Table 2-22 Routing Destination

Destination
ROUTE NONE
Tadiran Telecom
Description and Example
Another use of REPLACE is to replace the specific number based on another number associated
with the call. For example, replacing the calling number according to the called number.
Examples:
FXS
12345
FXS
CPN13
For calls from FXS ports with called party number of 12345, remove one digit at the end of the
calling number and add 8621; for calls from FXS ports with calling party number starting with
13, add 0 at the beginning of the called number.
End-of-number transformation. From top to bottom, number transformation will be stopped when
END or ROUTE is encountered; the gateways will route the call to the default routing upon
detecting END, or route the call to the designed routing after detecting ROUTE.
Example 1:
FXS
12345
ADD
FXS
12345
REMOVE
FXS
12345
END
Add suffix 8001 to the called number starting with 12345 for calls from FXS ports, then remove
four digits in front of the number to end number transformation yielding 58001.
Example 2:
IP
[222.34.55.1]
CPNX.
IP
[222.34.55.1]
CPNX.
For calls from IP address 222.34.55.1, calling party number is replaced by 2680000, and then the
call is routed to FXS port 2 with the new calling party number.
Designate the use of a codec, such as PCMU/20/16, where PCMU denotes G.711, /20 denotes
RTP packet interval of 20 milliseconds, and /16 denotes echo cancellation with 16 milliseconds
window. PCMU/20/0 should be used if echo cancellation is not required to activate.
Example: IP
6120
PCMU/20/16 codec will be applied to calls from IP with called party number starting with 6120.
Insert prefix of called party number when calling out. The inserted prefix number follows
RELAY.
Example:
IP
010
RELAY
For calls from IP with called party numbers starting with 010, digit stream 17909 will be
outpulsed before the original called party number is sent out.
Example:
IP
010
RELAY
For a call from the IP end with the called number starting with 010, before the call is made, 17909
is automatically dialed first and three seconds later, the called number is dialed.
One comma "," represents one second.
Description and Example
Calling barring (also known as "blacklist").
Example: IP
CPN[1,3-5]
Bar all calls from IP, of which the calling numbers start with 1, 3, 4, and 5.
Block all calls from IP numbers starting with 1, 3, 4, 5
REPLACE
CPN-1/8621
REPLACE
CDPN0/0
-8001
4
REPLACE
2680000
ROUTE
FXS
CODEC
PCMU/20/16
17909
17909 ,,,
ROUTE
NONE
User Manual
2
59
