is on the full Setup utility menu only. –...
  • Page 40 – System Security Select this option to view or change the following system security configuration. – Physical Presence Policy Configuration Select this choice to choose from the following Physical Presence Policy options. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 41 • Enable/Disable: select this option to enable/disable Physical Presence Policy. Default is Enable. • Asserted: select this option to set Physical Presence for a duration (in minutes) or turn it off. Default is De-asserted. • Input minutes for assertion: select this option to input a number from 0~100 which stands for the number of minutes Remote Physical Presence is asserted.
  • Page 42 If the compute node has Wake on LAN hardware and software and the operating system supports Wake on LAN functions, you can specify a startup sequence for the Wake on LAN Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 43 functions. For example, you can define a startup sequence that checks for a disc in the CD or DVD drive, then checks the hard disk drive, and then checks a network adapter. This choice is on the full UEFI Setup utility menu only. •...

  • Page 44: Setting The Boot Protocol To Boot From Legacy Devices Using The Setup Utility

    The Boot Selection Menu program is a built-in, menu-driven configuration utility program that you can use to temporarily redefine the first startup device without changing settings in the Setup utility. To use the Boot Selection Menu program, complete the following steps: Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 45: Updating The Universally Unique Identifier And Dmi/Smbios Data

    Step 1. Connect a keyboard, monitor, and mouse to the console breakout cable, and connect the console breakout cable to the compute node. Step 2. Turn on the compute node (see “Turning on the compute node” on page 16). Step 3. Press F12 (Select Boot Device).
  • Page 46 IMM2 account password (1 of 12 accounts). The default is PASSW0RD (with a zero, not the letter O). Step 2. Enter the following command: asu set SYSTEM_PROD_DATA.SysInfoSerialNum zzzzzzz [--host ipaddress] [--user userid][--password password] Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 47 where zzzzzzz is the 7-character serial number of the compute node. Step 3. Enter the following command: asu set SYSTEM_PROD_DATA.SysEncloseAssetTag aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa [--host ipaddress] where aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa is the 33-character asset tag number of the compute node. Step 4. Restart the IMM. Step 5.

  • Page 48: Configuring A Raid Array

    Connect a keyboard, monitor, and mouse to the console breakout cable and connect the console breakout cable to the compute node. Step 2. Turn on the compute node (see “Turning on the compute node” on page 16). Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 49: Setting Up The Lan-On-Motherboard (Lom)

    Gb physical port (8 total for the LOM). For more information about how LOM ports are mapped to switch modules in the chassis, see http:// pic.dhe.ibm.com/infocenter/ flexsys/information/topic/ com.lenovo.acc.8721.doc/ configuring_io_ modules.html • Two options for vNIC linking: – VNIC1, Virtual Fabric mode.
  • Page 50 No host operating system changes are required for you to use the LOM features. NIC and HBA functionality (including device management, utilities, and other functions) are transparent to the host operating system. For more information about using the LOM feature, go to http://www.emulex.com/support/ Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 51: Chapter 3. Installing The Operating System

    CD for deploying Windows operating systems and updates from UpdateXpress System Packs. For more information about the Lenovo Bootable Media Creator, see . To provision a compute node with an operating system by using Lenovo ToolsCenter Bootable Media Creator, complete the following steps: 1.

  • Page 52: Using The Serverguide Setup And Installation

    5. Start the compute node to boot the media and install the operating system. • Lenovo XClarity Administrator You can use the Lenovo XClarity Administrator (if available) to deploy operating systems and virtual images to multiple compute nodes that do not already have an operating system installed. This function allows you to deploy Red Hat Enterprise Linux (RHEL) including Kernel-based Virtual Machine (KVM), VMware vSphere Hypervisor (ESXi) with Lenovo Customization, and Microsoft Windows 2012.

  • Page 53: Typical Operating-System Installation

    Using Lenovo ServerGuide Scripting Toolkit The ServerGuide Scripting Toolkit is a collection of system-configuration tools and installation scripts that you can use to deploy software to your Flex System compute node in a repeatable, predictable manner.
  • Page 54 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 55: Chapter 4. Accessing The Imm2

    The network access tag is attached to the front of the compute node. The front of the network access tag lists the first four IMM MAC addresses in the lower-right corner, as shown in the following illustration. © Copyright Lenovo 2014, 2018...

  • Page 56: Logging In To The Web Interface

    "Flex System Chassis Management Module: Command-Line Interface Reference Guide" at http://pic.dhe.ibm.com/infocenter/flexsys/information/topic/com.lenovo.acc.cmm.doc/cli_ command_ ifconfig.html • To assign IP addresses from the CMM web interface, click Mgt Module Management ➙ Network ➙ Ethernet. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 57: Imm2 Action Descriptions

    Log out of the IMM web interface. Beneath the title bar are tabs that allow you to access various IMM2 functions, as listed in Table 2 “IMM2 actions” on page For more information about the IMM2 actions, see http://publib.boulder.ibm.com/infocenter/ systemx/ documentation/topic/ com.lenovo.sysx.imm2.doc/ printable_doc.html Table 2. IMM2 actions Description Selection System Status The System Status page allows you to view system status, active system events, and hardware health information.
  • Page 58 The Latest OS Failure Screen page displays a screen image, when available, Screen of the most recent operating system failure on the compute node. For your IMM to capture operating system failure screens, the operating system watchdog must be enabled. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 59 Table 2. IMM2 actions (continued) Description Selection IMM Management IMM Properties The IMM Properties page provides access to various properties, status, and settings for your IMM2: • The Firmware tab provides a link to the Server Firmware section of Server Management.

  • Page 60: Accessing The Imm2 Using The Lan Over Usb

    Use one of the following methods to resolve LAN over USB conflicts. Note: For conflicts with Open MPI, configure the application so that it does not attempt to use this interface. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 61: Configuring The Lan Over Usb Interface

    When you install a Windows operating system, there will be an unknown RNDIS device in the Device Manager. Lenovo provides a Windows INF file that identifies this device. The signed version of the INF file is included in all of the Windows versions of the IMM2, UEFI, and DSA update packages. Complete the following steps to install ibm_rndis_server_os.inf.
  • Page 62 A new local area connection appears. If the message This connection has limited or no connectivity is displayed, ignore this message. Step 10. Return to the Device Manager. IBM USB Remote NDIS Network Device or Lenovo USB Remote NDIS Network Device appears under Network Adapters.

  • Page 63: Chapter 5. Parts Listing, Types 7167 And 2590

    Tier 1 CRU at your request without a service contract, you will be charged for the installation. • Tier 2 customer replaceable unit: You may install a Tier 2 CRU yourself or request Lenovo to install it, at no additional charge, under the type of warranty service that is designated for your compute node.
  • Page 64 Filler, 2.5 inch hard disk drive bay (see "Consumable parts") 81Y9671 Hard disk drive, SAS 2.5 inch 300 GB 15K 6 Gbps slim hot-swap Hard disk drive, SAS 2.5 inch 300 GB 10K 6 Gbps SFF G2 hot-swap 90Y8878 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 65 Table 4. Parts listing, Types 7167 and 2590 (continued) CRU part CRU part number (Tier number (Tier Description Index Hard disk drive, SAS 2.5 inch 500 GB 7.2K NL 6 Gbps G2 hot-swap 90Y8954 Hard disk drive, SAS 2.5 inch 600 GB 10K 6 Gbps SFF G2 hot-swap 90Y8873 Hard disk drive, SAS 2.5 inch 600 GB, 15K, 6 Gbps G2HS hot-swap 00AJ301...
  • Page 66 44E4767 44E4765 ServeRAID-M5100 Series 2 x 1.8 inch SAS backplane Flex System Flash Kit V2 backplane card assembly 47C8844 Flex System Flash Kit V2 flex cable 00FE024 Thermal grease kit 41Y9292 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 67 Consumable parts Consumable parts are not covered by the Statement of Limited Warranty. The following consumable parts are available for purchase from the retail store. Table 5. Consumable parts Description Consumable part number Index Top cover (when ordering this part, order the Label kit (part number (00D6313) 46M2830 Air baffle above DIMMs 81Y5177...
  • Page 68 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 69: Chapter 6. Troubleshooting

    UEFI image. • If the fault LED is lit, it indicates that an error has occurred; view the light path diagnostics panel and LEDs to isolate the failing component. © Copyright Lenovo 2014, 2018...
  • Page 70 2. To view the light path diagnostics LEDs, select one of the following procedures: • You can view the LEDs through the CMM led command, the CMM web interface, the Lenovo XClarity Administrator (if available), or the Flex System Manager management software (if available).
  • Page 71 DIMM DIMM Microprocessor 3 Microprocessor 1 error error error error Storage backplane 1 error DIMM DIMM error error Storage backplane 2 error Battery error DIMM DIMM Microprocessor 4 Microprocessor 2 error error error error Light path diagnostics LEDs Use this information to diagnose possible errors that are indicated by the light path diagnostics LEDs. The following table describes the LEDs on the light path diagnostics panel and the light path diagnostics LEDs on the system board.
  • Page 72 LED. Microprocessor mismatch The microprocessors do not match. Make sure that all installed microprocessors are identical (number of cores, cache size, type, clock speed, and internal / external clock frequencies). Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 73 Table 6. Light path LED errors (continued) Light path diagnostics LED Description Action The system board failed. 1. Reinsert the compute node, and then restart the compute node. Check the IMM event log for information about the error. 2. (Trained service technician only) Replace the base assembly.
  • Page 74 DSAS_LF20 Yellow SAS 2-0 link failure The IMM2 lights this LED when there is a fault with the link between the SAS controller and SAS port 0 on SAS backplane 2. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 75: Imm Event Log

    Methods are available for you to view one or more event logs without having to restart the compute node. You can view the Chassis Management Module event log using the Lenovo XClarity Administrator, in the Flex System Manager Chassis Manager, or through the Event Log link in Flex System Manager management software.
  • Page 76 2. Click Linux. 3. Click the Linux blueprints tab. 4. Click Blueprints for Linux on IBM systems or Blueprints for Linux on Lenovo systems, and then click Using Intelligent Platform Management Interface (IPMI) on IBM Linux platforms or Using Intelligent Platform Management Interface (IPMI) on Lenovo Linux platforms.

  • Page 77: Lenovo Dynamic System Analysis Preboot Diagnostic Program

    “Viewing event logs through the Setup utility” on page Lenovo Dynamic System Analysis Preboot diagnostic program Lenovo Dynamic System Analysis (DSA) Preboot diagnostic program collects and analyzes system information to aid in diagnosing compute node problems. DSA Preboot performs the following tasks: •...

