T G W S IP -F X S /F S O G a te w a y S e rie s
System Configuration Interface
Figure 2-6

Table 2-5 System Configuration Parameters

Name
Off-hook timer
Interdigit timer
Complete entry
timer
Codec
Hook-flash handle
Tadiran Telecom
Description
If a subscriber does not dial any digit within the specified time by this parameter after off-hook,
the gateways will prompt to hang up with a busy tone.
The value must be an integer, decimal points are not allowed.
Unit: Seconds; Default value: 15 seconds.
The maximum time interval to dial the next digit.
After timeout, the gateways will call out with the collected number.
The value must be an integer, decimal points are not allowed.
Unit: Seconds; Default value: 5 seconds.
The value must be an integer, decimal points are not allowed.
Unit: Seconds; Default value: 2 seconds.
This parameter is used with the "x.T" rule set in dialing rules. For example, there is "021.T" in
the dialing rules table. When a subscriber has dialed 021 and has not dialed the next number
within a set time by this parameter (e.g. 2 seconds), the gateways will consider that the
subscriber has ended dial-up and call out the dialed number 021.
Configures the voice codec in the format of "codec/frame size", for example, G.729A/20. For
the available codec types and frame size, see Table 2-6. When multiple types of codec are
configured, the codec is separated by using a comma (,). The device negotiates with the
registration platform on the use of codec in left-to-right order.
Note: The default frame size for each codec is displayed on the page, you can specify a proper
value according to the actual configuration environment. If the frame size is not specified, the
default one will be used. For example, if the codec is set to G.729A, the device automatically
use G.729A/20 to negotiate with the registration platform.
The gateways provide the following processing modes after detecting hook flash from
subscriber terminals:
Internal: the hook flash event will be handled internally;
Server(RFC 2833): transmitting the hook flash to platform with RFC 2833;
Server (SIP INFO): transmitting the flash-off to platform with SIP INFO.
User Manual
31
