T G W S IP -F X S /F S O G a te w a y S e rie s
Indicator
STU
(red, green)
WAN
(green)
PC
(green)
FXS/FXO
(green)

1.3.2 TGW8-2G

The TGW8-2G adopts a compact metal structural design. It can be placed on a desk or installed in a
standard communications cabinet and provides eight analog ports. TGW8-2G supports the following
types of configuration.

Table 1-6 Configuration Combination of TGW8-2G

Models
TGW8-2G
TGW8S-2G
TGW8FXO-2G
Tadiran Telecom
Status Description
Steady green The device is running.
Off The device is powered off or a power supply fault occurred
The WAN interface failed to acquire the IP address. Possibly the WAN
interface is not connected to a network cable, the WAN interface
Steady red
address failed to be acquired by DHCP, the IP addresses are conflicted,
and the PPPoE dialing failed.
Blinking red The device is starting or the KUPDATE is upgrading.
Steady green Registration is successful.
Blinking
alternatively
Registration failed.
between red and
green
Blinking green Calling.
Off Registration has not started.
Steady green A WAN connection is established without any service flow.
Blinking green A WAN connection is established with service flow.
Off WAN interface is disconnected.
Steady green A link is connected without any service flow.
Blinking green A service flow is being transmitted.
Off A link is not connected.
Steady green Off-hook or call established
Blinking green Ringing on incoming call
Off The port is in idle status
Number of FXS Ports
4
8
0
User Manual
Number of FXO Ports
4
0
8