  • Page 78: Dsa Diagnostic Test Results

    After running the DSA diagnostic tests, use this information to resolve any issues that were found. DSA CPU stress test results The following messages can result when you run the CPU stress test. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 79 CPU Stress Test Passed. Recoverable Severity Event Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 089-801-000 : CPU Stress Test Aborted CPU Stress Test Aborted. Internal Program Error. Recoverable Severity Warning Serviceable...
  • Page 80 Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 089-804-000 : CPU Stress Test Aborted CPU Stress Test Aborted. User pressed Ctrl-C. Recoverable Severity Warning Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 81 Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 089-901-000 : CPU Stress Test Failed CPU Stress Test Failed. Recoverable Severity Error Serviceable Automatically notify support User Response Complete the following steps: 1. If the system has stopped responding, turn off and restart the system and then run the test again.
  • Page 82 Memory size is insufficient to run the test. At least 1 GB is required. Recoverable Severity Warning Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 202-803-000 : MemStr Test Aborted Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 83 User pressed Ctrl-C. Recoverable Severity Warning Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 202-901-000 : MemStr Test Failed Test Failed. Recoverable Severity Error Serviceable Automatically notify support User Response Complete the following steps: 1.
  • Page 84 Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 201-000-001 : Standalone Memory Test Passed Quick/Full Memory Test CPU 1 Passed. Recoverable Severity Event Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 85 Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 201-000-002 : Standalone Memory Test Passed Quick/Full Memory Test CPU 2 Passed. Recoverable Severity Event Serviceable Automatically notify support Related links – Lenovo Support website –...
  • Page 86 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-811-002 : Standalone Memory Test Aborted Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 87 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-811-003 : Standalone Memory Test Aborted Unable to Locate SMBIOS key "_SM_".
  • Page 88 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-812-002 : Standalone Memory Test Aborted Memory test is not supported for this system. Recoverable Severity Warning Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 89 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-812-003 : Standalone Memory Test Aborted Memory test is not supported for this system.
  • Page 90 Chipset Error: Can not turn OFF ECC error reporting in CPU. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 91 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-813-003 : Standalone Memory Test Aborted Chipset Error: Can not turn OFF ECC error reporting in CPU.
  • Page 92 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 93 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-815-000 : Standalone Memory Test Aborted Program Error with Quick Memory Menu Option Selection.
  • Page 94 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-815-003 : Standalone Memory Test Aborted Program Error with Quick Memory Menu Option Selection. Recoverable Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 95 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-816-000 : Standalone Memory Test Aborted Program Error with Full Memory Menu Option Selection.
  • Page 96 Lenovo Support website – Latest level of DSA • 201-816-003 : Standalone Memory Test Aborted Program Error with Full Memory Menu Option Selection. Recoverable Severity Warning Serviceable Automatically notify support User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 97 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-818-000 : Standalone Memory Test Aborted Unable to Locate SMBIOS key "_SM_".
  • Page 98 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 99 Related links – Lenovo Support website – Latest level of DSA • 201-819-000 : Standalone Memory Test Aborted The start-end address ranges in the restricted area of the memory. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1.
  • Page 100 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-820-000 : Standalone Memory Test Aborted Memory Upper limit is less than 16 Mbytes. Recoverable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 101 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-820-001 : Standalone Memory Test Aborted Memory Upper limit is less than 16 Mbytes.
  • Page 102 Lenovo Support website – Latest level of DSA • 201-821-000 : Standalone Memory Test Aborted Variable range MTRR registers are larger than fixed range MTRR registers. Recoverable Severity Warning Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 103 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-821-001 : Standalone Memory Test Aborted Variable range MTRR registers are larger than fixed range MTRR registers.
  • Page 104 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 105 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-822-001 : Standalone Memory Test Aborted Invalid MTRR service request. Recoverable Severity Warning Serviceable Automatically notify support...
  • Page 106 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-824-001 : Standalone Memory Test Aborted Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 107 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-824-002 : Standalone Memory Test Aborted Node Interleave feature must be OFF. Go to Setup and disable Node Interleave option and then re-run the test.
  • Page 108 – Lenovo Support website – Latest level of DSA • 201-826-001 : Standalone Memory Test Aborted BIOS: Memory Controller has been disabled. Go to Setup and Enable Memory Controller. Recoverable Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 109 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-826-002 : Standalone Memory Test Aborted BIOS: Memory Controller has been disabled. Go to Setup and Enable Memory Controller.
  • Page 110 • 201-827-001 : Standalone Memory Test Aborted BIOS: ECC function has been disabled by BIOS. Go to Setup and enable ECC generation. Recoverable Severity Warning Serviceable Automatically notify support User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 111 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-827-002 : Standalone Memory Test Aborted BIOS: ECC function has been disabled by BIOS. Go to Setup and enable ECC generation.
  • Page 112 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 113 Related links – Lenovo Support website – Latest level of DSA • 201-844-002 : Standalone Memory Test Aborted Chipset Error: Problem in masking MSR machine check control MASK registers. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1.
  • Page 114 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-845-002 : Standalone Memory Test Aborted Chipset Error: Problem clearing MSR machine check control registers. Recoverable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 115 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-845-003 : Standalone Memory Test Aborted Chipset Error: Problem clearing MSR machine check control registers.
  • Page 116 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-859-002 : Standalone Memory Test Aborted INVALID XSECSRAT type. Recoverable Severity Warning Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 117 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-859-003 : Standalone Memory Test Aborted INVALID XSECSRAT type.
  • Page 118 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 119 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-860-003 : Standalone Memory Test Aborted No OEM0 type 1 found. Recoverable Severity Warning Serviceable Automatically notify support...
  • Page 120 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-861-003 : Standalone Memory Test Aborted No SRAT type 1 found. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 121 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-862-000 : Standalone Memory Test Aborted No OEM1 structure found.
  • Page 122 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-862-003 : Standalone Memory Test Aborted No OEM1 structure found. Recoverable Severity Warning Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 123 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-863-000 : Standalone Memory Test Aborted No IBMERROR key in OEM1 structure.
  • Page 124 User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 125 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-864-000 : Standalone Memory Test Aborted No GAS located in OEM1.
  • Page 126 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-865-000 : Standalone Memory Test Aborted Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 127 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-865-001 : Standalone Memory Test Aborted No XSECSRAT key in OEM0 structure.
  • Page 128 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-866-000 : Standalone Memory Test Aborted EFI-SAL Invalid parameter from GetMemoryMap function. Recoverable Severity Warning Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 129 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-866-001 : Standalone Memory Test Aborted EFI-SAL Invalid parameter from GetMemoryMap function.
  • Page 130 EFI/SAL: Buffer not allocated. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 131 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-867-001 : Standalone Memory Test Aborted EFI/SAL: Buffer not allocated.
  • Page 132 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 133 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-868-002 : Standalone Memory Test Aborted EFI/SAL: Buffer allocated in GetMemoryMap too small.
  • Page 134 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-869-001 : Standalone Memory Test Aborted EFI/SAL Invalid parameter from GetMemoryMap function. Recoverable Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 135 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-869-002 : Standalone Memory Test Aborted EFI/SAL Invalid parameter from GetMemoryMap function.
  • Page 136 – Lenovo Support website – Latest level of DSA • 201-870-001 : Standalone Memory Test Aborted CPU Doamin in ACPI not valid. Recoverable Severity Warning Serviceable Automatically notify support User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 137 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-870-002 : Standalone Memory Test Aborted CPU Doamin in ACPI not valid.
  • Page 138 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 139 Related links – Lenovo Support website – Latest level of DSA • 201-871-002 : Standalone Memory Test Aborted Data Mis-compare encountered. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: 1. Perform the actions mentioned one at a time and try the test after each action.
  • Page 140 Lenovo Support website – Latest level of DSA • 201-877-002 : Standalone Memory Test Aborted BIOS: Sparing in Extended PCI reg. must be OFF. Go to setup and disable sparing. Recoverable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 141 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-877-003 : Standalone Memory Test Aborted BIOS: Sparing in Extended PCI reg. must be OFF. Go to setup and disable sparing.
  • Page 142 Latest level of DSA • 201-878-002 : Standalone Memory Test Aborted Sparing feature must be turned OFF. Go to setup and turn the sparing feature OFF. Recoverable Severity Warning Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 143 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-878-003 : Standalone Memory Test Aborted Sparing feature must be turned OFF. Go to setup and turn the sparing feature OFF.
  • Page 144 1. Perform the actions mentioned one at a time and try the test after each action. 2. If the problem remains, contact your technical-service representative. 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 145 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-885-003 : Standalone Memory Test Aborted Processor does not support MTRR register manipulation. Can not write to memory without cache.
  • Page 146 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-886-003 : Standalone Memory Test Aborted Memory Upper limit is less than 16 Mbytes. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 147 Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Related links – Lenovo Support website – Latest level of DSA • 201-899-000 : Standalone Memory Test Aborted Memory Diagnostics Test Aborted by user.
  • Page 148 3. Turn off the system and disconnect it from power. Wait for 45 seconds. Reseat DIMM(s). Reconnect it to power. 4. Make sure that DSA and BIOS/uEFI are at the latest level. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 149 7. If failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links – Lenovo Support website – Latest level of DSA • 201-901-001 : Standalone Memory Test Failed Memory Diagnostics Test Failed.
  • Page 150 Test results for the DSA optical drive test The following messages can result when you run the DSA optical drive test. • 215-000-000 : Optical Drive Test Passed Optical Drive Test Passed. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 151 Recoverable Severity Event Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 215-801-000 : Optical Drive Test Aborted Optical Drive Test Aborted. Unable to communicate with driver. Recoverable Severity Warning Serviceable Automatically notify support...
  • Page 152 Latest level of DSA • 215-804-000 : Optical Drive Test Aborted Optical Drive Test Aborted. The media tray is open. Recoverable Severity Warning Serviceable Automatically notify support User Response Complete the following steps: Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 153 5. If failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links – Lenovo Support website – Latest level of DSA • 215-901-000 : Optical Drive Test Aborted Optical Drive Test Aborted. Drive media is not detected.
  • Page 154 The following messages can result when you run the tape drive test. Test results for the DSA tape drive test The following messages can result when you run the DSA tape drive test. • 264-000-000 : Tape Test Passed Tape Test Passed. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 155 Recoverable Severity Event Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 264-901-000 : Tape Test Failed An error was found in the tape alert log. Recoverable Severity Error Serviceable Automatically notify support...
  • Page 156 Service Guide" for the next corrective action. Related links – Lenovo Support website – Latest level of DSA • 264-904-000 : Tape Test Failed Tape Test Failed. Drive hardware error. Recoverable Severity Error Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 157 6. If the failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links – Lenovo Support website – Latest level of DSA • 264-905-000 : Tape Test Failed Tape Test Failed. Software error: invalid request.
  • Page 158 1. Clean the tape drive using the appropriate cleaning media and install new media. Related links – Lenovo Support website – Latest level of DSA • 264-908-000 : Tape Test Failed An error was found in getting tape capacity. Recoverable Severity Error Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 159 1. Make sure that medium is present. 2. Clean the tape drive using the appropriate cleaning media and install new media. Related links – Lenovo Support website – Latest level of DSA DSA hard drive test results The following messages can result when you run the hard drive test.
  • Page 160 • 407-000-000 : LSIESG:DiskDefaultDiagnostic Test Passed The test passed. Recoverable Severity Event Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 407-800-000 : LSIESG:DiskDefaultDiagnostic Test Aborted Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 161 The test was canceled. Recoverable Severity Warning Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 407-900-000 : LSIESG:DiskDefaultDiagnostic Test Failed The hard drive self-test detected a failure. Recoverable Severity Error Serviceable Automatically notify support...
  • Page 162 Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 409-005-000 : Nvidia::DiagnosticServiceProvider::Matrix Test Passed Nvidia GPU Matrix test passed. Recoverable Severity Event Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 163 Related links – Lenovo Support website – Latest level of DSA • 409-006-000 : Nvidia::DiagnosticServiceProvider::Binomial Test Passed Nvidia GPU Binomial test passed. Recoverable Severity Event Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA •...
  • Page 164 Warning Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 409-900-000 : NVIDIA User Diagnostic Test Failed NVIDIA User Diagnostic Test Failed. Recoverable Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 165 4. Rerun the diagnostics, using the same GPU, on system that is known to be working. A variety of system issues can cause diagnostic failure. 5. If the problem remains, contact your IBM technical-support representative. Related links – Lenovo Support website – Latest level of DSA • 409-903-000 : Nvidia::DiagnosticServiceProvider::Bandwidth Test Failed Nvidia GPU Bandwidth Test Failed.
  • Page 166 5. If the problem remains, contact your IBM technical-support representative. Related links – Lenovo Support website – Latest level of DSA • 409-906-000 : Nvidia::DiagnosticServiceProvider::Binomial Test Failed Nvidia GPU Binomial Test Failed. Recoverable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 167 5. If the problem remains, contact your IBM technical-support representative. Related links – Lenovo Support website – Latest level of DSA DSA system management test results The following messages can result when you run the system management test.
  • Page 168 Perform the actions mentioned one at a time and try the test after each action: 1. Turn off the system and disconnect it from power. Wait for 45 seconds. Reconnect it to power. 2. Make sure that DSA and BMC/IMM are at the latest level. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 169 Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 166-804-001 : IMM I2C Test Aborted Invalid Command. Recoverable Severity Warning Serviceable Automatically notify support User Response Perform the actions mentioned one at a time and try the test after each action: 1.
  • Page 170 • 166-808-001 : IMM I2C Test Aborted Reservation Canceled or Invalid Reservation ID. Recoverable Severity Warning Serviceable Automatically notify support User Response Perform the actions mentioned one at a time and try the test after each action: Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 171 1. Turn off the system and disconnect it from power. Wait for 45 seconds. Reconnect it to power. 2. Make sure that DSA and BMC/IMM are at the latest level. Related links – IBM Support website – Latest level of DSA –...
  • Page 172 – Latest level of DSA – Latest level of BMC/IMM • 166-813-001 : IMM I2C Test Aborted Cannot return number of requested data bytes. Recoverable Severity Warning Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 173 User Response Perform the actions mentioned one at a time and try the test after each action: 1. Turn off the system and disconnect it from power. Wait for 45 seconds. Reconnect it to power. 2. Make sure that DSA and BMC/IMM are at the latest level. Related links –...
  • Page 174 Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 166-818-001 : IMM I2C Test Aborted Cannot execute duplicated request. Recoverable Severity Warning Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 175 Automatically notify support User Response Perform the actions mentioned one at a time and try the test after each action: 1. Turn off the system and disconnect it from power. Wait for 45 seconds. Reconnect it to power. 2. Make sure that DSA and BMC/IMM are at the latest level. Related links –...
  • Page 176 2. Make sure that DSA and BMC/IMM are at the latest level. Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM • 166-823-001 : IMM I2C Test Aborted Cannot execute command. Insufficient privilege level. Recoverable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 177 Severity Warning Serviceable Automatically notify support User Response Perform the actions mentioned one at a time and try the test after each action: 1. Turn off the system and disconnect it from power. Wait for 45 seconds. Reconnect it to power. 2.
  • Page 178 Perform the actions mentioned one at a time and try the test after each action: 1. Turn off the system and disconnect it from power. Wait for 45 seconds. Reconnect it to power. 2. Make sure that DSA and BMC/IMM are at the latest level. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 179 3. Run the test again. 4. If failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links – IBM Support website – Latest level of DSA – Latest level of BMC/IMM •...
  • Page 180 The following messages can result when you run the DSA checkpoint panel test. • 180-000-000 : Check-point Panel Test Passed Check-point Panel Test Passed. Recoverable Severity Event Serviceable Automatically notify support Related links Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 181 – Lenovo Support website – Latest level of DSA • 180-801-000 : Check-point Panel Test Aborted Check-point Panel Test Aborted. BMC is unable to verify that the operator information panel cable is connected. Recoverable Severity Warning Serviceable Automatically notify support...
  • Page 182 Recoverable Severity Event Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 405-002-000 : BRCM:TestEEPROM Test Passed The test passed. Recoverable Severity Event Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 183 Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 405-003-000 : BRCM:TestInternalMemory Test Passed The test passed. Recoverable Severity Event Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA •...
  • Page 184 Recoverable Severity Warning Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 405-801-000 : BRCM:TestMIIRegisters Test Aborted The MII register test was canceled. Recoverable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 185 Severity Warning Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 405-802-000 : BRCM:TestEEPROM Test Aborted The EEPROM test was canceled. Recoverable Severity Warning Serviceable Automatically notify support Related links – Lenovo Support website –...
  • Page 186 Latest level of DSA • 405-807-000 : BRCM:TestLEDs Test Aborted Verification of status LEDs was canceled. Recoverable Severity Warning Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 187 3. If failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links – Lenovo Support website – Latest level of DSA • 405-901-000 : BRCM:TestMIIRegisters Test Failed A failure was detected while testing internal PHY registers.
  • Page 188 Guide" for the next corrective action. Related links – Lenovo Support website – Latest level of DSA • 405-904-000 : BRCM:TestInterrupt Test Failed A failure was detected while testing interrupts. Recoverable Severity Error Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 189 3. If failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links – Lenovo Support website – Latest level of DSA • 405-905-000 : BRCM:TestLoopbackMAC Test Failed BRCM:TestLoopbackMAC Test Failed.
  • Page 190 Test results for the DSA Brocade test The following messages can result when you run the DSA Brocade test. • 218-000-000 : Brocade:MemoryTest Passed The test passed. Recoverable Severity Event Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 191 Related links – Lenovo Support website – Latest level of DSA • 218-001-000 : Brocade:ExternalLoopbackTest Passed The test passed. Recoverable Severity Event Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 218-002-000 : Brocade:SerdesLoopbackTest Passed The test passed.
  • Page 192 The test passed. Recoverable Severity Event Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 218-800-000 : Brocade:MemoryTest Aborted The test was canceled. Recoverable Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 193 Warning Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 218-801-000 : Brocade:ExternalLoopbackTest Aborted The test was canceled. Recoverable Severity Warning Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA •...
  • Page 194 • 218-806-000 : Brocade:InternalLoopbackTest Aborted The test was canceled. Recoverable Severity Warning Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 218-900-000 : Brocade:MemoryTest Failed Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 195 2. Verify whether the firmware is at proper level. 3. Rerun the test. 4. If the problem remains, contact your IBM technical-support representative. Related links – Lenovo Support website – Latest level of DSA • 218-901-000 : Brocade:ExternalLoopbackTest Failed A failure was detected during the Loopback test.
  • Page 196 Related links – Lenovo Support website – Latest level of DSA • 218-904-000 : Brocade:ExternalEthLoopbackTest Failed A failure was detected during the Loopback test. Recoverable Severity Error Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 197 3. Verify whether the firmware is at proper level. 4. Rerun the test. 5. If the problem remains, contact your IBM technical-support representative. Related links – Lenovo Support website – Latest level of DSA • 218-905-000 : Brocade:SerdesEthLoopbackTest Failed A failure was detected during the Loopback test.
  • Page 198 Recoverable Severity Event Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 516-002-000 : ELXUCNA: ELXUCNA: NIC LED(Beacon)Test Passed The test passed. Recoverable Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 199 Event Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 516-800-000 : ELXUCNA: NIC MAC LoopBackTest Aborted Loopback testing at the MAC layer was canceled. Recoverable Severity Warning Serviceable Automatically notify support Related links –...
  • Page 200 3. If failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links – Lenovo Support website – Latest level of DSA Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 201 3. If failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links – Lenovo Support website – Latest level of DSA DSA Mellanox adapter test results The following messages can result when you run the Mellanox adapter test.
  • Page 202 Recoverable Severity Warning Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 408-900-000 : MLNX:MLNX_DiagnosticTestEthernetPort Test Failed Port Test Failed. Recoverable Severity Error Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 203 2. If these condition was met but the test keeps failing the port's adapter might be faulty. 3. Try replacing the adapter and repeating the test. Related links – Lenovo Support website – Latest level of DSA • 408-901-000 : MLNX:MLNX_DiagnosticTestIBPort Test Failed Port Test Failed.
  • Page 204 3. Make sure that DSA and BIOS/uEFI are at the latest level. 4. If the problem remains, contact your technical-service representative. Related links – Lenovo Support website – Latest level of DSA Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 205 4. Replace the scalability cable(s) for specified port(s). 5. If the problem remains, contact your technical-service representative. Related links – Lenovo Support website – Latest level of DSA DSA Intel network test results The following messages can result when you run the Intel network test.
  • Page 206 Recoverable Severity Event Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 406-004-000 : IANet:Loopback Test Passed The test passed. Recoverable Severity Event Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 207 Automatically notify support Related links – Lenovo Support website – Latest level of DSA • 406-800-000 : IANet:Registers Test Aborted Registers test was canceled. Recoverable Severity Warning Serviceable Automatically notify support Related links – Lenovo Support website – Latest level of DSA •...
  • Page 208 DSA Diagnostic Event Log within the Firmware/VPD section for this component. 2. Rerun the test. 3. If failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 209 Related links – Lenovo Support website – Latest level of DSA • 406-901-000 : IANet:EEPROM Test Failed A failure was detected during the EEPROM test. Recoverable Severity Error Serviceable Automatically notify support User Response Complete the following steps: 1. Check component firmware level and upgrade if necessary. The installed firmware level can be found in the DSA Diagnostic Event Log within the Firmware/VPD section for this component.
  • Page 210 4. If failure remains, refer to "Troubleshooting by symptom" in the system "Installation and Service Guide" for the next corrective action. Related links – Lenovo Support website – Latest level of DSA Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 211: Event Messages

