User Manual
Indicator
Indicator of button:
RST

1.3.3 TGW16/24-2G

Designed with a 1U high and 19-inch wide compact chassis, TGW16/24-2G is suitable for installation
in a standard cabinet. TGW16/24-2G has a built-in power module with the rating voltage of 100-240 V
AC or -48 V DC (DC is optional). The interface card of TGW16/24-2G uses a RJ-45 socket and is
connected to the distribution panel in equipment room using CAT-5 cables supplied with the unit.
TGW16/24-2G offers up to 48 interfaces of FXS/FXO. TGW16/24-2G supports the following types of
configuration.

Table 1-10 Configuration Combinations of TGW16/24-2G

Models
TGW16-2G
TGW16-2G-DC
TGW24-16-2G
TGW24-16-2G-DC
TGW24-24-2G
TGW24-24-2G-DC
TGW-24-2G-16S/16B
8
Status Description
the port is damaged.
Indicates running status:
Steady yellow Calling in or out via an analog trunk.
Blinking yellow Ringing of calling in for an analog trunk.
Steady green Off-hook or call established
Blinking green Ringing on incoming call
Off The port is in idle status
Note: The device starts up for approximate 30s to indicate line type, then indicates running
status.
To restore the TGW8-2G to factory default, press the RST for more than 3 seconds and release
it when the STU light starts blinking in red. This setting will be valid after rebooting the device.
Number of FXS Ports
8
24
16
T G W S IP -F X S /F S O G a te w a y S e rie s
Number of FXO Ports
8
0
16
Tadiran Telecom
