Test Parameter Editing Commands
These commands are used to modify the test parameter within each step. These
commands require a parameter value to be included with the command. The writing of
the parameter requires that the unit not be included with the value, only the numeric
value should be included with the command.
Command
CONN {1|0}
CURR <value>
DDT <value>
MAXL <value>
MINL <value>
FREQ {50|60}
COFF <value>
System Parameter Editing Commands and Companion Queries
These commands are used to modify the system parameters for the instrument.
These
commands require a parameter value to be included with the command.
Command
PLC {1|0}
SSTP {1|0}
ALAR <value>
CNTR <value>
RLT {L|A|P}
HS {1|0}
Query Commands
These query commands will retrieve data from the instrument. These commands
include functions for retrieving test data, test results and remote hardware.
Command
TD?
RD <step number>?
SALL?
RR?
RI?
TD?
Read the active data being displayed on the LCD display while the test is in process. It
will also read the last data taken when the test sequence has completed. Each
48
Name
Connect ON/OFF
Edit Current
Dwell Time
Edit Max Limit
Edit Min Limit
Edit Frequency
Offset
Name
PLC Remote ON/OFF
Single Step ON/OFF
Alarm Level
Contrast Level
Result Setting
Hipot Start
Name
List Testing Data from test in Process
Data
Result Data 1-3
Query
List Step Response:
Parameters SALL memory+step,p1,p2,p3...
Read Reset 1=Open, 0=Closed
Query
Read Interlock 1=Open, 0=Closed
Query
Value
1=On, 0=Off
1.00-30.00A
0, 0.5-999.9sec
0-510mΩ
0-510mΩ
50 or 60Hz
0-100mΩ
Value
1=On, 0=Off
1=On, 0=Off
0-9, 0=Off, 9=High
0-9, 9=High
L=Last, A=All, P=P/F
0=GW, 1=G+W
Value