    In addition, the IMM2 sends that event to the CMM and to the Lenovo XClarity Administrator or Flex System Manager management software (if available). For each event code, the following fields are displayed: Event identifier A hexadecimal identifier that uniquely identifies an event or class of events.
  • Page 212 The SNMP trap ID that is found in the SNMP alert management information base (MIB). Automatically notify Support If this field is set to Yes and you have enabled Call Home on the Lenovo XClarity Administrator or Electronic Service Agent (ESA) on Flex System Manager management software (if available), Support will be notified automatically if the event is generated.
  • Page 213 Serviceable Automatically notify support Alert Category System - other SNMP Trap ID CIM Information Prefix: IMM ID: 0002 User Response Make sure that the certificate that you are importing is correct and properly generated. • 40000003-00000000 : Ethernet Data Rate modified from [arg1] to [arg2] by user [arg3]. The specified user has changed the Ethernet data rate of the Integrated Management Module external network interface to the specified value.
  • Page 214 Management Module external network interface to the specified value. May also be shown as 4000000600000000 or 0x4000000600000000 Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0006 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 215 Information only; no action is required. • 40000007-00000000 : Ethernet interface [arg1] by user [arg2]. The specified user has enabled or disabled the Ethernet interface. May also be shown as 4000000700000000 or 0x4000000700000000 Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information...
  • Page 216 The specified user has changed the gateway address of the Integrated Management Module external network interface to the specified value. May also be shown as 4000000b00000000 or 0x4000000b00000000 Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 217 Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0011 User Response Information only; no action is required. • 4000000c-00000000 : OS Watchdog response [arg1] by [arg2] . The OS Watchdog timer has been enabled or disabled by a user. May also be shown as 4000000c00000000 or 0x4000000c00000000 Severity Info...
  • Page 218 A user has exceeded the maximum allowed number of unsuccessful login attempts from a web browser and has been prevented from logging in for the lockout period. May also be shown as 4000001000000000 or 0x4000001000000000 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 219 Severity Warning Serviceable Automatically notify support Alert Category System - Remote Login SNMP Trap ID CIM Information Prefix: IMM ID: 0016 User Response Complete the following steps until the problem is solved: 1. Make sure that the correct login ID and password are being used. 2.
  • Page 220 The specified user has deleted system log events or audit log events. May also be shown as 4000001400000000 or 0x4000001400000000 Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 221 CIM Information Prefix: IMM ID: 0020 User Response Information only; no action is required. • 40000015-00000000 : Management Controller [arg1] reset was initiated by user [arg2]. The Integrated Management Module has been reset. The logs provide additional details. May also be shown as 4000001500000000 or 0x4000001500000000 Severity Info Serviceable...
  • Page 222 Information only; no action is required. • 40000019-00000000 : LAN: Ethernet[[arg1]] interface is now active. The IMM Ethernet interface has been enabled. May also be shown as 4000001900000000 or 0x4000001900000000 Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 223 Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0025 User Response Information only; no action is required. • 4000001a-00000000 : DHCP setting changed to [arg1] by user [arg2]. The specified user has changed the DHCP setting of the Integrated Management Module external network interface.
  • Page 224 • 4000001d-00000000 : Watchdog [arg1] Failed to Capture Screen. An operating-system error has occurred, and the screen capture failed. May also be shown as 4000001d00000000 or 0x4000001d00000000 Severity Error Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 225 Alert Category System - other SNMP Trap ID CIM Information Prefix: IMM ID: 0029 User Response Complete the following steps until the problem is solved: 1. Reconfigure the watchdog timer to a higher value. 2. Make sure that the IMM Ethernet over USB interface is enabled. 3.
  • Page 226 • 40000021-00000000 : Management Controller [arg1] clock has been set from NTP server [arg2]. The IMM clock has been set to the date and time that are provided by the Network Time Protocol server. May also be shown as 4000002100000000 or 0x4000002100000000 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 227 Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0033 User Response Information only; no action is required. • 40000022-00000000 : SSL data in the Management Controller [arg1] configuration data is invalid. Clearing configuration data region and disabling SSL.
  • Page 228 To avoid losing older log entries, save the log as a text file and clear the log. May also be shown as 4000002500000000 or 0x4000002500000000 Severity Info Serviceable Automatically notify support Alert Category System - Event Log Fullness SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 229 CIM Information Prefix: IMM ID: 0037 User Response Information only; no action is required. • 40000026-00000000 : The [arg1] on system [arg2] is 100% full. The IMM event log is full. New entries in the log will overwrite the oldest entries. To avoid losing older log entries, save the log as a text file and clear the log.
  • Page 230 Info Serviceable Automatically notify support Alert Category System - Remote Login SNMP Trap ID CIM Information Prefix: IMM ID: 0041 User Response Complete the following steps until the problem is solved: Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 231 1. Make sure that the correct login ID and password are being used. 2. Have the system administrator reset the login ID or password. • 4000002a-00000000 : [arg1] firmware mismatch internal to system [arg2]. Please attempt to flash the [arg3] firmware. A specific type of firmware mismatch has been detected.
  • Page 232 Information only; no action is required. • 4000002e-00000000 : DDNS registration successful. The domain name is [arg1]. The DDNS registration was successful. May also be shown as 4000002e00000000 or 0x4000002e00000000 Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 233 Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0046 User Response Information only; no action is required. • 4000002f-00000000 : IPv6 enabled by user [arg1] . The specified user has enabled IPv6 support on the Integrated Management Module. May also be shown as 4000002f00000000 or 0x4000002f00000000 Severity Info...
  • Page 234 • 40000033-00000000 : IPv6 stateless auto-configuration enabled by user [arg1]. IPv6 stateless address auto-configuration has been enabled on the Integrated Management Module by the specified user. May also be shown as 4000003300000000 or 0x4000003300000000 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 235 Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0051 User Response Information only; no action is required. • 40000034-00000000 : IPv6 static IP configuration disabled by user [arg1]. The specified user has disabled IPv6 static address assignment on the Integrated Management Module. May also be shown as 4000003400000000 or 0x4000003400000000 Severity Info...
  • Page 236 May also be shown as 4000003700000000 or 0x4000003700000000 Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0055 User Response Information only; no action is required. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 237 • 40000038-00000000 : ENET[[arg1]] IPv6-Static:HstName=[arg2], IP@=[arg3], Pref=[arg4], GW@= [arg5]. The IPv6 static address is active. May also be shown as 4000003800000000 or 0x4000003800000000 Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0056 User Response Information only;...
  • Page 238 • 4000003c-00000000 : Platform Watchdog Timer expired for [arg1]. IMM has detected an OS did not start in the expected amount of time. May also be shown as 4000003c00000000 or 0x4000003c00000000 Severity Error Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 239 Alert Category System - Loader timeout SNMP Trap ID CIM Information Prefix: IMM ID: 0060 User Response 1. Reconfigure the watchdog timer to a higher value. 2. Make sure that the IMM Ethernet over USB interface is enabled. 3. Reinstall the RNDIS or cdc_ether device driver for the operating system. 4.
  • Page 240 The specified user has changed the HTTPS port number. New HTTPS (secure web) connections must use the new port number. May also be shown as 4000004000000000 or 0x4000004000000000 Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0064 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 241 User Response Information only; no action is required. • 40000041-00000000 : CIM/XML HTTP port number changed from [arg1] to [arg2] by user [arg3]. The specified user has changed the CIM HTTP port number. May also be shown as 4000004100000000 or 0x4000004100000000 Severity Info Serviceable...
  • Page 242 • 40000045-00000000 : Syslog port number changed from [arg1] to [arg2] by user [arg3]. A user has modified the Syslog receiver port number. May also be shown as 4000004500000000 or 0x4000004500000000 Severity Info Serviceable Automatically notify support Alert Category none Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 243 SNMP Trap ID CIM Information Prefix: IMM ID: 0069 User Response Information only; no action is required. • 40000046-00000000 : Remote Presence port number changed from [arg1] to [arg2] by user [arg3]. A user has modified the Remote Presence port number. May also be shown as 4000004600000000 or 0x4000004600000000 Severity Info...
  • Page 244 • 4000004a-00000000 : SNMP [arg1] disabled by user [arg2] . The specified user has disabled the SNMPv1 or SNMPv3 agent. May also be shown as 4000004a00000000 or 0x4000004a00000000 Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 245 Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0074 User Response Information only; no action is required. • 4000004b-00000000 : SNMPv1 [arg1] set by user [arg2]: Name=[arg3], AccessType=[arg4], Address=[arg5], . A user changed the SNMP community string. May also be shown as 4000004b00000000 or 0x4000004b00000000 Severity Info...
  • Page 246 May also be shown as 4000004e00000000 or 0x4000004e00000000 Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0078 User Response Information only; no action is required. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 247 • 4000004f-00000000 : Date and Time set by user [arg1]: Date=[arg2], Time-[arg3], DST Auto-adjust= [arg4], Timezone=[arg5]. The specified user has changed the date and time in the Integrated Management Module. May also be shown as 4000004f00000000 or 0x4000004f00000000 Severity Info Serviceable Automatically notify support Alert Category...
  • Page 248 • 40000053-00000000 : Server [arg1] scheduled for every [arg2] at [arg3] by user [arg4]. A user configured a recurring Server Power Action. May also be shown as 4000005300000000 or 0x4000005300000000 Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 249 CIM Information Prefix: IMM ID: 0083 User Response Information only; no action is required. • 40000054-00000000 : Server [arg1] [arg2] cleared by user [arg3]. A user cleared a Server Power Action. May also be shown as 4000005400000000 or 0x4000005400000000 Severity Info Serviceable Automatically notify support...
  • Page 250 • 40000058-00000000 : DNS servers set by user [arg1]: UseAdditionalServers=[arg2], PreferredDNStype=[arg3], IPv4Server1=[arg4], IPv4Server2=[arg5], IPv4Server3=[arg6], IPv6Server1=[arg7], IPv6Server2=[arg8], IPv6Server3=[arg9]. The specified user has configured the DNS servers. May also be shown as 4000005800000000 or 0x4000005800000000 Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 251 Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0088 User Response Information only; no action is required. • 40000059-00000000 : LAN over USB [arg1] by user [arg2]. A user configured USB-LAN. May also be shown as 4000005900000000 or 0x4000005900000000 Severity Info Serviceable...
  • Page 252 Information only; no action is required. • 4000005d-00000000 : Secure LDAP [arg1] by user [arg2]. A user enables or disables Secure LDAP services. May also be shown as 4000005d00000000 or 0x4000005d00000000 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 253 Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0093 User Response Information only; no action is required. • 4000005e-00000000 : SSH [arg1] by user [arg2]. The specified user has enabled or disabled the Secure Shell (SSH) service. May also be shown as 4000005e00000000 or 0x4000005e00000000 Severity Info...
  • Page 254 May also be shown as 4000006100000000 or 0x4000006100000000 Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0097 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 255 Information only; no action is required. • 40000062-00000000 : Global Login General Settings set by user [arg1]: AuthenticationMethod= [arg2], LockoutPeriod=[arg3], SessionTimeout=[arg4]. A user changes the Global Login General Settings. May also be shown as 4000006200000000 or 0x4000006200000000 Severity Info Serviceable Automatically notify support Alert Category none...
  • Page 256 • 40000066-00000000 : User [arg1] password modified. The password for the specified user account has been changed. May also be shown as 4000006600000000 or 0x4000006600000000 Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 257 Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0102 User Response Information only; no action is required. • 40000067-00000000 : User [arg1] role set to [arg2]. A user account role assigned. May also be shown as 4000006700000000 or 0x4000006700000000 Severity Info Serviceable...
  • Page 258 Information only; no action is required. • 4000006b-00000000 : SSH Client key imported for user [arg1] from [arg2]. User imported an SSH Client key. May also be shown as 4000006b00000000 or 0x4000006b00000000 Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 259 Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0107 User Response Information only; no action is required. • 4000006c-00000000 : SSH Client key removed from user [arg1]. User removed an SSH Client key. May also be shown as 4000006c00000000 or 0x4000006c00000000 Severity Info Serviceable...
  • Page 260 SNMP Trap ID CIM Information Prefix: IMM ID: 0111 User Response Information only; no action is required. • 40000070-00000000 : SNMP Traps enabled by user [arg1]: EnabledAlerts=[arg2], AllowedFilters= [arg3] . Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 261 The specified user has enabled Simple Network Management Protocol (SNMP) traps. May also be shown as 4000007000000000 or 0x4000007000000000 Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0112 User Response Information only; no action is required. •...
  • Page 262 The soft minimum power cap value has been changed. May also be shown as 4000007400000000 or 0x4000007400000000 Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 263 Prefix: IMM ID: 0116 User Response Information only; no action is required. • 40000075-00000000 : The measured power value exceeded the power cap value. The measured power value has exceeded the power cap value. May also be shown as 4000007500000000 or 0x4000007500000000 Severity Warning Serviceable...
  • Page 264 • 40000079-00000000 : Static Power Savings mode has been turned on by user [arg1]. Static Power Savings mode turned on by user. May also be shown as 4000007900000000 or 0x4000007900000000 Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 265 Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0121 User Response Information only; no action is required. • 4000007a-00000000 : Static Power Savings mode has been turned off by user [arg1]. Static Power Savings mode turned off by user. May also be shown as 4000007a00000000 or 0x4000007a00000000 Severity Info...
  • Page 266 Prefix: IMM ID: 0125 User Response Information only; no action is required. • 4000007e-00000000 : External throttling occurred . External throttling has occurred. May also be shown as 4000007e00000000 or 0x4000007e00000000 Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 267 Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0126 User Response Information only; no action is required. • 4000007f-00000000 : Power cap throttling occurred. Power cap throttling has occurrred. May also be shown as 4000007f00000000 or 0x4000007f00000000 Severity Info Serviceable...
  • Page 268 SNMP Trap ID CIM Information Prefix: IMM ID: 0130 User Response Information only; no action is required. • 40000083-00000000 : The new minimum power cap value has returned below the power cap value. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 269 The new minimum power cap value has returned below the power cap value. May also be shown as 4000008300000000 or 0x4000008300000000 Severity Info Serviceable Automatically notify support Alert Category Warning - Power SNMP Trap ID CIM Information Prefix: IMM ID: 0131 User Response Information only;...
  • Page 270 • 40000087-00000000 : Manual Call Home by user [arg1]: [arg2]. The specified user has submitted a service request. May also be shown as 4000008700000000 or 0x4000008700000000 Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 271 Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0135 User Response IBM Support will address the problem. • 40000088-00000000 : Management Controller [arg1]: Configuration restoration from a file by user [arg2] completed. The specified user has successfully restored the configuration of the specified management controller from a file.
  • Page 272 One or more of the Storage Management IP addresses has changed. May also be shown as 4000008b00000000 or 0x4000008b00000000 Severity Info Serviceable Automatically notify support Alert Category System - IMM Network event Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 273 SNMP Trap ID CIM Information Prefix: IMM ID: 0139 User Response Information only; no action is required. • 4000008c-00000000 : Security: Userid: [arg1] had [arg2] login failures from a CIM client at IP address [arg3]. A user has exceeded the maximum allowed number of unsuccessful login attempts from a CIM client and has been prevented from logging in for the lockout period.
  • Page 274 Information only; no action is required. • 40000090-00000000 : The bare metal update application reports a status of [arg1]. Bare Metal Update Application Status May also be shown as 4000009000000000 or 0x4000009000000000 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 275 Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0144 User Response Information only; no action is required. • 40000091-00000000 : User [arg1] has terminated an active console session. A user has terminated an active console session. May also be shown as 4000009100000000 or 0x4000009100000000 Severity Info...
  • Page 276 User generated a new encryption key pair and installed a self-signed certificate for the TKLM client. May also be shown as 4000009400000000 or 0x4000009400000000 Severity Info Serviceable Automatically notify support Alert Category none SNMP Trap ID CIM Information Prefix: IMM ID: 0148 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 277 User Response Information only; no action is required. • 40000095-00000000 : User [arg1] has generated a new encryption key and certificate signing request for the TKLM client. User generated a new encryption key and certificate signing request for the TKLM client. May also be shown as 4000009500000000 or 0x4000009500000000 Severity Info...
  • Page 278 [arg3]. A user was not able to log in to a Management Controller from IPMI May also be shown as 4000009900000000 or 0x4000009900000000 Severity Info Serviceable Automatically notify support Alert Category Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 279 System - Remote Login SNMP Trap ID CIM Information Prefix: IMM ID: 0153 User Response Information only; no action is required. • 4000009a-00000000 : Security: Userid: [arg1] had [arg2] login failures from SNMP client at IP address [arg3]. A user was not able to access a Management Controller from SNMP. May also be shown as 4000009a00000000 or 0x4000009a00000000 Severity Info...
  • Page 280 • 4000009e-00000000 : Login ID: [arg1] from [arg2] at IP address [arg3] has been logged off. A user has been logged off of a Management Controller. May also be shown as 4000009e00000000 or 0x4000009e00000000 Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 281 Automatically notify support Alert Category System - Remote Login SNMP Trap ID CIM Information Prefix: IMM ID: 0158 User Response Information only; no action is required. • 4000009f-00000000 : User [arg1] has initiated a TKLM Server Connection Test to check connectivity to server [arg2].
  • Page 282 Information only; no action is required. • 400000a3-00000000 : User [arg1] has set the SMTP Server reverse-path to [arg2]. User set SMTP Server reverse-path address. May also be shown as 400000a300000000 or 0x400000a300000000 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 283 Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0163 User Response Information only; no action is required. • 400000a4-00000000 : User [arg1] has removed a certificate. User removed certificate. May also be shown as 400000a400000000 or 0x400000a400000000 Severity Info...
  • Page 284 Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0167 User Response Information only; no action is required. • 400000a8-00000000 : The server was reset via pushbutton. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 285 Server was reset via pushbutton. May also be shown as 400000a800000000 or 0x400000a800000000 Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0168 User Response Information only; no action is required. •...
  • Page 286 Server was automatically powered on because the power restore policy is set to always restore. May also be shown as 400000ac00000000 or 0x400000ac00000000 Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 287 Prefix: IMM ID: 0172 User Response Information only; no action is required. • 400000ad-00000000 : The server was automatically powered on because the power restore policy is set to restore previous power state.. Server was automatically powered on because the power restore policy is set to restore previous power state.
  • Page 288 • 400000b1-00000000 : The server was powered up via Real Time Clock (scheduled power on). Server was powered up via Real Time Clock (scheduled power on). May also be shown as 400000b100000000 or 0x400000b100000000 Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 289 Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0177 User Response Information only; no action is required. • 400000b2-00000000 : The server was powered off for an unknown reason. Server was powered off for an unknown reason. May also be shown as 400000b200000000 or 0x400000b200000000 Severity Info...
  • Page 290 • 400000b6-00000000 : The server stayed powered off because the power restore policy is set to always restore.. Server stayed powered off because the power restore policy is set to always restore. May also be shown as 400000b600000000 or 0x400000b600000000 Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 291 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0182 User Response Information only; no action is required. • 400000b7-00000000 : The server stayed powered off because the power restore policy is set to restore previous power state..
  • Page 292 Information only; no action is required. • 400000bb-00000000 : Management Controller [arg1] reset was initiated by PRESET. Management Controller reset was initiated by PRESET. May also be shown as 400000bb00000000 or 0x400000bb00000000 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 293 Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0187 User Response Information only; no action is required. • 400000bc-00000000 : Management Controller [arg1] reset was initiated by CMM. Management Controller reset was initiated by CMM. May also be shown as 400000bc00000000 or 0x400000bc00000000 Severity Info...
  • Page 294 System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0191 User Response Information only; no action is required. • 400000c0-00000000 : Inventory data collecting and processing complete for [arg1]. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 295 Inventory data collecting and processing complete. May also be shown as 400000c000000000 or 0x400000c000000000 Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: IMM ID: 0192 User Response Information only; no action is required. •...
  • Page 296 3. Make sure that the room temperature is within operating specifications. • 80010701-3702ffff : Numeric sensor [NumericSensorElementName] going high (upper non-critical) has asserted. The inlet 2 temperature has exceeded its specified threshold. May also be shown as 800107013702ffff or 0x800107013702ffff Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 297 Warning Serviceable Automatically notify support Alert Category Warning - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0490 User Response Complete the following steps until the problem is solved: 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues.
  • Page 298 SNMP Trap ID CIM Information Prefix: PLAT ID: 0494 User Response Use one of the following procedures: – If the specified sensor is Planar 3.3V or Planar 5V, replace the system board. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 299 – If the specified sensor is Planar 12V, check the Chassis Management Module or Flex System Manager event log for power-supply-related issues, and resolve those issues. If the problem remains, replace the system board. • 80010b01-3701ffff : Numeric sensor Inlet 1 Temp going high (upper non-recoverable) has asserted. has asserted.
  • Page 300 A sensor has detected. May also be shown as 8003010e2581ffff or 0x8003010e2581ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0508 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 301 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 302 • 80070101-030102ff : Sensor CPU 1 Overtemp has transitioned from normal to non-critical state. The microprocessor 1 temperature has risen above its specified threshold. May also be shown as 80070101030102ff or 0x80070101030102ff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 303 Severity Warning Serviceable Automatically notify support Alert Category Warning - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0520 User Response Complete the following steps until the problem is solved: 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues.
  • Page 304 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3. Make sure that the room temperature is within operating specifications. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 305 • 80070101-0302ffff : Sensor CPU 2 Overtemp has transitioned from normal to non-critical state. The temperature of microprocessor 2 has exceeded its specified threshold. May also be shown as 800701010302ffff or 0x800701010302ffff Severity Warning Serviceable Automatically notify support Alert Category Warning - Temperature SNMP Trap ID CIM Information...
  • Page 306 Severity Warning Serviceable Automatically notify support Alert Category Warning - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0520 User Response Complete the following steps until the problem is solved: Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 307 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3.
  • Page 308 The temperature of the I/O expansion adapter in I/O expansion connector 1 has exceeded its specified threshold. May also be shown as 800701012c01ffff or 0x800701012c01ffff Severity Warning Serviceable Automatically notify support Alert Category Warning - Temperature SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 309 CIM Information Prefix: PLAT ID: 0520 User Response Complete the following steps until the problem is solved: 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 310 • 80070101-2c04ffff : Sensor Mezz Exp 4 temp has transitioned from normal to non-critical state. The temperature of the I/O expansion adapter in I/O expansion connector 4 has exceeded its specified threshold. May also be shown as 800701012c04ffff or 0x800701012c04ffff Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 311 Warning Serviceable Automatically notify support Alert Category Warning - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0520 User Response Complete the following steps until the problem is solved: 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues.
  • Page 312 3. Replace the corrupt disk. GPT Status : Sec Rollback Err : Secure Boot Err : • 8007010f-2582ffff : Sensor [SensorElementName] has transitioned from normal to non-critical state. Less than optimal I/O resource configuration. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 313 May also be shown as 8007010f2582ffff or 0x8007010f2582ffff Severity Warning Serviceable Automatically notify support Alert Category Warning - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0520 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 314 Severity Error Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0522 User Response Check the physical drive(s) and replace the bad one(s). Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 315 • 8007020f-2201ffff : Sensor TXT ACM Module has transitioned to critical from a less severe state. TXT ACM Module or Drive Key Fault reports that it is above a normal state. May also be shown as 8007020f2201ffff or 0x8007020f2201ffff Severity Error Serviceable Automatically notify support...
  • Page 316 The I/O expansion adapter in I/O expansion connector 2 has reported a fault. May also be shown as 800702172c02ffff or 0x800702172c02ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0522 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 317 Complete the following steps: 1. Remove any recently installed components. 2. Try to power on the chassis. – If the chassis successfully powers on, complete the following steps: a. Check the ServerProven website to make sure that recently installed components are compatible with the chassis.
  • Page 318 Finding the UEFI diagnostic code • 8007021b-0302ffff : Sensor CPU 2 QPILinkErr has transitioned to critical from a less severe state. CPU 2 QPI Link Failure detected. May also be shown as 8007021b0302ffff or 0x8007021b0302ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 319 Severity Error Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0522 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 320 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the microprocessor 1 heat sink is securely installed. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 321 5. Make sure that the microprocessor 1 heat sink is installed correctly and the thermal material is correctly applied. 6. Replace microprocessor 1. • 80070301-0301ffff : Sensor CPU 1 Overtemp has gone to Nonrecoverable state from a less severe state. The microprocessor 1 temperature has risen above its specified threshold, causing a hard shutdown of the node.
  • Page 322 4. Make sure that the microprocessor 2 heat sink is securely installed. 5. Make sure that the microprocessor 2 heat sink is installed correctly and the thermal material is correctly applied. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 323 6. Replace microprocessor 2. • 80070301-030301ff : Sensor CPU 3 Overtemp has gone to Nonrecoverable state from a less severe state. The temperature of microprocessor 3 has exceeded its specified threshold, causing a hard shutdown of the compute node. May also be shown as 80070301030301ff or 0x80070301030301ff Severity Error Serviceable...
  • Page 324 4. Make sure that the microprocessor 4 heat sink is securely installed. 5. Make sure that the microprocessor 4 heat sink is installed correctly and the thermal material is correctly applied. 6. Replace microprocessor 4. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 325 • 80070301-030402ff : Sensor CPU 4 Overtemp has gone to Nonrecoverable state from a less severe state. The temperature of microprocessor 4 has exceeded its specified threshold, causing a hard shutdown of the compute node. May also be shown as 80070301030402ff or 0x80070301030402ff Severity Error Serviceable...
  • Page 326 The temperature of the I/O expansion adapter in I/O expansion connector 2 has exceeded its specified threshold. The compute node has attempted a soft shutdown. May also be shown as 800703012c02ffff or 0x800703012c02ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 327 Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0524 User Response Complete the following steps until the problem is solved: 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues.
  • Page 328 The compute node has attempted a soft shutdown. May also be shown as 800703012c04ffff or 0x800703012c04ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 329 CIM Information Prefix: PLAT ID: 0524 User Response Complete the following steps until the problem is solved: 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 330 The previously high temperature of the I/O expansion adapter in I/O expansion connector 2 has returned to below its specified threshold. May also be shown as 800704012c02ffff or 0x800704012c02ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 331 CIM Information Prefix: PLAT ID: 0526 User Response Information only; no action is required. • 80070401-2c03ffff : Sensor Mezz Exp 3 temp has transitioned to non-critical from a more severe state. The previously high temperature of the I/O expansion adapter in I/O expansion connector 3 has returned to below its specified threshold.
