Destination
ROUTE FXS
ROUTE FXO
ROUTE IP

2.5.3 Examples of Routing Rules

Examples of how routing table can be used to implement features:
1) Assigning One Phone with Dual Numbers
2) Hunt Group
3) Outbound Call Barring
4) Trunk Group for Outbound Calling
Assigning One Phone with Dual Numbers
For example, an analog extension of an FXS port, FXS1, of TGW4 can be associated with two phone
numbers: a PSTN number 61202701 and an extension number 1001. The PSTN number is used for direct
inward dialing and the extension number is used for intercom. This feature can be supported by
configuring the FXS1 number as 61202701 and adding the following routing rule to the routing table:
FXS 1001
Hunt Group
A hunt group is a group of extensions, to which an inbound call is terminated following certain rules.
Here is an example of terminating incoming calls from analog trunks to a hunt group consisting of ports
FXS1 and FXS2 in round-robin fashion:
FXO x
Outbound Call Barring
Restrict users to make certain calls, such as an international call. Examples are as follows:
60
Description and Example
Route a call to FXS port(s).
Example 1: IP 800[0-3]
Select a port in sequential order.
Example 2: IP 800[0-3]
Direct this call to FXS port 1.
Example 3:
IP 800[0-3]
Select a port in round-robin order
Example 4: IP 800[0-3]
Select all idle ports and provide ringing.
Route a call to FXO port(s).
Example 1: IP x
Select a port in sequential order.
Example 2: IP 800[0-1]
Select a port in round-robin order.
Route a call to the SIP proxy server
Example: FXS 021 ROUTE IP 228.167.22.34:5060
228.167.22.34:5060 is the IP address and port of the platform.
ROUTE FXS
ROUTE FXS 1-2/R
ROUTE FXS 1-2
ROUTE FXS 1
ROUTE FXS 1-2/R
ROUTE FXS 1-2/G
ROUTE FXO 1-2
ROUTE FXO 1-2/R
1
