connected test step. Each time the TEST button is pressed the next connected test
step will execute. If you press the RESET button before completing all connected test
steps, it will return you to the original starting test step. If a step fails and you wish to
continue to the next test step press TEST.
Alarm Volume
The numbers 0 through 9 correspond to different volume settings, 0 meaning the
volume is OFF and 9 meaning the volume is at the loudest setting. After the "+" soft
key is pressed a momentary alarm chirp will occur to indicate the volume of the new
setting.
LCD Contrast
The numbers 0 through 9 correspond to the different contrast settings, 0 meaning the
lightest color of displayed characters and 9 meaning the darkest color of displayed
characters. After the "+" soft key is pressed the display will automatically adjust to the
new display setting.
Results
Selects the type of results you would prefer
to have displayed at the end of a test or
sequence of connected test steps. The
available selections are: All, P/F and Last.
When All is selected, a Results Summary
screen will be displayed at the end of the
test or sequence of connected test steps
displaying the results of all of the test steps.
The Results Summary screen will appear as
follows:
When P/F is selected, a Pass or Fail screen will be displayed at the end of the test.
The Pass and Fail screens will appear as follows:
24