  • Page 332 The compute node has attempted a soft shutdown. May also be shown as 800706012c02ffff or 0x800706012c02ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0530 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 333 Complete the following steps until the problem is solved: 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 334 • 80070614-2201ffff : Sensor TPM Phy Pres Set has transitioned to non-recoverable. Trusted Platform Module (TPM) initialization error. May also be shown as 800706142201ffff or 0x800706142201ffff Severity Error Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 335 Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0530 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Info Center for the appropriate user response.
  • Page 336 May also be shown as 800706172c03ffff or 0x800706172c03ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0530 User Response Complete the following steps: Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 337 1. Remove the I/O expansion adapter in I/O expansion connector 3. 2. Try to power on the chassis. – If the chassis successfully powers on, complete the following steps: a. Check the ServerProven website to make sure that recently installed components are compatible with the chassis.
  • Page 338 Informational message. On a LOM model compute node, if you are utilizing LOM and it is not working ensure you have the necessary fabric connector installed. – To utilize the LOM: Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 339 – have the LOM model compute node – have the corresponding fabric connector installed – Information regarding the fabric connectors: – LOM 1 utilizes the fabric connector in location 1. – LOM 2 utilizes the fabric connector in location 2. –...
  • Page 340 • 80080128-2101ffff : Device [LogicalDeviceElementName] has been added. The specified device has been installed in the compute node. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 341 May also be shown as 800801282101ffff or 0x800801282101ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0536 User Response Information only; no action is required. • 8009000c-0701ffff : Device Performance Mode has been disabled. The user has switched from Performance mode to Acoustic mode.
  • Page 342 Redundancy has been lost. May also be shown as 800b010c2581ffff or 0x800b010c2581ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0802 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 343 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 344 A Processor has Failed - IERR Condition. May also be shown as 806f00070302ffff or 0x806f00070302ffff Severity Error Serviceable Automatically notify support Alert Category Critical - CPU SNMP Trap ID CIM Information Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 345 Prefix: PLAT ID: 0042 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 346 May also be shown as 806f000d0400ffff or 0x806f000d0400ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0162 User Response Information only; no action is required. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 347 • 806f000d-0401ffff : The Drive Drive 1 has been added. Hard disk drive 1 has been installed. May also be shown as 806f000d0401ffff or 0x806f000d0401ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0162 User Response Information only;...
  • Page 348 Hard disk drive 5 has been installed. May also be shown as 806f000d0405ffff or 0x806f000d0405ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0162 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 349 User Response Information only; no action is required. • 806f000d-0406ffff : The Drive Drive 6 has been added. Hard disk drive 6 has been installed. May also be shown as 806f000d0406ffff or 0x806f000d0406ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information...
  • Page 350 – Finding the UEFI diagnostic code • 806f000f-220102ff : Subsystem [MemoryElementName] has insufficient memory for operation. The usable Memory is insufficient for operation. May also be shown as 806f000f220102ff or 0x806f000f220102ff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 351 Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0132 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 352 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – Finding the UEFI diagnostic code • 806f000f-22010aff : The System [ComputerSystemElementName] encountered firmware error - no video device detected. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 353 A system firmware error No video device detected has occurred. May also be shown as 806f000f22010aff or 0x806f000f22010aff Severity Error Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0766 User Response This is a UEFI detected event.
  • Page 354 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – Finding the UEFI diagnostic code • 806f0013-1701ffff : A diagnostic interrupt has occurred on system [ComputerSystemElementName]. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 355 The user has pressed the NMI button, or the NMI button has malfunctioned. May also be shown as 806f00131701ffff or 0x806f00131701ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0222 User Response If the NMI button on the operator information panel has not been pressed, complete the following steps:...
  • Page 356 Finding the UEFI diagnostic code • 806f0021-25820903 : Fault in slot [PhysicalConnectorSystemElementName] on system [ComputerSystemElementName]. A fault in a slot has been detected, PCIe Error. May also be shown as 806f002125820903 or 0x806f002125820903 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 357 Severity Error Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0330 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 358 • 806f0028-2101ffff : Sensor TPM Cmd Failures is unavailable or degraded on management system [ComputerSystemElementName]. TPM initialization or start up commands have failed. May also be shown as 806f00282101ffff or 0x806f00282101ffff Severity Warning Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 359 Serviceable Automatically notify support Alert Category Warning - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0398 User Response 1. Reboot the system. 2. If error persists, or boot is unsuccessful, (Trained service technician only) Replace the system board.. •...
  • Page 360 The temperature of microprocessor 3 has exceeded the critical level, causing a hard shutdown of the compute node. May also be shown as 806f01070303ffff or 0x806f01070303ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 361 CIM Information Prefix: PLAT ID: 0036 User Response Complete the following steps until the problem is solved: 1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 362 May also be shown as 806f01090701ffff or 0x806f01090701ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0108 User Response Information only; no action is required. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 363 • 806f010c-2001ffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. May also be shown as 806f010c2001ffff or 0x806f010c2001ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response...
  • Page 364 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 365 Related links – Finding the UEFI diagnostic code • 806f010c-2005ffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. May also be shown as 806f010c2005ffff or 0x806f010c2005ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID...
  • Page 366 An uncorrectable memory error has been detected. May also be shown as 806f010c2008ffff or 0x806f010c2008ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 367 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 368 Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. May also be shown as 806f010c200cffff or 0x806f010c200cffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 369 CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 370 • 806f010c-2010ffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. May also be shown as 806f010c2010ffff or 0x806f010c2010ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 371 SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 372 • 806f010c-2014ffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. May also be shown as 806f010c2014ffff or 0x806f010c2014ffff Severity Error Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 373 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 374 Finding the UEFI diagnostic code • 806f010c-2018ffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. May also be shown as 806f010c2018ffff or 0x806f010c2018ffff Severity Error Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 375 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 376 Finding the UEFI diagnostic code • 806f010c-201c01ff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. May also be shown as 806f010c201c01ff or 0x806f010c201c01ff Severity Error Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 377 Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 378 Finding the UEFI diagnostic code • 806f010c-201fffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. May also be shown as 806f010c201fffff or 0x806f010c201fffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 379 Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 380 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – Finding the UEFI diagnostic code • 806f010c-2023ffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 381 An uncorrectable memory error has been detected. May also be shown as 806f010c2023ffff or 0x806f010c2023ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 382 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 383 – Finding the UEFI diagnostic code • 806f010c-2027ffff : Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An uncorrectable memory error has been detected. May also be shown as 806f010c2027ffff or 0x806f010c2027ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information...
  • Page 384 An uncorrectable memory error has been detected. May also be shown as 806f010c2029ffff or 0x806f010c2029ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0138 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 385 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 386 An uncorrectable memory error has been detected. May also be shown as 806f010c202dffff or 0x806f010c202dffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 387 Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 388 A memory uncorrectable error has been detected. All DIMMs. One of the DIMMs. May also be shown as 806f010c2581ffff or 0x806f010c2581ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 389 CIM Information Prefix: PLAT ID: 0138 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 390 The hard disk drive controller has detected a fault in hard disk drive 3. Hard disk drive 3 is now defunct. May also be shown as 806f010d0403ffff or 0x806f010d0403ffff Severity Error Serviceable Automatically notify support Alert Category Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 391 Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0164 User Response Complete the following steps until the problem is solved: 1. Check the Support Portal for service bulletins and RETAIN tips related to your drive. 2.
  • Page 392 The hard disk drive controller has detected a fault in hard disk drive 7. Hard disk drive 7 is now defunct. May also be shown as 806f010d0407ffff or 0x806f010d0407ffff Severity Error Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 393 Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0164 User Response Complete the following steps until the problem is solved: 1. Check the Support Portal for service bulletins and RETAIN tips related to your drive. 2.
  • Page 394 The SAS cable connections between the SAS backplane 1 and the system board are not complete. May also be shown as 806f011b1f03ffff or 0x806f011b1f03ffff Severity Error Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 395 Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0266 User Response 1. Check the connections of the SAS cable between the disk and the backplane 2. (Trained service personnel only). • 806f011b-1f04ffff : The connector [PhysicalConnectorElementName] has encountered a configuration error.
  • Page 396 A Processor has Failed - FRB1/BIST condition. May also be shown as 806f02070302ffff or 0x806f02070302ffff Severity Error Serviceable Automatically notify support Alert Category Critical - CPU SNMP Trap ID CIM Information Prefix: PLAT ID: 0044 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 397 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 398 Failure predicted (PFA) on the hard drive. May also be shown as 806f020d0400ffff or 0x806f020d0400ffff Severity Warning Serviceable Automatically notify support Alert Category System - Predicted Failure SNMP Trap ID CIM Information Prefix: PLAT ID: 0168 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 399 User Response Replace the hard disk drive at the next maintenance period. • 806f020d-0401ffff : Failure Predicted on drive [StorageVolumeElementName] for array [ComputerSystemElementName]. Failure predicted (PFA) on the hard drive. May also be shown as 806f020d0401ffff or 0x806f020d0401ffff Severity Warning Serviceable Automatically notify support Alert Category...
  • Page 400 Replace the hard disk drive at the next maintenance period. • 806f020d-0405ffff : Failure Predicted on drive [StorageVolumeElementName] for array [ComputerSystemElementName]. Failure predicted (PFA) on the hard drive. May also be shown as 806f020d0405ffff or 0x806f020d0405ffff Severity Warning Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 401 Automatically notify support Alert Category System - Predicted Failure SNMP Trap ID CIM Information Prefix: PLAT ID: 0168 User Response Replace the hard disk drive at the next maintenance period. • 806f020d-0406ffff : Failure Predicted on drive [StorageVolumeElementName] for array [ComputerSystemElementName].
  • Page 402 SNMP Trap ID CIM Information Prefix: PLAT ID: 0394 User Response Information only; no action is required. • 806f0225-1f06ffff : LOM2 has been disabled. The LAN On Motherboard (LOM) 2 is disabled. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 403 May also be shown as 806f02251f06ffff or 0x806f02251f06ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0394 User Response Information only; no action is required. • 806f030c-2001ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 404 Finding the UEFI diagnostic code • 806f030c-200401ff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). May also be shown as 806f030c200401ff or 0x806f030c200401ff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 405 Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 406 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – Finding the UEFI diagnostic code • 806f030c-2007ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 407 Memory error discovered during boot..(not a runtime error). May also be shown as 806f030c2007ffff or 0x806f030c2007ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 408 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 409 – Finding the UEFI diagnostic code • 806f030c-200bffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). May also be shown as 806f030c200bffff or 0x806f030c200bffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information...
  • Page 410 Memory error discovered during boot..(not a runtime error). May also be shown as 806f030c200effff or 0x806f030c200effff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 411 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 412 Memory error discovered during boot..(not a runtime error). May also be shown as 806f030c2012ffff or 0x806f030c2012ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 413 Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 414 [MemoryElementName]. Memory error discovered during boot..(not a runtime error). May also be shown as 806f030c2016ffff or 0x806f030c2016ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 415 CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 416 • 806f030c-201affff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). May also be shown as 806f030c201affff or 0x806f030c201affff Severity Error Serviceable Automatically notify support Alert Category Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 417 Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 418 • 806f030c-201effff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). May also be shown as 806f030c201effff or 0x806f030c201effff Severity Error Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 419 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 420 Finding the UEFI diagnostic code • 806f030c-2022ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). May also be shown as 806f030c2022ffff or 0x806f030c2022ffff Severity Error Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 421 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 422 Finding the UEFI diagnostic code • 806f030c-2026ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). May also be shown as 806f030c2026ffff or 0x806f030c2026ffff Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 423 Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 424 Information Center for the appropriate user response. Related links – Finding the UEFI diagnostic code • 806f030c-2029ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 425 May also be shown as 806f030c2029ffff or 0x806f030c2029ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 426 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – Finding the UEFI diagnostic code Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 427 • 806f030c-202dffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). May also be shown as 806f030c202dffff or 0x806f030c202dffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0136 User Response...
  • Page 428 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 429 Related links – Finding the UEFI diagnostic code • 806f030c-2581ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory error discovered during boot..(not a runtime error). May also be shown as 806f030c2581ffff or 0x806f030c2581ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID...
  • Page 430 User Response Information only; no action required. • 806f030d-0403ffff : Hot Spare enabled for [ComputerSystemElementName]. A hot spare is available. May also be shown as 806f030d0403ffff or 0x806f030d0403ffff Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 431 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0170 User Response Information only; no action required. • 806f030d-0404ffff : Hot Spare enabled for [ComputerSystemElementName]. A hot spare is available. May also be shown as 806f030d0404ffff or 0x806f030d0404ffff Severity Info Serviceable...
  • Page 432 • 806f0313-1701ffff : A software NMI has occurred on system [ComputerSystemElementName]. A software NMI has occurred. The compute node might have restarted, depending on the configuration setting. May also be shown as 806f03131701ffff or 0x806f03131701ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 433 Severity Error Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0228 User Response Check the operating-system logs and resolve any issues related the NMI. • 806f0323-2101ffff : Power cycle of system [ComputerSystemElementName] initiated by watchdog IPMI Watchdog.
  • Page 434 Finding the UEFI diagnostic code • 806f040c-2003ffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. May also be shown as 806f040c2003ffff or 0x806f040c2003ffff Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 435 Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 436 Related links – Finding the UEFI diagnostic code • 806f040c-2007ffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. May also be shown as 806f040c2007ffff or 0x806f040c2007ffff Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 437 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 438 Information Center for the appropriate user response. Related links – Finding the UEFI diagnostic code • 806f040c-200bffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. May also be shown as 806f040c200bffff or 0x806f040c200bffff Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 439 Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 440 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – Finding the UEFI diagnostic code • 806f040c-200fffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 441 May also be shown as 806f040c200fffff or 0x806f040c200fffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 442 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – Finding the UEFI diagnostic code Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 443 • 806f040c-2013ffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. May also be shown as 806f040c2013ffff or 0x806f040c2013ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event.
  • Page 444 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 445 Related links – Finding the UEFI diagnostic code • 806f040c-2017ffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. May also be shown as 806f040c2017ffff or 0x806f040c2017ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response...
  • Page 446 Memory has been Disabled. May also be shown as 806f040c201affff or 0x806f040c201affff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 447 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 448 • 806f040c-201effff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. May also be shown as 806f040c201effff or 0x806f040c201effff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 449 CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 450 • 806f040c-2022ffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. May also be shown as 806f040c2022ffff or 0x806f040c2022ffff Severity Info Serviceable Automatically notify support Alert Category System - Other Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 451 SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 452 Finding the UEFI diagnostic code • 806f040c-2026ffff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. May also be shown as 806f040c2026ffff or 0x806f040c2026ffff Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 453 Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 454 Related links – Finding the UEFI diagnostic code • 806f040c-202affff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. May also be shown as 806f040c202affff or 0x806f040c202affff Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 455 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 456 Information Center for the appropriate user response. Related links – Finding the UEFI diagnostic code • 806f040c-202effff : [PhysicalMemoryElementName] Disabled on Subsystem [MemoryElementName]. Memory has been Disabled. May also be shown as 806f040c202effff or 0x806f040c202effff Severity Info Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 457 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0131 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 458 • 806f0413-2582ffff : A PCI PERR has occurred on system [ComputerSystemElementName]. A PCI Parity Error (PERR) occurred on one of these sensors: All PCI Error, One of PCI Error. May also be shown as 806f04132582ffff or 0x806f04132582ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 459 Severity Error Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0232 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 460 Related links – Finding the UEFI diagnostic code • 806f0507-0304ffff : CPU 4 has a Configuration Mismatch. A Processor Configuration Mismatch has occurred. May also be shown as 806f05070304ffff or 0x806f05070304ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 461 Severity Error Serviceable Automatically notify support Alert Category Critical - CPU SNMP Trap ID CIM Information Prefix: PLAT ID: 0062 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 462 Information Center for the appropriate user response. Related links – Finding the UEFI diagnostic code • 806f050c-2003ffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 463 May also be shown as 806f050c2003ffff or 0x806f050c2003ffff Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 464 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – Finding the UEFI diagnostic code Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 465 • 806f050c-2006ffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. May also be shown as 806f050c2006ffff or 0x806f050c2006ffff Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response...
  • Page 466 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 467 Related links – Finding the UEFI diagnostic code • 806f050c-2009ffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. May also be shown as 806f050c2009ffff or 0x806f050c2009ffff Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID...
  • Page 468 The Memory Logging Limit has been Reached. May also be shown as 806f050c200cffff or 0x806f050c200cffff Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 469 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 470 Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. May also be shown as 806f050c2010ffff or 0x806f050c2010ffff Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 471 CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 472 • 806f050c-2014ffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. the Memory Logging Limit has been Reached. May also be shown as 806f050c2014ffff or 0x806f050c2014ffff Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 473 SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 474 • 806f050c-2018ffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. May also be shown as 806f050c2018ffff or 0x806f050c2018ffff Severity Warning Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 475 Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 476 Finding the UEFI diagnostic code • 806f050c-201cffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. May also be shown as 806f050c201cffff or 0x806f050c201cffff Severity Warning Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 477 Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 478 Finding the UEFI diagnostic code • 806f050c-2020ffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. May also be shown as 806f050c2020ffff or 0x806f050c2020ffff Severity Warning Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 479 Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 480 Finding the UEFI diagnostic code • 806f050c-2024ffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. May also be shown as 806f050c2024ffff or 0x806f050c2024ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 481 Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 482 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – Finding the UEFI diagnostic code • 806f050c-2027ffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 483 The Memory Logging Limit has been Reached. May also be shown as 806f050c2027ffff or 0x806f050c2027ffff Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 484 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 485 – Finding the UEFI diagnostic code • 806f050c-202bffff : Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. The Memory Logging Limit has been Reached. May also be shown as 806f050c202bffff or 0x806f050c202bffff Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information...
  • Page 486 The Memory Logging Limit has been Reached. May also be shown as 806f050c202effff or 0x806f050c202effff Severity Warning Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0144 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 487 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 488 The RAID array is in critical condition. Immediate action is required to avoid a system outage. May also be shown as 806f050d0400ffff or 0x806f050d0400ffff Severity Warning Serviceable Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0174 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 489 User Response Replace the hard disk drive that is indicated by a lit status LED. • 806f050d-0401ffff : Array [ComputerSystemElementName] is in critical condition. The RAID array is in critical condition. Immediate action is required to avoid a system outage. May also be shown as 806f050d0401ffff or 0x806f050d0401ffff Severity Error...
  • Page 490 The RAID array is in critical condition. Immediate action is required to avoid a system outage. May also be shown as 806f050d0405ffff or 0x806f050d0405ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Hard Disk drive Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 491 SNMP Trap ID CIM Information Prefix: PLAT ID: 0174 User Response Replace the hard disk drive that is indicated by a lit status LED. • 806f050d-0406ffff : Array [ComputerSystemElementName] is in critical condition. The RAID array is in critical condition. Immediate action is required to avoid a system outage. May also be shown as 806f050d0406ffff or 0x806f050d0406ffff Severity Error...
  • Page 492 • 806f0607-0301ffff : An SM BIOS Uncorrectable CPU complex error for CPU 1 has asserted. An SM BIOS Uncorrectable CPU complex error has asserted. May also be shown as 806f06070301ffff or 0x806f06070301ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 493 Severity Error Serviceable Automatically notify support Alert Category Critical - CPU SNMP Trap ID CIM Information Prefix: PLAT ID: 0816 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 494 • 806f0607-2584ffff : An SM BIOS Uncorrectable CPU complex error for [ProcessorElementName] has asserted. An SM BIOS Uncorrectable CPU complex error has been detected. All CPUs. One of CPUs. May also be shown as 806f06072584ffff or 0x806f06072584ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 495 Severity Error Serviceable Automatically notify support Alert Category Critical - CPU SNMP Trap ID CIM Information Prefix: PLAT ID: 0816 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 496 The Drive 3 is part of an RAID array that is in the failed condition. To identify drives in the failed array all member drives will report this message. May also be shown as 806f060d0403ffff or 0x806f060d0403ffff Severity Error Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 497 Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0176 User Response – Check IMM log for Predictive Fault (PFA) or other hard drive messages to help identify failing drive (s). –...
  • Page 498 The Drive 7 is part of an RAID array that is in the failed condition. To identify drives in the failed array all member drives will report this message. May also be shown as 806f060d0407ffff or 0x806f060d0407ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Hard Disk drive Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 499 SNMP Trap ID CIM Information Prefix: PLAT ID: 0176 User Response – Replace the hard disk drives that are indicated by a lit status LED on the drive. – Recreate the array. – Restore data from backup. • 806f070c-2001ffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 500 • 806f070c-2004ffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. May also be shown as 806f070c2004ffff or 0x806f070c2004ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 501 SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 502 • 806f070c-2008ffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. May also be shown as 806f070c2008ffff or 0x806f070c2008ffff Severity Error Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 503 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 504 Finding the UEFI diagnostic code • 806f070c-200cffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. May also be shown as 806f070c200cffff or 0x806f070c200cffff Severity Error Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 505 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 506 Finding the UEFI diagnostic code • 806f070c-2010ffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. May also be shown as 806f070c2010ffff or 0x806f070c2010ffff Severity Error Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 507 Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 508 Finding the UEFI diagnostic code • 806f070c-2014ffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. May also be shown as 806f070c2014ffff or 0x806f070c2014ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 509 Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 510 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – Finding the UEFI diagnostic code • 806f070c-2018ffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 511 A Memory DIMM configuration error has been detected. May also be shown as 806f070c2018ffff or 0x806f070c2018ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text.
  • Page 512 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 513 – Finding the UEFI diagnostic code • 806f070c-201cffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. May also be shown as 806f070c201cffff or 0x806f070c201cffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information...
  • Page 514 A Memory DIMM configuration error has been detected. May also be shown as 806f070c201fffff or 0x806f070c201fffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 515 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 516 A Memory DIMM configuration error has been detected. May also be shown as 806f070c2023ffff or 0x806f070c2023ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 517 Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 518 [MemoryElementName]. A Memory DIMM configuration error has been detected. May also be shown as 806f070c2027ffff or 0x806f070c2027ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 519 CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 520 • 806f070c-202bffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. May also be shown as 806f070c202bffff or 0x806f070c202bffff Severity Error Serviceable Automatically notify support Alert Category Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 521 Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 522 • 806f070c-202fffff : Configuration Error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory DIMM configuration error has been detected. May also be shown as 806f070c202fffff or 0x806f070c202fffff Severity Error Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 523 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0126 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 524 The array that contains Drive 1 is in the process of being rebuilt. May also be shown as 806f070d0401ffff or 0x806f070d0401ffff Severity Info Serviceable Automatically notify support Alert Category System - Other Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 525 SNMP Trap ID CIM Information Prefix: PLAT ID: 0178 User Response Information only; no action is required. • 806f070d-0402ffff : Rebuild in progress for Array in system [ComputerSystemElementName]. The array that contains Drive 2 is in the process of being rebuilt. May also be shown as 806f070d0402ffff or 0x806f070d0402ffff Severity Info...
