The Hipot Start parameter is only used when connecting the HYAMP III with an
Associated Research Hipot tester. If GW is selected, the Hipot test will run after the
HYAMP III has completed its test. If G + W is selected, the Hipot test will run at the
same time as the HYAMP III.
The Hipot Start parameter directly controls the Start Output relay. Running in the
GW mode will momentarily close the Start Output relay at the end of the HYAMP III
test. Running in the G + W mode will momentarily close the Start Output relay at the
start of the HYAMP III test.
Cal-Alert (Calibration Alert)
The Cal-Alert feature alerts the user that the instrument is due for calibration. Turning
this parameter ON will activate the Cal-Alert function and when the date matches the
Alert Date, the instrument will display the Cal-Alert warning screen upon power up. If
the "Show this screen again?" function has been turned OFF at the Cal-Alert Warning
screen, this parameter will automatically be set to OFF.
Cal Date(Calibration Date)
Cal Date is a non-editable parameter that indicates the last date that calibration was
performed on the instrument. This parameter is updated at the time of calibration.
Cal Due (Calibration Due Date)
After a calibration is performed, the Cal Due Date is automatically set for 1 year after
the calibration date. This parameter may be overwritten to any date desired. Within
the Cal Due Date parameter are three separate fields, month, day, and year. Use the
"" soft key to select the field within the date you want to edit then use the "+" soft key
to change the numeric value. Once you change the value it is automatically stored.
NOTE: It is recommended that calibration should be performed at least once a
year.
Alert (Alert Date)
The Alert Date is like an alarm clock that will warn you in advance of the actual
Calibration Due Date. After a calibration is performed, the Alert Date is automatically
set for 11 months after the calibration date. For example, if the calibration is
performed on 12/15/2002 the Alert Date will automatically be set to 11/15/2003.
This parameter may be overwritten to any advanced date desired. Within the Alert
Date parameter are three separate fields, month, day, and year. Use the "" soft key
to select the field within the date you want to edit. Use the "+" soft key to change the
numeric value. Once you change the value it is automatically stored.
Date
Within the Set Date parameter are four fields, date format (mdy / dmy), month, day,
and year. Use the "" soft key to select the field within the date you want to edit. Use
26
