User Manual
Figure 1-11 TGW16-3G Front Panel
Description of TGW16/24-3G Front Panel
Table 1-16
Item
Each RJ45 socket has 8 pins leading out 4 pairs of analog telephone or trunk lines in agreement with the
pair specifications for Ethernet interfaces, whose corresponding relations can be seen in the table below.
CAT-5 cables are used to connect the interface card and distribution panel in equipment installation.
Standard RJ11 telephone lines can be used to plug in a RJ45 socket. The telephone/trunk lines are
connected to the 3
Pin Specifications for TGW16/24-3G RJ45 Socket Port
Table 1-17
RJ45 Pin Number
Analog line pair
Reference color
12
Remarks
Three interface slots; each has four RJ45 sockets; each RJ45 socket can correspond with four pairs of
analog lines.
Note: Numbers of interface slots vary from different configuration.
Matrix of 4 x 4 LED status indicators on the interface card
rd
pair of pins for simple call test.
1 2
st
1 Pair
TIP1 RING1
Orange
Orange
white
3 4
nd rd
2 Pair 3 Pair
TIP2 TIP3 RING3
Green Blue
Blue
white white
T G W S IP -F X S /F S O G a te w a y S e rie s
5 6 7
nd
2 Pair
RING2 TIP4
Brown
Green
white
Tadiran Telecom
8
th
4 Pair
RING4
Brown