  • Page 526 • 806f070d-0406ffff : Rebuild in progress for Array in system [ComputerSystemElementName]. The array that contains Drive 6 is in the process of being rebuilt. May also be shown as 806f070d0406ffff or 0x806f070d0406ffff Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 527 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0178 User Response Information only; no action is required. • 806f070d-0407ffff : Rebuild in progress for Array in system [ComputerSystemElementName]. The array that contains Drive 7 is in the process of being rebuilt. May also be shown as 806f070d0407ffff or 0x806f070d0407ffff Severity Info...
  • Page 528 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – Finding the UEFI diagnostic code Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 529 • 806f0807-0302ffff : CPU 2 has been Disabled. A Processor has been Disabled. May also be shown as 806f08070302ffff or 0x806f08070302ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0061 User Response This is a UEFI detected event.
  • Page 530 IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links – Finding the UEFI diagnostic code Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 531 • 806f0813-2581ffff : A Uncorrectable Bus Error has occurred on system [ComputerSystemElementName]. A catastrophic system error has occurred. The system firmware will attempt to analyze the failure to determine whether the failure was due to a hardware component or a software component. May also be shown as 806f08132581ffff or 0x806f08132581ffff Severity Error...
  • Page 532 Memory has been Throttled. May also be shown as 806f090c2001ffff or 0x806f090c2001ffff Severity Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 533 Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 534 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 535 • 806f090c-2005ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. May also be shown as 806f090c2005ffff or 0x806f090c2005ffff Severity Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1.
  • Page 536 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. • 806f090c-2008ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. May also be shown as 806f090c2008ffff or 0x806f090c2008ffff Severity Warning Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 537 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 538 • 806f090c-200bffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. May also be shown as 806f090c200bffff or 0x806f090c200bffff Severity Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 539 CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 540 System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 541 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5.
  • Page 542 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 543 • 806f090c-2012ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. May also be shown as 806f090c2012ffff or 0x806f090c2012ffff Severity Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1.
  • Page 544 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. • 806f090c-2015ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. May also be shown as 806f090c2015ffff or 0x806f090c2015ffff Severity Warning Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 545 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 546 • 806f090c-2018ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. May also be shown as 806f090c2018ffff or 0x806f090c2018ffff Severity Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 547 CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 548 System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 549 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5.
  • Page 550 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 551 • 806f090c-201fffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. May also be shown as 806f090c201fffff or 0x806f090c201fffff Severity Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1.
  • Page 552 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. • 806f090c-2022ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. May also be shown as 806f090c2022ffff or 0x806f090c2022ffff Severity Warning Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 553 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 554 • 806f090c-2025ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. May also be shown as 806f090c2025ffff or 0x806f090c2025ffff Severity Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 555 CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 556 System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 557 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5.
  • Page 558 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 559 • 806f090c-202cffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. May also be shown as 806f090c202cffff or 0x806f090c202cffff Severity Warning Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1.
  • Page 560 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. • 806f090c-202fffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] Throttled. Memory has been Throttled. May also be shown as 806f090c202fffff or 0x806f090c202fffff Severity Warning Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 561 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0142 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 562 The processor is being throttled due to thermal or power conditions. May also be shown as 806f0a070302ffff or 0x806f0a070302ffff Severity Warning Serviceable Automatically notify support Alert Category Warning - CPU SNMP Trap ID CIM Information Prefix: PLAT ID: 0038 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 563 Complete the following steps: 1. Check the CMM or FSM event log for any fan- or cooling-related issues or power-related issues.. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 564 An over temperature condition for memory has been detected. May also be shown as 806f0a0c2001ffff or 0x806f0a0c2001ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 565 CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 566 Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 567 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5.
  • Page 568 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 569 • 806f0a0c-2008ffff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. May also be shown as 806f0a0c2008ffff or 0x806f0a0c2008ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information...
  • Page 570 • 806f0a0c-200bffff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. May also be shown as 806f0a0c200bffff or 0x806f0a0c200bffff Severity Error Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 571 Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 572 An over temperature condition for memory has been detected. May also be shown as 806f0a0c200effff or 0x806f0a0c200effff Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 573 CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 574 Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 575 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5.
  • Page 576 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 577 • 806f0a0c-2015ffff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. May also be shown as 806f0a0c2015ffff or 0x806f0a0c2015ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information...
  • Page 578 • 806f0a0c-2018ffff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. May also be shown as 806f0a0c2018ffff or 0x806f0a0c2018ffff Severity Error Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 579 Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 580 An over temperature condition for memory has been detected. May also be shown as 806f0a0c201bffff or 0x806f0a0c201bffff Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 581 CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 582 Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 583 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5.
  • Page 584 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 585 • 806f0a0c-2022ffff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. May also be shown as 806f0a0c2022ffff or 0x806f0a0c2022ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information...
  • Page 586 • 806f0a0c-2025ffff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. May also be shown as 806f0a0c2025ffff or 0x806f0a0c2025ffff Severity Error Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 587 Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 588 An over temperature condition for memory has been detected. May also be shown as 806f0a0c2028ffff or 0x806f0a0c2028ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 589 CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed.
  • Page 590 Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0146 User Response Complete the following steps: 1. Check the CMM or FSM event log for any fan or cooling related issues. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 591 2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and correctly installed. 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5.
  • Page 592 3. Make sure that the room temperature is within operating specifications. 4. Make sure that the DIMM baffles are in place. 5. If the problem persists and there are no other DIMMs with the same indication, replace the DIMM. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 593 • 806f0a0c-202fffff : An Over-Temperature Condition has been detected on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. An over temperature condition for memory has been detected. May also be shown as 806f0a0c202fffff or 0x806f0a0c202fffff Severity Error Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information...
  • Page 594 • 806f0a13-2582ffff : A Fatal Bus Error has occurred on bus [SensorElementName]. IMM has detected a Bus Fatal Error relating to PCI. May also be shown as 806f0a132582ffff or 0x806f0a132582ffff Severity Error Serviceable Automatically notify support Alert Category Critical - Other Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 595 SNMP Trap ID CIM Information Prefix: PLAT ID: 0244 User Response This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response.
  • Page 596 The previously high inlet 1 temperature has returned to below its specified threshold. May also be shown as 810107013701ffff or 0x810107013701ffff Severity Info Serviceable Automatically notify support Alert Category Warning - Temperature SNMP Trap ID CIM Information Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 597 Prefix: PLAT ID: 0491 User Response Information only; no action is required. • 81010701-3702ffff : Numeric sensor [NumericSensorElementName] going high (upper non-critical) has deasserted. The previously high inlet 2 temperature has returned to below its specified threshold. May also be shown as 810107013702ffff or 0x810107013702ffff Severity Info Serviceable...
  • Page 598 • 81010b01-3701ffff : Numeric sensor [NumericSensorElementName] going high (upper non- recoverable) has deasserted. The previously high inlet temperature 1 has returned to below its specified threshold. May also be shown as 81010b013701ffff or 0x81010b013701ffff Severity Info Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 599 Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0499 User Response Information only; no action is required. • 81010b01-3702ffff : Numeric sensor [NumericSensorElementName] going high (upper non- recoverable) has deasserted. The previously high inlet temperature 2 has returned to below its specified threshold. May also be shown as 81010b013702ffff or 0x81010b013702ffff Severity Info...
  • Page 600 A sensor has recovered. May also be shown as 8103010e2581ffff or 0x8103010e2581ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0509 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 601 This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information Center for the appropriate user response. Related links –...
  • Page 602 • 81070101-030201ff : Sensor CPU 2 Overtemp has deasserted the transition from normal to non- critical state. The previously high microprocessor 2 temperature has returned to below its specified threshold. May also be shown as 81070101030201ff or 0x81070101030201ff Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 603 Info Serviceable Automatically notify support Alert Category Warning - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0521 User Response Information only; no action is required. • 81070101-030202ff : Sensor CPU 2 Overtemp has deasserted the transition from normal to non- critical state.
  • Page 604 The previously high microprocessor 3 temperature has returned to below its specified threshold. May also be shown as 81070101030302ff or 0x81070101030302ff Severity Info Serviceable Automatically notify support Alert Category Warning - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0521 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 605 Information only; no action is required. • 81070101-0303ffff : Sensor CPU 3 Overtemp has deasserted the transition from normal to non- critical state. The previously high microprocessor 3 temperature has returned to below its specified threshold. May also be shown as 810701010303ffff or 0x810701010303ffff Severity Info Serviceable...
  • Page 606 • 81070101-2c01ffff : Sensor Mezz Exp 1 temp has deasserted the transition from normal to non- critical state. The previously high I/O Exansion card temperature has returned to below its specified threshold. May also be shown as 810701012c01ffff or 0x810701012c01ffff Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 607 Alert Category Warning - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0521 User Response Information only; no action is required. • 81070101-2c02ffff : Sensor Mezz Exp 2 temp has deasserted the transition from normal to non- critical state. The previously high I/O Exansion card temperature has returned to below its specified threshold.
  • Page 608 User Response Information only; no action is required. • 8107010d-0b01ffff : Sensor [SensorElementName] has deasserted the transition from normal to non-critical state. A drive failure causing RAID redundancy has been removed. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 609 May also be shown as 8107010d0b01ffff or 0x8107010d0b01ffff Severity Info Serviceable Automatically notify support Alert Category Warning - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0521 User Response Information only; no action required. • 8107010f-2201ffff : Sensor [SensorElementName] has deasserted the transition from normal to non-critical state.
  • Page 610 A voltage fault is no longer detected with the system board. May also be shown as 810702020701ffff or 0x810702020701ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Voltage SNMP Trap ID CIM Information Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 611 Prefix: PLAT ID: 0523 User Response Information only; no action is required. • 8107020d-0b01ffff : Sensor [SensorElementName] has transitioned to a less severe state from critical. The failed drive(s) causing a RAID redundancy loss has recovered. May also be shown as 8107020d0b01ffff or 0x8107020d0b01ffff Severity Info Serviceable...
  • Page 612 • 81070217-2c02ffff : Sensor Mezz Exp 2 Fault has transitioned to a less severe state from critical. The I/O Expansion card is no longer in a fault condition. May also be shown as 810702172c02ffff or 0x810702172c02ffff Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 613 Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0523 User Response Information only; no action is required. • 81070217-2c03ffff : Sensor Mezz Exp 3 Fault has transitioned to a less severe state from critical. The I/O Expansion card is no longer in a fault condition.
  • Page 614 • 8107021b-0302ffff : Sensor CPU 2 QPILinkErr has transitioned to a less severe state from critical. IMM has detected that CPU 2 has recovered from a QPI Link Error. May also be shown as 8107021b0302ffff or 0x8107021b0302ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 615 Severity Info Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0523 User Response Information only; no action is required. • 8107021b-0303ffff : Sensor CPU 3 QPILinkErr has transitioned to a less severe state from critical. IMM has detected that CPU 3 has recovered from a QPI Link Error.
  • Page 616 May also be shown as 810703010302ffff or 0x810703010302ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0525 User Response Information only; no action is required. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 617 • 81070301-0303ffff : Sensor CPU 3 Overtemp has deasserted the transition to non-recoverable from a less severe state. The previously high microprocessor 3 temperature has returned to below its specified threshold. May also be shown as 810703010303ffff or 0x810703010303ffff Severity Info Serviceable Automatically notify support...
  • Page 618 The previously high I/O Expansion card temperature has returned below its specified threshold. May also be shown as 810703012c03ffff or 0x810703012c03ffff Severity Info Serviceable Automatically notify support Alert Category Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 619 Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0525 User Response Information only; no action is required. • 81070301-2c04ffff : Sensor Mezz Exp 4 temp has deasserted the transition to non-recoverable from a less severe state. The previously high I/O Expansion card temperature has returned below its specified threshold. May also be shown as 810703012c04ffff or 0x810703012c04ffff Severity Info...
  • Page 620 • 81070601-2c02ffff : Sensor Mezz Exp 2 temp has deasserted the transition to non-recoverable. The previously high I/O Expansion card temperature has returned below its specified threshold. May also be shown as 810706012c02ffff or 0x810706012c02ffff Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 621 Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0531 User Response Information only; no action is required. • 81070601-2c03ffff : Sensor Mezz Exp 3 temp has deasserted the transition to non-recoverable. The previously high I/O Expansion card temperature has returned below its specified threshold.
  • Page 622 SNMP Trap ID CIM Information Prefix: PLAT ID: 0531 User Response Information only; no action is required. • 81070617-2c02ffff : Sensor Mezz Exp 2 Fault has deasserted the transition to non-recoverable. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 623 The I/O expansion adapter in I/O expansion connector 2 no longer reports a non-recoverable condition. May also be shown as 810706172c02ffff or 0x810706172c02ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0531 User Response Information only;...
  • Page 624 Redundancy has been recovered. May also be shown as 810b010c2581ffff or 0x810b010c2581ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0803 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 625 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 810b030c-2581ffff : Non-redundant:Sufficient Resources from Redundancy Degraded or Fully Redundant for [RedundancySetElementName] has deasserted. Memory component group has regained its redundancy. May also be shown as 810b030c2581ffff or 0x810b030c2581ffff Severity Info Serviceable...
  • Page 626 SNMP Trap ID CIM Information Prefix: PLAT ID: 0043 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f0007-0303ffff : [ProcessorElementName] has Recovered from IERR. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 627 A Processor has Recovered - IERR Condition. May also be shown as 816f00070303ffff or 0x816f00070303ffff Severity Info Serviceable Automatically notify support Alert Category Critical - CPU SNMP Trap ID CIM Information Prefix: PLAT ID: 0043 User Response Information only; no action is required. Related links –...
  • Page 628 Presence of drive 1 is no longer detected. If hard drive is absent from drive bay a filler is required. May also be shown as 816f000d0401ffff or 0x816f000d0401ffff Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 629 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0163 User Response – If drive was intentionally removed, no action required. – Make sure that the drive properly seated. – If drive is properly seated, replace the drive. •...
  • Page 630 Presence of drive 5 is no longer detected. If hard drive is absent from drive bay a filler is required. May also be shown as 816f000d0405ffff or 0x816f000d0405ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 631 CIM Information Prefix: PLAT ID: 0163 User Response – If drive was intentionally removed, no action required. – Make sure that the drive properly seated. – If drive is properly seated, replace the drive. • 816f000d-0406ffff : The Drive [StorageVolumeElementName] has been removed from unit [PhysicalPackageElementName].
  • Page 632 May also be shown as 816f00131701ffff or 0x816f00131701ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0223 User Response Information only; no action is required. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 633 • 816f0021-2201ffff : Fault condition removed on slot [PhysicalConnectorElementName] on system [ComputerSystemElementName]. A fault in a slot has been removed. No Op ROM Space. May also be shown as 816f00212201ffff or 0x816f00212201ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information...
  • Page 634 • 816f0107-0302ffff : An Over-Temperature Condition has been removed on [ProcessorElementName]. The microprocessor 2 temperature has returned to below the critical level. May also be shown as 816f01070302ffff or 0x816f01070302ffff Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 635 Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0037 User Response Information only; no action is required. • 816f0107-0303ffff : An Over-Temperature Condition has been removed on [ProcessorElementName]. The microprocessor 3 temperature has returned to below the critical level. May also be shown as 816f01070303ffff or 0x816f01070303ffff Severity Info...
  • Page 636 A Memory uncorrectable error has recovered. May also be shown as 816f010c2001ffff or 0x816f010c2001ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 637 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f010c-2002ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory uncorrectable error has recovered. May also be shown as 816f010c2002ffff or 0x816f010c2002ffff Severity Info Serviceable...
  • Page 638 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 639 • 816f010c-2006ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory uncorrectable error has recovered. May also be shown as 816f010c2006ffff or 0x816f010c2006ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response...
  • Page 640 Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f010c-200affff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory uncorrectable error has recovered. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 641 May also be shown as 816f010c200affff or 0x816f010c200affff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code •...
  • Page 642 Finding the UEFI diagnostic code • 816f010c-200effff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory uncorrectable error has recovered. May also be shown as 816f010c200effff or 0x816f010c200effff Severity Info Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 643 Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f010c-200fffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 644 • 816f010c-2012ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory uncorrectable error has recovered. May also be shown as 816f010c2012ffff or 0x816f010c2012ffff Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 645 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f010c-2013ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 646 • 816f010c-2016ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory uncorrectable error has recovered. May also be shown as 816f010c2016ffff or 0x816f010c2016ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 647 CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f010c-2017ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory uncorrectable error has recovered. May also be shown as 816f010c2017ffff or 0x816f010c2017ffff Severity Info...
  • Page 648 May also be shown as 816f010c201affff or 0x816f010c201affff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 649 Related links – Finding the UEFI diagnostic code • 816f010c-201bffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory uncorrectable error has recovered. May also be shown as 816f010c201bffff or 0x816f010c201bffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID...
  • Page 650 Prefix: PLAT ID: 0139 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f010c-201fffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 651 A Memory uncorrectable error has recovered. May also be shown as 816f010c201fffff or 0x816f010c201fffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. Related links –...
  • Page 652 Finding the UEFI diagnostic code • 816f010c-2023ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory uncorrectable error has recovered. May also be shown as 816f010c2023ffff or 0x816f010c2023ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 653 Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f010c-2024ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 654 Finding the UEFI diagnostic code • 816f010c-2027ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory uncorrectable error has recovered. May also be shown as 816f010c2027ffff or 0x816f010c2027ffff Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 655 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f010c-2028ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 656 • 816f010c-202bffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory uncorrectable error has recovered. May also be shown as 816f010c202bffff or 0x816f010c202bffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 657 SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f010c-202cffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory uncorrectable error has recovered. May also be shown as 816f010c202cffff or 0x816f010c202cffff Severity Info...
  • Page 658 A Memory uncorrectable error has recovered. May also be shown as 816f010c202fffff or 0x816f010c202fffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0139 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 659 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f010c-2030ffff : Uncorrectable error recovery detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. A Memory uncorrectable error has recovered. May also be shown as 816f010c2030ffff or 0x816f010c2030ffff Severity Info Serviceable...
  • Page 660 Information only; no action is required. • 816f010d-0402ffff : The Drive [StorageVolumeElementName] has been enabled. The previously disabled drive 2 has been enabled. May also be shown as 816f010d0402ffff or 0x816f010d0402ffff Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 661 Info Serviceable Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0167 User Response Information only; no action is required. • 816f010d-0403ffff : The Drive [StorageVolumeElementName] has been enabled. The previously disabled drive 3 has been enabled. May also be shown as 816f010d0403ffff or 0x816f010d0403ffff Severity Info...
  • Page 662 Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0167 User Response Information only; no action is required. • 816f010d-0407ffff : The Drive [StorageVolumeElementName] has been enabled. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 663 The previously disabled drive 7 has been enabled. May also be shown as 816f010d0407ffff or 0x816f010d0407ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0167 User Response Information only;...
  • Page 664 Finding the UEFI diagnostic code • 816f0207-0303ffff : [ProcessorElementName] has Recovered from FRB1/BIST condition. A Processor has Recovered - FRB1/BIST condition. May also be shown as 816f02070303ffff or 0x816f02070303ffff Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 665 Alert Category Critical - CPU SNMP Trap ID CIM Information Prefix: PLAT ID: 0045 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f0207-0304ffff : [ProcessorElementName] has Recovered from FRB1/BIST condition. A Processor has Recovered - FRB1/BIST condition. May also be shown as 816f02070304ffff or 0x816f02070304ffff Severity Info...
  • Page 666 May also be shown as 816f020d0401ffff or 0x816f020d0401ffff Severity Info Serviceable Automatically notify support Alert Category System - Predicted Failure SNMP Trap ID CIM Information Prefix: PLAT ID: 0169 User Response Information only; no action is required. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 667 • 816f020d-0402ffff : Failure no longer Predicted on drive [StorageVolumeElementName] for array [ComputerSystemElementName]. The predicted failure for Drive 2 no longer exists. May also be shown as 816f020d0402ffff or 0x816f020d0402ffff Severity Info Serviceable Automatically notify support Alert Category System - Predicted Failure SNMP Trap ID CIM Information Prefix: PLAT ID: 0169...
  • Page 668 • 816f020d-0406ffff : Failure no longer Predicted on drive [StorageVolumeElementName] for array [ComputerSystemElementName]. The predicted failure for Drive 6 no longer exists. May also be shown as 816f020d0406ffff or 0x816f020d0406ffff Severity Info Serviceable Automatically notify support Alert Category Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 669 System - Predicted Failure SNMP Trap ID CIM Information Prefix: PLAT ID: 0169 User Response Information only; no action is required. • 816f020d-0407ffff : Failure no longer Predicted on drive [StorageVolumeElementName] for array [ComputerSystemElementName]. The predicted failure for Drive 7 no longer exists. May also be shown as 816f020d0407ffff or 0x816f020d0407ffff Severity Info...
  • Page 670 • 816f030c-2002ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c2002ffff or 0x816f030c2002ffff Severity Info Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 671 Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. • 816f030c-2003ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c2003ffff or 0x816f030c2003ffff Severity Info...
  • Page 672 May also be shown as 816f030c2006ffff or 0x816f030c2006ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 673 • 816f030c-2007ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c2007ffff or 0x816f030c2007ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137...
  • Page 674 • 816f030c-200bffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c200bffff or 0x816f030c200bffff Severity Info Serviceable Automatically notify support Alert Category Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 675 Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. • 816f030c-200cffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c200cffff or 0x816f030c200cffff Severity Info...
  • Page 676 Information only; no action is required. • 816f030c-2010ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c2010ffff or 0x816f030c2010ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 677 Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. • 816f030c-2011ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered.
  • Page 678 A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c2014ffff or 0x816f030c2014ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 679 User Response Information only; no action is required. • 816f030c-2015ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c2015ffff or 0x816f030c2015ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory...
  • Page 680 • 816f030c-2019ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c2019ffff or 0x816f030c2019ffff Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 681 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. • 816f030c-201affff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c201affff or 0x816f030c201affff Severity Info...
  • Page 682 Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. • 816f030c-201effff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 683 A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c201effff or 0x816f030c201effff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. •...
  • Page 684 A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c2022ffff or 0x816f030c2022ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 685 CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. • 816f030c-2023ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c2023ffff or 0x816f030c2023ffff Severity Info Serviceable...
  • Page 686 Information only; no action is required. • 816f030c-2027ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c2027ffff or 0x816f030c2027ffff Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 687 Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. • 816f030c-2028ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c2028ffff or 0x816f030c2028ffff Severity Info...
  • Page 688 A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c202bffff or 0x816f030c202bffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 689 Information only; no action is required. • 816f030c-202cffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c202cffff or 0x816f030c202cffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID...
  • Page 690 • 816f030c-2030ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered. May also be shown as 816f030c2030ffff or 0x816f030c2030ffff Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 691 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0137 User Response Information only; no action is required. • 816f030c-2581ffff : Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName] has recovered. A Memory Scrub failure detected during boot has recovered on All DIMMs or One of the DIMMs. May also be shown as 816f030c2581ffff or 0x816f030c2581ffff Severity Info...
