System Status Interface
Figure 2-53

Table 2-43 System Status Parameters

Name
Login User Info
SIP Registration Info
Latest Call Info
Call Context Info
(Call Context Info)
Rtp Context Info

2.9.2 Call Message

After login, click Logs>Call Message to open this interface.
94
Description
Show the IP address and permissions of the login user. The numbers following the IP address
show the online permission level of the user: 1- administrator, 2 - operator, 3 – viewer. The
viewer can only read the configuration.
When more than one administrator log in at the same time, the first login's permission level is
1,the other two users' permission level is level 3; when more than one operator log in at the
same time, the first user's permission level is 2, the others are 3.
Show registration status:
Not enabled: the registration server's address has not been entered;
Latest response: the latest response message for the registration. 200 means the registration is
successful;
No response: no response from registration server. The cause may be contributed to 1) incorrect
address for the registration server; 2) IP network failure; or, 3) the registration server is not
reachable.
Show the latest call.
Show the call status.
Show the voice channel related to the calls.
