Foip; Figure 2-11 Fax Configuration Interface (Tgw4/Tgw8) - Tadiran Telecom aeonix TGW4 User Manual

User Manual
Name
Using notify instead of
401/402
No name in default package
Keep connection when
on-hook

2.2.9 FoIP

After login, click Basic>FoIP to open this interface.
Fax Configuration Interface (
Figure 2-11
38
Description
Set whether the gateways report "offhook events" to replace 401 messages in NTFY or
report "on-hook events" to replace 402 messages in NTFY when responding to messages
sent by the proxy server. Default not selected.
Selected: the gateways will use NTFY messages to replace 401 and 402 messages.
Select if a package name is included when the gateways reply to the default package.
Default not selected.
Select if the gateways actively cancel connection disconnect when subscribers hook on.
Default not selected.
TGW4/TGW8
T G W S IP -F X S /F S O G a te w a y S e rie s
)
Tadiran Telecom