  • Page 692 User Response Information only; no action required. • 816f030d-0403ffff : Hot spare disabled for [ComputerSystemElementName]. A hot spare is not available. May also be shown as 816f030d0403ffff or 0x816f030d0403ffff Severity Info Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 693 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0171 User Response Information only; no action required. • 816f030d-0404ffff : Hot spare disabled for [ComputerSystemElementName]. A hot spare is not available. May also be shown as 816f030d0404ffff or 0x816f030d0404ffff Severity Info Serviceable...
  • Page 694 Prefix: PLAT ID: 0171 User Response Information only; no action required. • 816f0313-1701ffff : System [ComputerSystemElementName] has recovered from an NMI. A Software NMI has Recovered. May also be shown as 816f03131701ffff or 0x816f03131701ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 695 Severity Info Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0230 User Response Information only; no action is required. • 816f040c-2001ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. May also be shown as 816f040c2001ffff or 0x816f040c2001ffff Severity Info...
  • Page 696 Finding the UEFI diagnostic code • 816f040c-2004ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. May also be shown as 816f040c2004ffff or 0x816f040c2004ffff Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 697 Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f040c-2005ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. May also be shown as 816f040c2005ffff or 0x816f040c2005ffff Severity Info...
  • Page 698 • 816f040c-2008ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. May also be shown as 816f040c2008ffff or 0x816f040c2008ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 699 CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f040c-2009ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. May also be shown as 816f040c2009ffff or 0x816f040c2009ffff Severity Info Serviceable...
  • Page 700 May also be shown as 816f040c200cffff or 0x816f040c200cffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 701 Related links – Finding the UEFI diagnostic code • 816f040c-200dffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. May also be shown as 816f040c200dffff or 0x816f040c200dffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response...
  • Page 702 SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f040c-2011ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 703 Memory has been enabled. May also be shown as 816f040c2011ffff or 0x816f040c2011ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. Related links –...
  • Page 704 Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f040c-2015ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. May also be shown as 816f040c2015ffff or 0x816f040c2015ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 705 Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f040c-2016ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName].
  • Page 706 Related links – Finding the UEFI diagnostic code • 816f040c-2019ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. May also be shown as 816f040c2019ffff or 0x816f040c2019ffff Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 707 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f040c-201affff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName].
  • Page 708 • 816f040c-201dffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. May also be shown as 816f040c201dffff or 0x816f040c201dffff Severity Info Serviceable Automatically notify support Alert Category System - Other Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 709 SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f040c-201effff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. May also be shown as 816f040c201effff or 0x816f040c201effff Severity Info Serviceable...
  • Page 710 Memory has been enabled. May also be shown as 816f040c2021ffff or 0x816f040c2021ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 711 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f040c-2022ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. May also be shown as 816f040c2022ffff or 0x816f040c2022ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID...
  • Page 712 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 713 • 816f040c-2026ffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. May also be shown as 816f040c2026ffff or 0x816f040c2026ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only;...
  • Page 714 Prefix: PLAT ID: 0130 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f040c-202affff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 715 May also be shown as 816f040c202affff or 0x816f040c202affff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code •...
  • Page 716 Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f040c-202effff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName]. Memory has been enabled. May also be shown as 816f040c202effff or 0x816f040c202effff Severity Info Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 717 Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0130 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f040c-202fffff : [PhysicalMemoryElementName] Enabled on Subsystem [MemoryElementName].
  • Page 718 • 816f0413-2582ffff : A PCI PERR recovery has occurred on system [ComputerSystemElementName]. A PCI Parity Error (PERR) has recovered. All PCI Error. One of PCI Error. May also be shown as 816f04132582ffff or 0x816f04132582ffff Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 719 Alert Category Critical - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0233 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f0507-0301ffff : [ProcessorElementName] has Recovered from a Configuration Mismatch. A Processor Configuration Mismatch has recovered.
  • Page 720 May also be shown as 816f05070304ffff or 0x816f05070304ffff Severity Info Serviceable Automatically notify support Alert Category Critical - CPU SNMP Trap ID CIM Information Prefix: PLAT ID: 0063 User Response Information only; no action is required. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 721 Related links – Finding the UEFI diagnostic code • 816f0507-2584ffff : [ProcessorElementName] has Recovered from a Configuration Mismatch. A processor configuration mismatch has recovered. All CPUs. One of CPUs. May also be shown as 816f05072584ffff or 0x816f05072584ffff Severity Info Serviceable Automatically notify support Alert Category Critical - CPU...
  • Page 722 Prefix: PLAT ID: 0145 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f050c-2004ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 723 the memory logging limit has been removed. May also be shown as 816f050c2004ffff or 0x816f050c2004ffff Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. Related links –...
  • Page 724 Finding the UEFI diagnostic code • 816f050c-2008ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. the memory logging limit has been removed. May also be shown as 816f050c2008ffff or 0x816f050c2008ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 725 Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f050c-2009ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 726 Finding the UEFI diagnostic code • 816f050c-200cffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. the memory logging limit has been removed. May also be shown as 816f050c200cffff or 0x816f050c200cffff Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 727 Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f050c-200dffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 728 • 816f050c-2010ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. the memory logging limit has been removed. May also be shown as 816f050c2010ffff or 0x816f050c2010ffff Severity Info Serviceable Automatically notify support Alert Category Warning - Memory Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 729 SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f050c-2011ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. the memory logging limit has been removed. May also be shown as 816f050c2011ffff or 0x816f050c2011ffff Severity Info...
  • Page 730 May also be shown as 816f050c2014ffff or 0x816f050c2014ffff Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 731 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f050c-2015ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. the memory logging limit has been removed. May also be shown as 816f050c2015ffff or 0x816f050c2015ffff Severity Info Serviceable...
  • Page 732 Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 733 • 816f050c-2019ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. the memory logging limit has been removed. May also be shown as 816f050c2019ffff or 0x816f050c2019ffff Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response...
  • Page 734 Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f050c-201dffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. the memory logging limit has been removed. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 735 May also be shown as 816f050c201dffff or 0x816f050c201dffff Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code •...
  • Page 736 Finding the UEFI diagnostic code • 816f050c-2021ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. the memory logging limit has been removed. May also be shown as 816f050c2021ffff or 0x816f050c2021ffff Severity Info Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 737 Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f050c-2022ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 738 • 816f050c-2025ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. the memory logging limit has been removed. May also be shown as 816f050c2025ffff or 0x816f050c2025ffff Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 739 Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f050c-2026ffff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 740 Subsystem [MemoryElementName]. the memory logging limit has been removed. May also be shown as 816f050c2029ffff or 0x816f050c2029ffff Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 741 CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f050c-202affff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. the memory logging limit has been removed. May also be shown as 816f050c202affff or 0x816f050c202affff Severity Info...
  • Page 742 May also be shown as 816f050c202dffff or 0x816f050c202dffff Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 743 Related links – Finding the UEFI diagnostic code • 816f050c-202effff : Memory Logging Limit Removed for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. the memory logging limit has been removed. May also be shown as 816f050c202effff or 0x816f050c202effff Severity Info Serviceable Automatically notify support Alert Category Warning - Memory SNMP Trap ID...
  • Page 744 SNMP Trap ID CIM Information Prefix: PLAT ID: 0145 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f050d-0400ffff : Critical Array [ComputerSystemElementName] has deasserted. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 745 The RAID array is no longer in a critical condition. May also be shown as 816f050d0400ffff or 0x816f050d0400ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0175 User Response Information only;...
  • Page 746 The RAID array is no longer in a critical condition. May also be shown as 816f050d0404ffff or 0x816f050d0404ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0175 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 747 User Response Information only; no action is required. • 816f050d-0405ffff : Critical Array [ComputerSystemElementName] has deasserted. The RAID array is no longer in a critical condition. May also be shown as 816f050d0405ffff or 0x816f050d0405ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID...
  • Page 748 • 816f0607-0301ffff : An SM BIOS Uncorrectable CPU complex error for [ProcessorElementName] has deasserted. An SM BIOS uncorrectable CPU complex error has recovered. May also be shown as 816f06070301ffff or 0x816f06070301ffff Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 749 Alert Category Critical - CPU SNMP Trap ID CIM Information Prefix: PLAT ID: 0817 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f0607-0302ffff : An SM BIOS Uncorrectable CPU complex error for [ProcessorElementName] has deasserted.
  • Page 750 CPU complex error has deasserted. All CPUs. One of CPUs. May also be shown as 816f06072584ffff or 0x816f06072584ffff Severity Info Serviceable Automatically notify support Alert Category Critical - CPU SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 751 CIM Information Prefix: PLAT ID: 0817 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f060d-0400ffff : Array in system [ComputerSystemElementName] has been restored. The failed RAID array has been restored. May also be shown as 816f060d0400ffff or 0x816f060d0400ffff Severity Info Serviceable...
  • Page 752 Information only; no action is required. • 816f060d-0404ffff : Array in system [ComputerSystemElementName] has been restored. The failed RAID array has been restored. May also be shown as 816f060d0404ffff or 0x816f060d0404ffff Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 753 Automatically notify support Alert Category Critical - Hard Disk drive SNMP Trap ID CIM Information Prefix: PLAT ID: 0177 User Response Information only; no action is required. • 816f060d-0405ffff : Array in system [ComputerSystemElementName] has been restored. The failed RAID array has been restored. May also be shown as 816f060d0405ffff or 0x816f060d0405ffff Severity Info...
  • Page 754 Prefix: PLAT ID: 0127 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f070c-2002ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 755 A memory DIMM configuration error has recovered. May also be shown as 816f070c2002ffff or 0x816f070c2002ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. Related links –...
  • Page 756 Finding the UEFI diagnostic code • 816f070c-2006ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. May also be shown as 816f070c2006ffff or 0x816f070c2006ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 757 Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f070c-2007ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted.
  • Page 758 Finding the UEFI diagnostic code • 816f070c-200affff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. May also be shown as 816f070c200affff or 0x816f070c200affff Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 759 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f070c-200bffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted.
  • Page 760 • 816f070c-200effff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. May also be shown as 816f070c200effff or 0x816f070c200effff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 761 SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f070c-200fffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. May also be shown as 816f070c200fffff or 0x816f070c200fffff Severity Info...
  • Page 762 A memory DIMM configuration error has recovered. May also be shown as 816f070c2012ffff or 0x816f070c2012ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 763 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f070c-2013ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. May also be shown as 816f070c2013ffff or 0x816f070c2013ffff Severity Info Serviceable...
  • Page 764 Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 765 • 816f070c-2017ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. May also be shown as 816f070c2017ffff or 0x816f070c2017ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response...
  • Page 766 Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f070c-201bffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 767 May also be shown as 816f070c201bffff or 0x816f070c201bffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code •...
  • Page 768 Finding the UEFI diagnostic code • 816f070c-201fffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. May also be shown as 816f070c201fffff or 0x816f070c201fffff Severity Info Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 769 Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f070c-2020ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted.
  • Page 770 • 816f070c-2023ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. May also be shown as 816f070c2023ffff or 0x816f070c2023ffff Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 771 Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f070c-2024ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered.
  • Page 772 [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. May also be shown as 816f070c2027ffff or 0x816f070c2027ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 773 CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f070c-2028ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. May also be shown as 816f070c2028ffff or 0x816f070c2028ffff Severity Info...
  • Page 774 May also be shown as 816f070c202bffff or 0x816f070c202bffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 775 Related links – Finding the UEFI diagnostic code • 816f070c-202cffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. A memory DIMM configuration error has recovered. May also be shown as 816f070c202cffff or 0x816f070c202cffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID...
  • Page 776 Prefix: PLAT ID: 0127 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f070c-2030ffff : Configuration error for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]has deasserted. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 777 A memory DIMM configuration error has recovered. May also be shown as 816f070c2030ffff or 0x816f070c2030ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Memory SNMP Trap ID CIM Information Prefix: PLAT ID: 0127 User Response Information only; no action is required. Related links –...
  • Page 778 • 816f070d-0402ffff : Rebuild completed for Array in system [ComputerSystemElementName]. The rebuild of the RAID array has completed. May also be shown as 816f070d0402ffff or 0x816f070d0402ffff Severity Info Serviceable Automatically notify support Alert Category System - Other Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 779 SNMP Trap ID CIM Information Prefix: PLAT ID: 0179 User Response Information only; no action is required. • 816f070d-0403ffff : Rebuild completed for Array in system [ComputerSystemElementName]. The rebuild of the RAID array has completed. May also be shown as 816f070d0403ffff or 0x816f070d0403ffff Severity Info Serviceable...
  • Page 780 Information only; no action is required. • 816f070d-0407ffff : Rebuild completed for Array in system [ComputerSystemElementName]. The rebuild of the RAID array has completed. May also be shown as 816f070d0407ffff or 0x816f070d0407ffff Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 781 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0179 User Response Information only; no action is required. • 816f0807-0301ffff : [ProcessorElementName] has been Enabled. A Processor has been Enabled. May also be shown as 816f08070301ffff or 0x816f08070301ffff Severity Info Serviceable...
  • Page 782 May also be shown as 816f08070304ffff or 0x816f08070304ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0060 User Response Information only; no action is required. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 783 Related links – Finding the UEFI diagnostic code • 816f0807-2584ffff : [ProcessorElementName] has been Enabled. A processor has been enabled. All CPUs. One of CPUs. May also be shown as 816f08072584ffff or 0x816f08072584ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information...
  • Page 784 Information only; no action is required. • 816f090c-2002ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM throttling has been turned off. May also be shown as 816f090c2002ffff or 0x816f090c2002ffff Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 785 Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. • 816f090c-2003ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM throttling has been turned off. May also be shown as 816f090c2003ffff or 0x816f090c2003ffff Severity Info...
  • Page 786 Memory DIMM throttling has been turned off. May also be shown as 816f090c2006ffff or 0x816f090c2006ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 787 Information only; no action is required. • 816f090c-2007ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM throttling has been turned off. May also be shown as 816f090c2007ffff or 0x816f090c2007ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information...
  • Page 788 • 816f090c-200bffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM throttling has been turned off. May also be shown as 816f090c200bffff or 0x816f090c200bffff Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 789 Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. • 816f090c-200cffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM throttling has been turned off. May also be shown as 816f090c200cffff or 0x816f090c200cffff Severity Info...
  • Page 790 CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. • 816f090c-2010ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM throttling has been turned off. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 791 May also be shown as 816f090c2010ffff or 0x816f090c2010ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. • 816f090c-2011ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled.
  • Page 792 Throttled. Memory DIMM throttling has been turned off. May also be shown as 816f090c2014ffff or 0x816f090c2014ffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 793 CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. • 816f090c-2015ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM throttling has been turned off. May also be shown as 816f090c2015ffff or 0x816f090c2015ffff Severity Info Serviceable...
  • Page 794 Information only; no action is required. • 816f090c-2019ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM throttling has been turned off. May also be shown as 816f090c2019ffff or 0x816f090c2019ffff Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 795 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. • 816f090c-201affff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM throttling has been turned off. May also be shown as 816f090c201affff or 0x816f090c201affff Severity Info...
  • Page 796 May also be shown as 816f090c201dffff or 0x816f090c201dffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 797 • 816f090c-201effff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM throttling has been turned off. May also be shown as 816f090c201effff or 0x816f090c201effff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response...
  • Page 798 • 816f090c-2022ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM throttling has been turned off. May also be shown as 816f090c2022ffff or 0x816f090c2022ffff Severity Info Serviceable Automatically notify support Alert Category Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 799 System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. • 816f090c-2023ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM throttling has been turned off. May also be shown as 816f090c2023ffff or 0x816f090c2023ffff Severity Info Serviceable...
  • Page 800 Information only; no action is required. • 816f090c-2027ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM throttling has been turned off. May also be shown as 816f090c2027ffff or 0x816f090c2027ffff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 801 Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. • 816f090c-2028ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM throttling has been turned off. May also be shown as 816f090c2028ffff or 0x816f090c2028ffff Severity Info...
  • Page 802 Memory DIMM throttling has been turned off. May also be shown as 816f090c202bffff or 0x816f090c202bffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 803 User Response Information only; no action is required. • 816f090c-202cffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM throttling has been turned off. May also be shown as 816f090c202cffff or 0x816f090c202cffff Severity Info Serviceable Automatically notify support Alert Category System - Other SNMP Trap ID...
  • Page 804 Information only; no action is required. • 816f090c-2030ffff : [PhysicalMemoryElementName] on Subsystem [MemoryElementName] is no longer Throttled. Memory DIMM throttling has been turned off. May also be shown as 816f090c2030ffff or 0x816f090c2030ffff Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 805 Automatically notify support Alert Category System - Other SNMP Trap ID CIM Information Prefix: PLAT ID: 0143 User Response Information only; no action is required. • 816f0a07-0301ffff : The Processor [ProcessorElementName] is no longer operating in a Degraded State. The microprocessor 1 is no longer being throttled. (or ... has been turned off.) May also be shown as 816f0a070301ffff or 0x816f0a070301ffff Severity Info...
  • Page 806 SNMP Trap ID CIM Information Prefix: PLAT ID: 0039 User Response Information only; no action is required. • 816f0a07-2584ffff : The Processor [ProcessorElementName] is no longer operating in a Degraded State. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 807 The microprocessor is no longer being throttled. (or ... has been turned off.) All CPUs. One of CPUs. May also be shown as 816f0a072584ffff or 0x816f0a072584ffff Severity Info Serviceable Automatically notify support Alert Category Warning - CPU SNMP Trap ID CIM Information Prefix: PLAT ID: 0039 User Response...
  • Page 808 Memory DIMM is no longer in an over-temperature condition. May also be shown as 816f0a0c2004ffff or 0x816f0a0c2004ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 809 CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. • 816f0a0c-2005ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM is no longer in an over-temperature condition. May also be shown as 816f0a0c2005ffff or 0x816f0a0c2005ffff Severity Info Serviceable...
  • Page 810 • 816f0a0c-2009ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM is no longer in an over-temperature condition. May also be shown as 816f0a0c2009ffff or 0x816f0a0c2009ffff Severity Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 811 Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. • 816f0a0c-200affff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM is no longer in an over-temperature condition.
  • Page 812 Memory DIMM is no longer in an over-temperature condition. May also be shown as 816f0a0c200dffff or 0x816f0a0c200dffff Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 813 Information only; no action is required. • 816f0a0c-200effff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM is no longer in an over-temperature condition. May also be shown as 816f0a0c200effff or 0x816f0a0c200effff Severity Info Serviceable Automatically notify support Alert Category...
  • Page 814 • 816f0a0c-2012ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM is no longer in an over-temperature condition. May also be shown as 816f0a0c2012ffff or 0x816f0a0c2012ffff Severity Info Serviceable Automatically notify support Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 815 Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. • 816f0a0c-2013ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM is no longer in an over-temperature condition. May also be shown as 816f0a0c2013ffff or 0x816f0a0c2013ffff Severity Info...
  • Page 816 User Response Information only; no action is required. • 816f0a0c-2017ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM is no longer in an over-temperature condition. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 817 May also be shown as 816f0a0c2017ffff or 0x816f0a0c2017ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. • 816f0a0c-2018ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 818 Memory DIMM is no longer in an over-temperature condition. May also be shown as 816f0a0c201bffff or 0x816f0a0c201bffff Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 819 CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. • 816f0a0c-201cffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM is no longer in an over-temperature condition. May also be shown as 816f0a0c201cffff or 0x816f0a0c201cffff Severity Info Serviceable...
  • Page 820 • 816f0a0c-2020ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM is no longer in an over-temperature condition. May also be shown as 816f0a0c2020ffff or 0x816f0a0c2020ffff Severity Info Serviceable Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 821 Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. • 816f0a0c-2021ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM is no longer in an over-temperature condition.
  • Page 822 May also be shown as 816f0a0c2024ffff or 0x816f0a0c2024ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 823 • 816f0a0c-2025ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM is no longer in an over-temperature condition. May also be shown as 816f0a0c2025ffff or 0x816f0a0c2025ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information...
  • Page 824 • 816f0a0c-2029ffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM is no longer in an over-temperature condition. May also be shown as 816f0a0c2029ffff or 0x816f0a0c2029ffff Severity Info Serviceable Automatically notify support Alert Category Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 825 Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. • 816f0a0c-202affff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM is no longer in an over-temperature condition. May also be shown as 816f0a0c202affff or 0x816f0a0c202affff Severity Info...
  • Page 826 • 816f0a0c-202effff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM is no longer in an over-temperature condition. May also be shown as 816f0a0c202effff or 0x816f0a0c202effff Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 827 Severity Info Serviceable Automatically notify support Alert Category Critical - Temperature SNMP Trap ID CIM Information Prefix: PLAT ID: 0147 User Response Information only; no action is required. • 816f0a0c-202fffff : An Over-Temperature Condition has been removed on the [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Memory DIMM is no longer in an over-temperature condition.
  • Page 828 IMM has detected that the system has recovered from a fatal bus error. (All PCI Error or One of PCI Error or PCIs) May also be shown as 816f0a132582ffff or 0x816f0a132582ffff Severity Info Serviceable Automatically notify support Alert Category Critical - Other SNMP Trap ID CIM Information Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 829 Prefix: PLAT ID: 0245 User Response Information only; no action is required. Related links – Finding the UEFI diagnostic code • 816f0b13-0701ffff : Bus [SensorElementName] is no longer operating in a degraded state. IMM has detected the DMI Bus is No Longer Degraded. May also be shown as 816f0b130701ffff or 0x816f0b130701ffff Severity Info...
  • Page 830 [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-2009ffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-200affff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-200bffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 831 Table 9. Events that automatically notify Support (continued) Automatically Message String Notify Support Event ID 806f010c-200cffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-200dffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-200effff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 832 [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-2026ffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-2027ffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-202802ff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 833 Table 9. Events that automatically notify Support (continued) Automatically Message String Notify Support Event ID 806f010c-2028ffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-2029ffff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f010c-202affff Uncorrectable error detected for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 834 Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f030c-2006ffff Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f030c-2007ffff Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f030c-2008ffff Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 835 Table 9. Events that automatically notify Support (continued) Automatically Message String Notify Support Event ID 806f030c-2009ffff Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f030c-200affff Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f030c-200bffff Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f030c-200cffff Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 836 Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f030c-202fffff Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f030c-2030ffff Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f030c-2581ffff Scrub Failure for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 837 Table 9. Events that automatically notify Support (continued) Automatically Message String Notify Support Event ID 806f050c-2001ffff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f050c-2002ffff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f050c-2003ffff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].
  • Page 838 [MemoryElementName]. 806f050c-201affff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f050c-201bffff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f050c-201cffff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 839 Table 9. Events that automatically notify Support (continued) Automatically Message String Notify Support Event ID 806f050c-201dffff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f050c-201effff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName]. 806f050c-201fffff Memory Logging Limit Reached for [PhysicalMemoryElementName] on Subsystem [MemoryElementName].

