Subscriber Line Batch (Unavailable On The Tgw4) - Tadiran Telecom aeonix TGW4 User Manual

T G W S IP -F X S /F S O G a te w a y S e rie s
Name
Registration
subscription
Call waiting
Call hold
Call transfer by
calling party
Caller ID
delivery
Caller ID
restriction
DND allowance
Outgoing call
barring
Three-way
calling
Polarity reversal
signal sending
Disabled
Subscribe MWI
DDI (Direct
Dialing in)
Recording

2.3.3 Subscriber Line Batch (Unavailable on the TGW4)

The content below is only applicable to gateways with FXS ports.
After login, click Line> Batch to open the configuration interface.
Step 1 Click , the following interface is shown. Choose batch configured features and click OK.
Step 2 Click
Line > Configuration.
Tadiran Telecom
Description
The device subscribes the registration status of the line. If the subscription is successful, the SIP
server sends a NOTIFY message for notification of the registration status of the line.
Note: This parameter is displayed only when IMS is selected and Registration subscription is
checked on Advanced>SIP page.
Select if Call waiting is activated on this line. By default this is not selected.
Select it to enable Call Hold on this line. By default this is not selected.
Note: If this function is enabled, the gateways will automatically activate Call Transfer.
Select if Caller Transfer is activated on this line. By default, this is not selected. When A calls B, B
picks up the call and A transfers the call to C.
Note: The call hold must be activated before caller transfer.
Set whether the calling number is sent to the called party. This feature requires the support of
softswtich. By default this is selected.
Set whether the number of this telephone is sent to the called party with support from platform. By
default this is not selected
Select if Do Not Disturb is allowed to enable on this line. By default, this is not selected.
Select if outgoing calls are barred on this line. By default, this is not selected.
Select if 3-way service is activated, and by default this is not selected.
Select if reverse polarity signal sending is activated on this line. By default, this is not selected.
Note:
The gateways will provide reverse polarity signal when the phone is connected after this feature is
activated.
Select to disable the line, in which the FXS port no longer supplies current to the phone. By default,
this is not selected.
Select if voice mail service is activated. This is not selected by default. (Also see MWI
Re-subscription on page Advanced > SIP.)
Set whether DDI (Direct Dialing In) is activated, By default, this is not selected. Different from
FXS, DDI is only used for incoming calls, and the gateways will not send dial tone after off-hook
(calling in) on user side.
Note: Reverse polarity signal must be activated on the gateways when DDI is used.
Select if recording service is activated, and by default this is not selected.
to activate this function to configure this parameter. For details of the parameter, see
User Manual
45