  • Page 840: Uefi Diagnostic Codes

    UEFI diagnostic codes are logged in the IMM event log in the compute node. For each event code, the following fields are displayed: Event identifier An identifier that uniquely identifies an event. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 841 Event description The logged message string that appears for an event. Explanation Additional information to explain why the event occurred. Severity An indication of the level of concern for the condition. In the event log, the severity is abbreviated to the first character.
  • Page 842 • I.11002: [I.11002] A processor mismatch has been detected between one or more processors in the system. [I.11002] A processor mismatch has been detected between one or more processors in the system. Severity: Info User Response: Complete the following steps: Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 843 1. This message could occur with messages about other processor configuration problems. Resolve those messages first. 2. If the problem persists, ensure that matching processors are installed (i.e., matching option part numbers, etc) 3. Verify that the processors are installed in the correct sockets. If not, correct that problem. 4.
  • Page 844 • I.1800B: [I.1800B] A cache size mismatch has been detected for one or more processor packages. [I.1800B] A cache size mismatch has been detected for one or more processor packages. Severity: Info Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 845 User Response: Complete the following steps: 1. Verify that matching processors are installed in the correct processor sockets. Correct any mismatch found. 2. Check the IBM support site for an applicable service bulletin or firmware update that applies to this processor error.
  • Page 846 3. Check the IBM support site for any applicable service bulletin or UEFI or adapter firmware update that applies to this error. NOTE: It may be necessary to configure slot to Gen1 or to use special utility Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 847 software so that adapter firmware can be upgraded. Gen1/Gen2 settings can be configured via F1 Setup -> System Settings -> Devices and I/O Ports -> PCIe Gen1/Gen2/Gen3 Speed Selection, or the ASU Utility. 4. Replace the adapter. • I.3048005: [I.3048005] UEFI has booted from the backup flash bank. [I.3048005] UEFI has booted from the backup flash bank.
  • Page 848 [I.580A5] Mirror Fail-over complete. DIMM number % has failed over to to the mirrored copy. Severity: Info User Response: Complete the following steps: Check the system-event log for uncorrected DIMM failures and replace those DIMMs. • I.580A6: [I.580A6] Memory spare copy has completed successfully. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 849 [I.580A6] Memory spare copy has completed successfully. Severity: Info User Response: Complete the following steps: Check system log for related DIMM failures and replace those DIMMs. • S.1100C: [S.1100C] An uncorrectable error has been detected on processor %. [S.1100C] An uncorrectable error has been detected on processor %. Severity: Error User Response: Complete the following steps:...
  • Page 850 • S.3040007: [S.3040007] A firmware fault has been detected in the UEFI image. [S.3040007] A firmware fault has been detected in the UEFI image. Severity: Error User Response: Complete the following steps: Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 851 1. Check the IBM support site for an applicable service bulletin or firmware update that applies to this error. 2. Update the UEFI image. 3. Replace the system board. • S.3050007: [S.3050007] A firmware fault has been detected in the UEFI image. [S.3050007] A firmware fault has been detected in the UEFI image.
  • Page 852 [S.51003] An uncorrectable memory error was detected in DIMM slot % on rank %. Severity: Error User Response: Complete the following steps: 1. Prior to replacing memory DIMM, refer to TIP H212154 for minimum code level. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 853 2. If the compute node has recently been installed, moved, serviced, or upgraded, verify that the DIMM is properly seated and visually verify that there is no foreign material in any DIMM connector on that memory channel. If either of these conditions is found, correct and retry with the same DIMM. (Note: The event Log might contain a recent 00580A4 event denoting detected change in DIMM population that could be related to this problem.) 3.
  • Page 854 2. Check the IBM support site for an applicable service bulletin or firmware update for the system or adapter that applies to this error. 3. Replace the system board. • S.680B8: [S.680B8] Internal QPI Link Failure Detected. [S.680B8] Internal QPI Link Failure Detected. Severity: Error Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 855 User Response: Complete the following steps: 1. Check the IBM support site for an applicable service bulletin or firmware update that applies to this error. 2. Inspect the processor socket for foreign debris or damage. If debris is found, remove the debris. 3.
  • Page 856 3. Replace the system board. • W.305800C: [W.305800C] DRIVER HEALTH PROTOCOL: Reports 'System Shutdown' Required Controller. [W.305800C] DRIVER HEALTH PROTOCOL: Reports 'System Shutdown' Required Controller. Severity: Warning User Response: Complete the following steps: Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 857 1. Reboot the system. 2. If problem persists, switch to the backup UEFI image or update the current UEFI image. 3. Replace system board. • W.305800D: [W.305800D] DRIVER HEALTH PROTOCOL: Disconnect Controller Failed. Requires 'Reboot'. [W.305800D] DRIVER HEALTH PROTOCOL: Disconnect Controller Failed. Requires 'Reboot'. Severity: Warning User Response: Complete the following steps:...
  • Page 858 • W.3868002: [W.3868002] BOFM: Error communicating with the IMM - BOFM may not be deployed correctly. [W.3868002] BOFM: Error communicating with the IMM - BOFM may not be deployed correctly. Severity: Warning User Response: Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 859 Complete the following steps: 1. Update all firmware (including adapter firmware) to the latest levels. 2. If problem persists, contact Support. • W.3938002: [W.3938002] A boot configuration error has been detected. [W.3938002] A boot configuration error has been detected. Severity: Warning User Response: Complete the following steps: 1.
  • Page 860 Make sure that the DIMM connectors are correctly populated for sparing mode. • W.68002: [W.68002] A CMOS battery error has been detected [W.68002] A CMOS battery error has been detected Severity: Warning User Response: Complete the following steps: Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 861: Troubleshooting By Symptom

    2. Go to http://www.lenovo.com/ serverproven/ to validate that the embedded hypervisor device is supported for the compute node.
  • Page 862 LEDs are lit on the applicable ports. • See the documentation for the I/O module for additional information about troubleshooting SAN connectivity or network connectivity issues. Complete the following steps until the problem is solved: Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 863 "Flex System Enterprise Chassis Types 8721, 8724, and 8725: Installation and Service Guide" at http:// pic.dhe.ibm.com/infocenter/flexsys/information/topic/com.lenovo.acc.8721.doc/product_ page.html d. Remove the I/O module and install a working I/O module in the same I/O bay. e. If the problem is solved, replace the I/O module that you removed.
  • Page 864 Use the information in this section to troubleshoot the compute node when you cannot log in to the management node. Action Complete the following steps until the problem is solved: 1. Make sure that you are using the correct password and that the capitals lock is off. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 865 4. Check for any firmware updates that might apply to this problem. You http://www.lenovo.com/support can view the release notes for a firmware update to determine the issues that the update addresses. 5. Remove the compute node from the chassis and check the connectors on the back of the node for bent pins.
  • Page 866 Check the connectors on the chassis midplane to make sure that no pins are bent. d. Remove the CMM and install a working CMM in the same bay. • If the problem is solved, replace the CMM that you removed. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 867 IP address. 6. Check for any firmware updates that might apply to this problem. You http://www.lenovo.com/support can view the release notes for a firmware update to determine the issues that the update addresses. 7. Check for any service bulletins that are related to network connectivity.
  • Page 868 Check the connectors on the chassis midplane to make sure that no pins are bent. d. Remove the I/O module and install a working I/O module in the same I/O bay. • If the problem is solved, replace the I/O module that you removed. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 869 4. Make sure that the configuration settings in the node are correct and that the port is enabled. 5. Check for any firmware updates that might apply to this issue. You can http://www.lenovo.com/support view the release notes for a firmware update to determine the issues that are addressed by the update. 6. Check http://www.lenovo.com/support...
  • Page 870 Check the connectors on the nodes and the chassis midplane to make sure that no pins are bent. c. Replace the I/O expansion card in the management node. d. Replace the system-board assembly in the management node. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 871 Restart the I/O module. b. Check for any firmware updates that might apply to this issue. You http://www.lenovo.com/support can view the release notes for a firmware update to determine the issues that are addressed by the update. c. Perform a virtual reseat of the I/O module.
  • Page 872 If you are unable to log in from the management network, attempt to log in from the data network. If the management node is powered on and hung, perform a virtual reseat of the management node from the CMM. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 873 CMM interface so that a new IP address can be acquired. 6. Check for any firmware updates that might apply to this issue. You can http://www.lenovo.com/support view the release notes for a firmware update to determine the issues that are addressed by the update. 7. Check for any service bulletins that are related to network connectivity.
  • Page 874 CMM interface so that a new IP address can be acquired. If a system-management processor does not have a valid IP address, complete the following steps: a. Restart the CMM in the remote chassis. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 875: Hard Disk Drive Problems

    Check for any firmware or software updates that might apply to this http://www.lenovo.com/support issue. You can view the release notes for a firmware update to determine the issues that are addressed by the update. c. Remove and reinstall the CMM.

  • Page 876: Intermittent Problems

    The intermittent problems table is a two-column table that lists the symptoms and corrective actions for intermittent problems. Column 1 lists the symptom. Column 2 describes the corrective actions for each symptom. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 877: Intermittent Connectivity Problems

    • Follow the suggested actions in the order in which they are listed in the Action column until the problem is solved. Chapter 5 “Parts listing, Types 7167 and 2590” on page 53 • See to determine which components are customer replaceable units (CRU) and which components are field replaceable units (FRU) that must be replaced only by a trained service technician.

  • Page 878: Memory Problems

    Memory problems Use this information to solve memory problems. Follow the suggested actions in the order in which they are listed in the Action column until the problem is solved. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 879: Observable Problems

    (see “Using the Setup utility” on page 28). 5. Run memory diagnostics (see “Lenovo Dynamic System Analysis Preboot diagnostic program ” on page 67). 6. Remove DIMMs until the compute node is showing the correct amount of memory.
  • Page 880 6. Contact your place of purchase of the software or your software provider. Unusual smell An unusual smell might be coming from newly installed equipment. If the problem remains, contact Support. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 881: Problems

    • Follow the suggested actions in the order in which they are listed in the Action column until the problem is solved. Chapter 5 “Parts listing, Types 7167 and 2590” on page 53 • See to determine which components are customer replaceable units (CRU) and which components are field replaceable units (FRU) that must be replaced only by a trained service technician.

  • Page 882: Performance Problems

    Performance problems Use this information to solve performance problems. Follow the suggested actions in the order in which they are listed in the Action column until the problem is solved. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 883: Power-On Problems

    • Follow the suggested actions in the order in which they are listed in the Action column until the problem is solved. Chapter 5 “Parts listing, Types 7167 and 2590” on page 53 • See to determine which components are customer replaceable units (CRU) and which components are field replaceable units (FRU) that must be replaced only by a trained service technician.
  • Page 884 CMM service command. For more information about the CMM service command, see the "Flex System Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 885 • From the CMM web interface, select Power Modules and Management from the Chassis Management menu. For more information, see the the "Flex System Chassis Management Module: User's Guide" at http://pic.dhe.ibm.com/infocenter/flexsys/information/topic/com.lenovo.acc.cmm.doc/ . All fields and options are described in the CMM web interface online help. cmm_user_ guide.html 5.

  • Page 886: Software Problems

    Management Module (see the documentation for the Flex System chassis and Chassis Management Module for more information). 2. Turn off the compute node. 3. Remove the compute node from the Flex System chassis and remove the cover. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 887: Collecting Service Data

    4. Remove or disconnect the following devices, one at a time, until you find the failure. Reinstall, turn on, and reconfigure the compute node each time. • I/O expansion adapter. • Hard disk drives. • DIMMs. The minimum configuration requirement is 4 GB (one 4 GB DIMM on the system board). The following minimum configuration is required for the compute node to start: •...
  • Page 888 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 889: Chapter 7. Installing, Removing, And

    1, 3, and 4. Microprocessor socket 2 will only have a socket cover when a microprocessor is not install. If the compute node has only one microprocessor, it must be installed in microprocessor socket 1. • The air baffles are installed over the DIMM connectors. © Copyright Lenovo 2014, 2018...

  • Page 890: Handling Static-Sensitive Devices

    Chapter 3 “Installing the operating system” on page 41 and your operating-system documentation for additional information. Removing a compute node from a chassis Use this information to remove a compute node from a Flex System chassis. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 891: Installing A Compute Node In A Chassis

    Before you remove a compute node, complete the following steps: 1. Read “Safety” on page iii “Installation guidelines” on page 879. 2. If the compute node is operating, shut down the operating system. 3. Press the power button to turn off the compute node (see “Turning off the compute node”...
  • Page 892 Reinstalling a compute node into a different node bay can have unintended consequences. If you reinstall the compute node into a different node bay, you might have to reconfigure the compute node. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 893: Removing And Replacing Tier 1 Customer Replaceable Units (Crus)

    Removing and replacing Tier 1 customer replaceable units (CRUs) Use this information for removing and replacing Tier 1 CRUs. Replacement of Tier 1 CRUs is your responsibility. If Lenovo installs a Tier 1 CRU at your request, you will be charged for the installation.

  • Page 894: Installing The Adapter-Retention Assembly

    The adapter-retention assembly consists of five separate parts. You can replace only the parts that you choose and save the unused parts for future use. To install the adapter-retention assembly, complete the following steps. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 895: Removing The Bezel

    Adapter retention assemblies Screws Step 1. Remove the cover (see “Removing the compute node cover” on page 888). Step 2. Remove the air baffles. Step 3. Carefully place the chassis on its side with the front handle side up. Step 4. Align the adapter-retention assembly on the system board.

  • Page 896: Installing The Bezel

    Note: Make sure that the bezel is pressed flat against the chassis around the power button, to maintain access to the power button. Removing the CMOS battery Use this information to remove the CMOS battery. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 897: Installing The Cmos Battery

    Before you remove the CMOS battery, complete the following steps: 1. Read “Safety” on page iii “Installation guidelines” on page 879. 2. If the compute node is installed in a Flex System chassis, remove it (see “Removing a compute node from a chassis”...

  • Page 898: Removing The Compute Node Cover

    “Installation guidelines” on page 879. 2. If the compute node is installed in a Flex System chassis, remove it (see “Removing a compute node from a chassis” on page 880 for instructions). Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 899 3. Carefully lay the compute node on a flat, static-protective surface, orienting the compute node with the bezel pointing toward you. Statement 12 CAUTION: The following label indicates a hot surface nearby. Statement 21 CAUTION: Hazardous energy is present when the compute node is connected to the power source. Always replace the compute node cover before installing the compute node.

  • Page 900: Installing The Compute Node Cover

    Push point Release button Posts Slots Step 3. Hold the front of the compute node and slide the cover forward to the closed position, until it clicks into place. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 901: Removing A Dimm

    After you install the compute node cover, install the compute node into the chassis (see “Installing a compute node in a chassis” on page 881 for instructions). Removing a DIMM Use this information to remove a dual inline memory module (DIMM). Before you remove a DIMM, complete the following steps: 1.

  • Page 902: Installing A Dimm

    “Removing a compute node from a chassis” on page 880 for instructions). 4. Carefully lay the compute node on a flat, static-protective surface, orienting the compute node with the bezel pointing toward you. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 903 "Flex System Chassis Management Module: Command-Line Interface Reference Guide" at http://pic.dhe.ibm.com/infocenter/flexsys/ information/topic/com.lenovo.acc.cmm.doc/cli_command_ sol.html • For more information about Lenovo XClarity Administrator, see https://support.lenovo.com/us/en/ documents/LNVO-XCLARIT • For more information about Flex System Manager management software, see "Flex System Manager Software: Installation and Service Guide"...
  • Page 904 Channel 2 19, 20, and 21 Channel 3 22, 23, and 14 Channel 2 25, 26, and 27 Microprocessor 3 28, 29, and 30 Channel 3 Channel 1 31, 32, and 33 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 905 Table 12. Memory-channel configuration (continued) Microprocessor Memory channel DIMM connectors Channel 0 34, 35, and 36 Channel 2 37, 38, and 39 40, 41, and 42 Channel 3 Microprocessor 4 Channel 1 43, 44, and 45 46, 47, and 48 Channel 0 The following notes describe information that you must consider when you install memory: •...
  • Page 906 DIMMs 1, 4, 5, 9, 12, 13, 11, 12, 13, 14, 16, 17, 18, 16, 17, 21, 24, 25, 28, 33, 20, 21, 23, and 24 36, 37, 40, 45, and 48 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 907 Table 13. DIMM population sequence for independent-channel mode (continued) Number of DIMMs 1 microprocessor 2 microprocessors 4 microprocessors installed installed installed installed DIMMs 1, 2, 3, 4, 5, 6, 8, 9, DIMMs 1, 4, 5, 9, 12, 13, 11, 12, 13, 14, 16, 17, 18, 16, 17, 21, 24, 25, 28, 32, 20, 21, 23, and 24 33, 36, 37, 40, 45, and 48...
  • Page 908 11, 12, 13, 14, 15, 16, 17, 18, 20, 21, 23, 24, 25, 26, 28, 29, 31, 32, 33, 34, 35, 36, 37, 38, 40, 41, 43, 44, 45, 47, and 48 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 909 Table 13. DIMM population sequence for independent-channel mode (continued) Number of DIMMs 1 microprocessor 2 microprocessors 4 microprocessors installed installed installed installed DIMMs 1, 2, 3, 4, 5, 6, 8, 9, 11, 12, 13, 14, 15, 16, 17, 18, 20, 21, 23, 24, 25, 26, 28, 29, 31, 32, 33, 34, 35, 36, 37, 38, 40, 41, 43, 44, 45, 46, 47, and 48...
  • Page 910 33 and 36, 45 and 48, 9 5, and 14 and 17, 8 and 11, and 12, 21 and 24, 25 and 20 and 23, 3 and 6 28, 37 and 40, 2 and 5 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 911 Table 14. DIMM population sequence for mirrored-channel mode (continued) Number of DIMM pairs 1 microprocessor 2 microprocessor 4 microprocessor installed installed installed installed DIMMs 1 and 4, 13 and 16, DIMMs 1 and 4, 13 and 16, 9 and 12, 21 and 24, 2 and 33 and 36, 45 and 48, 9 5, and 14 and 17, 8 and 11, and 12, 21 and 24, 25 and...
  • Page 912 Flex System chassis or any unpainted metal surface on any other grounded rack component in the rack in which you are installing the DIMM for at least 2 seconds; then, remove the DIMM from its package. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 913 Step 6. Make sure that both retaining clips on the DIMM connector are in the open position. Step 7. Turn the DIMM so that the DIMM keys align correctly with the DIMM connector on the system board. Attention: To avoid breaking the retaining clips or damaging the DIMM connector, handle the clips gently.

  • Page 914: Removing The Front Handle

    If you are instructed to return the front handles, follow all packaging instructions, and use any packaging materials for shipping that are supplied to you. Installing the front handles Use this information to install the front handle. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 915: Removing The Hard Disk Drive Backplane

    Before you install the front handles, complete the following steps: 1. Read “Safety” on page iii “Installation guidelines” on page 879. 2. If the compute node is installed in a Flex System chassis, remove it (see “Removing a compute node from a chassis”...
  • Page 916 If you are instructed to return the hard disk drive backplane, follow all packaging instructions, and use any packaging materials for shipping that are supplied to you. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 917: Installing The Hard Disk Drive Backplane

    Installing the hard disk drive backplane Use this information to install the hard disk drive backplane. Note: This procedure should be performed only by trained service technicians. Before you install the hard disk drive backplane, complete the following steps: 1. Read “Safety”...

  • Page 918: Removing A Hot-Swap Hard Disk Drive

    If you are instructed to return the hard disk drive, follow all packaging instructions, and use any packaging materials for shipping that are supplied to you. Installing a hot-swap hard disk drive Use this information to install a hot-swap hard disk drive. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 919: Removing An I/O Expansion Adapter

    Before you install the hot-swap hard disk drive, read “Safety” on page iii “Installation guidelines” on page 879. The compute node has two SAS or SATA hard disk drive bays for installing hot-swap hard disk drives, such as hot-swap SAS hard disk drives. One hard disk drive might already be installed in the compute node in hard disk drive bay 0.

  • Page 920: Installing An I/O Expansion Adapter

    This component can be installed as an optional device or as a CRU. The installation procedure is the same for the optional device and the CRU. To install an I/O expansion adapter, complete the following steps. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 921: Removing The Light Path Diagnostics Panel

    See the ServeRAID-M Software User Guide at https:// for instructions. support.lenovo.com/us/en/documents/migr-5086126 After you install the I/O expansion adapter, complete the following steps: 1. Install the cover onto the compute node (see “Installing the compute node cover” on page 890 instructions).

  • Page 922: Installing The Light Path Diagnostics Panel

    3. Carefully lay the compute node on a flat, static-protective surface, orienting the compute node with the bezel pointing toward you. To install a light path diagnostics panel, complete the following steps. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 923: Removing The Usb Flash Drive

    Light path diagnostics Bracket panel Connector Step 1. Remove the cover (see “Removing the compute node cover” on page 888). Step 2. Connect the cable on the system board. Step 3. Align the light path diagnostics panel with the bracket. Step 4.

  • Page 924: Installing The Usb Flash Drive

    This component can be installed as an optional device or as a CRU. The installation procedure is the same for the optional device and the CRU. To install the USB flash drive, complete the following steps. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 925: Removing And Replacing Tier 2 Customer Replaceable Units (Crus)

    Use this information for removing and replacing Tier 2 CRUs. You may install a Tier 2 CRU yourself or request Lenovo to install it, at no additional charge, under the type of warranty service that is designated for the compute node. A Tier 2 CRU must be installed only by trained service technicians.
  • Page 926 Use the microprocessor installation tool that comes with the replacement base assembly to remove the microprocessor from the defective base assembly and install it immediately in the replacement base assembly. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 927 Use a screwdriver to loosen the screw on one side of the heat sink to break the seal with the microprocessor. Use a screwdriver to loosen the screws on the heat sink, rotating each screw two full turns until each screw is loose. Gently pull the heat sink from the microprocessor.
  • Page 928 • If using Installation Tool B, gently twist the handle of the installation tool clockwise until it locks in the “H” or “L” position, depending on the size of microprocessor, and then lift the microprocessor out of the socket. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 929 Attention: Do not touch the connectors on the microprocessor and the microprocessor socket. Open the packaging that contains the new microprocessor installation tool assembly and carefully remove the installation tool assembly from the package. Note: Do not touch the microprocessor contacts. Contaminants on the microprocessor contacts, such as oil from your skin, can cause connection failures between the contacts and the socket.
  • Page 930 • Make sure that the microprocessor is aligned correctly in the socket before you try to close the microprocessor retainer. • Do not touch the thermal grease on the bottom of the heat sink or on top of the microprocessor. Touching the thermal grease will contaminate it. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 931 Microprocessor retainer Release lever Dust cover Release lever Close the microprocessor retainer on the microprocessor socket. Identify which release lever is labeled as the first release lever to close, and close it. Close the second release lever on the microprocessor socket. Attention: •...
  • Page 932 IP address of the IMM is restored. 3. Reactivate any Features on Demand features. Instructions for automating the activation of features and installing activation keys is in the Lenovo Features on Demand Users Guide. To download the document, go to , log in, and click Help.

  • Page 933: Removing The Chassis Bulkhead

    If you are instructed to return the defective base assembly, follow all packaging instructions, and use any packaging materials for shipping that are supplied to you. Important: Make sure that both heat-sink fillers are installed on the defective base assembly that you are returning, prior to shipment.

  • Page 934: Installing The Chassis Bulkhead

    • Install the air baffles with the arrow indicating air airflow direction pointing to the rear of the compute node. • To maintain proper system cooling, do not operate the compute node without air baffles installed over the DIMM connectors. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 935: Removing The Hard Disk Drive Cage

    After you install the chassis bulkhead, complete the following steps: 1. Install the cover onto the compute node (see “Installing the compute node cover” on page 890 instructions). 2. Install the compute node into the chassis (see “Installing a compute node in a chassis” on page 881 instructions).

  • Page 936: Removing A Fabric Connector

    880 for instructions). 3. Carefully lay the compute node on a flat, static-protective surface, orienting the compute node with the bezel pointing toward you. 4. Obtain a #1 Phillips screwdriver. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 937: Installing A Fabric Connector

    When you remove the fabric connector, the UEFI firmware holds the Ethernet controller in reset and displays a warning message, if an I/O expansion adapter is not installed in the I/O expansion connector 1 to provide connectivity to the chassis. To remove a fabric connector, complete the following steps.

  • Page 938: Removing A Microprocessor And Heat Sink

    • The microprocessor installation tool might become worn after several uses. Make sure that the tool can hold the microprocessor securely if you are reusing an existing microprocessor installation tool. Do not return the tool with other parts that you are returning. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 939 • If you are installing a second microprocessor, the option kit comes with a microprocessor installation tool that you must use when you install a microprocessor. The microprocessor installation tool comes with the replacement microprocessor installed on it and a cover over the microprocessor. •...
  • Page 940 Open the second release lever on the microprocessor socket. Open the microprocessor retainer. Attention: Do not touch the connectors on the microprocessor and the microprocessor socket. Step 5. Remove the microprocessor from the socket. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 941 Select the empty installation tool and ensure that the handle is in the open position. If the installation tool handle is not in the open position, use the following instructions for your installation tool: • If using Installation Tool A, twist the microprocessor installation tool handle counterclockwise to the open position.

  • Page 942: Installing A Microprocessor And Heat Sink

    Note: This procedure should be performed only by trained service technicians. The architecture of the Intel E5-46xx CPU and DMI switching of microprocessor sockets 1 and 2 allow for the processors to be populated as shown in the following figures. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 943 Table 15. Supported CPU installation combinations Number of Microprocessors Microprocessors Microprocessors Microprocessors microprocessors socket 1 socket 2 socket 3 socket 4 CPU0 CPU0 CPU1 CPU0 CPU1 CPU2 CPU3 Notes: 1. CPU0 is the boot strap processor. 2. If a bad processor in microprocessor socket 1 causes the processor installed in microprocessor socket 2 to become the boot strap processor and is subsequently replaced, the processor ordering reverts to the default CPU IDs for the new number of CPUs, because the FPGA would not hold the last CPU ID assignments and “add in”...
  • Page 944 “Removing a compute node from a chassis” on page 880 for instructions). 3. Carefully lay the compute node on a flat, static-protective surface, orienting the compute node with the bezel pointing toward you. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 945 The following notes describe the type of microprocessor that the compute node supports and other information that you must consider when you install a microprocessor: • This component can be installed as an optional device or as a CRU. The installation procedure is the same for the optional device and the CRU.
  • Page 946 (see “Thermal grease” on page 940). Step 3. Remove the heat-sink filler, if one is present. Step 4. Open the microprocessor socket release levers and retainer. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 947 Microprocessor retainer Release lever Release lever Identify which release lever is labeled as the first release lever to open and open it. Open the second release lever on the microprocessor socket. Open the microprocessor retainer. Step 5. Install the microprocessor in the microprocessor socket. Open the packaging that contains the new microprocessor installation tool assembly and carefully remove the installation tool assembly from the package.
  • Page 948 Align the installation tool with the microprocessor socket. The installation tool rests flush on the socket only if it is properly aligned. Installation tool Microprocessor Screws Install the microprocessor using the following instructions for your installation tool. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 949 • If using Installation Tool A, twist the handle on the microprocessor tool assembly counterclockwise to the open position to insert the microprocessor into the socket, and lift the installation tool out of the socket. • If using Installation Tool B, twist the handle of the installation tool assembly counterclockwise until the microprocessor is inserted into the socket, and lift the installation tool out of the socket.

  • Page 950: Thermal Grease

    Step 4. Use a clean area of the cleaning pad to wipe the thermal grease from the microprocessor; then, dispose of the cleaning pad after all of the thermal grease is removed. Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 951: Removing A Microprocessor-Retention Assembly

    0.02 mL of thermal grease Microprocessor Step 5. Use the thermal-grease syringe to place nine uniformly spaced dots of 0.02 mL each on the top of the microprocessor. Note: 0.01mL is one tick mark on the syringe. If the grease is properly applied, approximately half (0.22 mL) of the grease will remain in the syringe.

  • Page 952: Installing A Microprocessor-Retention Assembly

    To install a microprocessor-retention assembly, complete the following steps. Microprocessor- retention assembly Heat-sink key Step 1. Remove the cover (see “Removing the compute node cover” on page 888). Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 953 Step 2. Make sure that the microprocessor socket release levers are in the open position. Step 3. Align the microprocessor-retention assembly on the system board. Attention: 1. Do not allow the microprocessor-retention assembly to touch the microprocessor socket. Doing so might result in permanent damage to the system board. 2.
  • Page 954 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 955: Appendix A. Getting Help And Technical Assistance

    Before you call, make sure that you have taken these steps to try to solve the problem yourself. If you believe that you require warranty service for your Lenovo product, the service technicians will be able to assist you more efficiently if you prepare before you call.

  • Page 956: Using The Documentation

    • Secure upload with the system serial number: https://www.ecurep.ibm.com/ app/upload_hw Creating a personalized support web page You can create a personalized support web page by identifying Lenovo products that are of interest to you. To create a personalized support web page, go to http://www.ibm.com/support/ mynotifications .

  • Page 957: Hardware Service And Support

    IBM is Lenovo's preferred service provider for the System x, Flex System and NeXtScale System products. You can receive hardware service through your Lenovo reseller or from IBM. To locate a reseller authorized by Lenovo to provide warranty service, go to and click Business Partner http://www.ibm.com/partnerworld...
  • Page 958 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 959: Appendix B. Notices

    Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.

  • Page 960: Trademarks

    Lenovo encourages owners of information technology (IT) equipment to responsibly recycle their equipment when it is no longer needed. Lenovo offers a variety of programs and services to assist equipment owners in recycling their IT products. For information on recycling Lenovo products, go to: http://www.lenovo.com/...

  • Page 961: Particulate Contamination

    If Lenovo determines that the levels of particulates or gases in your environment have caused damage to the device, Lenovo may condition provision of repair or replacement of devices or parts on implementation of appropriate remedial measures to mitigate such environmental contamination.

  • Page 962: Electronic Emission Notices

    Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Lenovo is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment. Unauthorized changes or modifications could void the user's authority to operate the equipment.

  • Page 963: Germany Class A Statement

    Verträglichkeit von Geräten), bzw. der EMV EU Richtlinie 2014/30/EU, für Geräte der Klasse A. Dieses Gerät ist berechtigt, in Übereinstimmung mit dem Deutschen EMVG das EG-Konformitätszeichen - CE - zu führen. Verantwortlich für die Konformitätserklärung nach Paragraf 5 des EMVG ist die Lenovo (Deutschland) GmbH, Meitnerstr. 9, D-70563 Stuttgart.

  • Page 964: Japanese Electromagnetic Compatibility Statements

    This is for any areas other than home. Russia Electromagnetic Interference (EMI) Class A statement People's Republic of China Class A electronic emission statement Taiwan Class A compliance statement Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 965: Taiwan Bsmi Rohs Declaration

    Taiwan BSMI RoHS declaration Appendix B. Notices...
  • Page 966 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...

  • Page 967: Index

    CD commands on USB interface preference, Setup utility documentation, Brocade components documentation, related compute node, removing and replacing drive illustrated option, SAS returning option, SATA system board compute node running installing © Copyright Lenovo 2014, 2018...
  • Page 968 Germany Class A statement logging in guidelines Important notice, meaning installation important notices servicing electrical equipment indicators system reliability information center trained service technicians inspecting for unsafe conditions installation guidelines installing bezel Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 969 See IMM2 installing intermittent connectivity problems removing intermittent problems specifications introduction, Flex System x440 Compute Node memory problems IP addresses, LAN over USB memory, Setup utility messages UEFI diagnostic codes microprocessor Japanese electromagnetic compatibility statements...
  • Page 970 Setup utility RFID tag system settings, Setup utility Russia Class A electronic emission statement system summary, Setup utility system-board assembly Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
  • Page 971 Troubleshooting, single node cannot ping the I/O module Troubleshooting, single node cannot ping the x440 Compute Node Types 7167 and 2590 management node 859, 862 dimensions Troubleshooting, single node cannot ping the specifications management node, different chassis 859, 862 weight © Copyright Lenovo 2014, 2018...
  • Page 972 Lenovo Flex System x440 Compute NodeInstallation and Service Guide...
