IKONIX SCi 260 Series Operation & Service Manual

Ground bond tester
Hide thumbs
Table of Contents

Advertisement

Quick Links

Operation &
Service Manual
Model 264, 266 • V1.05
Model 264 (40 Amperes Ground Bond Tester)
Model 266 (60 Amperes Ground Bond Tester)
Item 99-10760-01
Printed May 20, 2020
Model 266
RoHS 2
COMPLIANT
2011/65/EU
Model 264

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCi 260 Series and is the answer not in the manual?

Questions and answers

Related Manuals for IKONIX SCi 260 Series

Summary of Contents for IKONIX SCi 260 Series

  • Page 1 Operation & Service Manual Model 264, 266 • V1.05 Model 264 (40 Amperes Ground Bond Tester) Model 266 (60 Amperes Ground Bond Tester) Item 99-10760-01 Printed May 20, 2020 RoHS 2 COMPLIANT 2011/65/EU Model 266 Model 264...
  • Page 2 DECLARATION OF CONFORMITY Manufacturer: SCI a Division of Ikonix USA Address: 28105 N. Keith Drive Lake Forest, IL 60045 Product Name: SCI 260 Series Model Number: Conforms to the following Standards: Safety: UL 61010-1:2012 CAN/CSA-C22.2 NO. 61010-1-12 IEC 61010-1:2010 IEC 61010-2-30:2010...
  • Page 3 DECLARATION OF CONFORMITY Manufacturer: SCI a Division of Ikonix USA Address: 28105 N. Keith Drive Lake Forest, IL 60045 Product Name: SCI 260 Series Model Number: Conforms to the following Standards: Safety: UL 61010-1:2012 CAN/CSA-C22.2 NO. 61010-1-12 EN 61010-1:2010 EN 61010-2-30:2010...
  • Page 4 Warranty Policy SCI a Division of Ikonix USA certifies that the tester listed in this manual meets or exceeds published manufacturing specifications. This tester was calibrated using standards that are traceable to the National Institute of Standards and Technology (NIST).

  • Page 5: Table Of Contents

    TABLE OF CONTENTS SAFETY PRECAUTIONS ..................................1 Front Panel Controls ..................................2 264 Rear Panel Controls ..................................3 266 Rear Panel Controls ..................................4 Setup Instructions for Model 264/266 ............................5 Getting to Know Your Tester .........................................6 1. Working with Memories ........................................6 2. Perform Test Screen .........................................6 3.

  • Page 6: Safety Precautions

    Safety Precautions GENERAL This product and its related documentation must be reviewed for familiarization with safety markings and instructions before operation. This product is a Safety Class I tester (provided with a protective earth terminal). Before applying power verify that the tester is connected to the correct line voltage and the correct fuse is installed. INSTRUCTION MANUAL SYMBOL.

  • Page 7: Front Panel Controls

    Front Panel Controls RESET BUTTON - This is a momentary contact switch used to reset the tester. If an out-of-range reading is detected during a test, the red failure lamp within the button will light. To reset the system for the next test, press and release this button.

  • Page 8: 264 Rear Panel Controls

    264 Rear Panel Controls POSITION FOR OPTIONAL REAR OUTPUT JACKS Please refer section Optional Rear Panel Controls for details. CALIBRATION ENABLE KEY - To enter the calibration mode press this key while the tester is being powered ON. USB INTERFACE - Optional USB port for serial communication.

  • Page 9: 266 Rear Panel Controls

    266 Rear Panel Controls POSITION FOR OPTIONAL REAR OUTPUT JACKS - Please refer section Optional Rear Panel Controls for details. CALIBRATION ENABLE KEY - To enter the calibration mode press this key while the tester is being powered ON. USB INTERFACE - Optional USB port for serial communication.

  • Page 10: Setup Instructions For Model 264/266

    2. Connect the power input plug into its socket on the rear panel of the tester. The SCI 260 series of testers has an automatic input voltage range. 3. Connect the male end of the plug to the grounded AC outlet.

  • Page 11: Getting To Know Your Tester

    Getting to Know Your Tester 1. Working with Memories The model 264/266 is equipped with 5 memory locations numbered M1 through M5. Each memory location contains one step that can be connected sequentially to the next consecutive step. 2. Perform Test Screen The Perform Test Screen displays 4 parameters Follow the setup procedures to set the desired parameters.

  • Page 12: Setting Up A Gnd Bond Test

    4. Setting up a GND Bond Test PROGRAM A MEMORY: CHANGE CURRENT START When CURR is selected. Press the Turn the yellow rotary knob to Turn the rotary knob to change scroll to desired parameter to rotary knob to edit the Current. the Current for each digit.
  • Page 13 PROGRAM A MEMORY: CHANGE LO LIMIT START When LO-L is selected. Press the Turn the yellow rotary knob to Turn the rotary knob to change scroll to desired parameter to rotary knob to edit the LO-Limit. the LO-Limit setting for each digit. edit LO-L.
  • Page 14 PROGRAM A MEMORY: CHANGE FREQUENCY START Turn the yellow rotary knob to When FREQ is selected. Press the Turn the rotary knob to change the Frequency setting: 50Hz or 60Hz. scroll to desired parameter to rotary knob to edit the Frequency. edit FREQ.
  • Page 15 PROGRAM A MEMORY: CHANGE OFFSET AUTO START RESET TEST RETURN POWER When OFFS is selected. Push the Short the Red High Current lead with rotary knob to edit the O set. the Black Return Lead as shown above The options will blink. RESET TEST RETURN...

  • Page 16: System Parameter Descriptions

    System Parameter Descriptions System Parameter Setting Description Allows the user to initiate a test through the REMOTE INPUT on the rear panel of the tester. If PLC Remote = ON the front panel TEST button is PLC Remote ON/OFF disabled and a test may only be started through the rear panel I/O. If PLC Remote = OFF, the test must be initiated via the front panel TEST button.

  • Page 17: Using The Display

    EDIT PLC REMOTE SETTINGS START Home screen. Turn the yellow rotary knob to When PLC is selected. Press the scroll to PLC to edit the PLC rotary knob to enter the PLC settings. settings. The options will blink. Turn the rotary knob to change Press the rotary knob to select You will be returned to the the PLC settings: ON or OFF.

  • Page 18: Failure Mode Displays

    Failure Mode Displays Failure Mode Display** Description Displayed if the resistance exceeds the metering range. For current range 3.0 – 10.0A (Model 264) 3.0 – 15.0A (Model 266) Displayed if the resistance exceeds the metering range. For current range 10.1 – 30.0A (Model 264) 15.1 –...

  • Page 19: Error Messages

    Error Messages Display Description All of the buttons are not active in this situation. This type of failure permanently locks the tester in the Fatal Error mode and required that the tester be serviced by a SCI authorized service center. Contact the SCI Customer Support Center at 1-800-504- 0055 to receive further instruction.

  • Page 20: Using The Remote I/O

    Using the Remote I/O Two 9-pin “D” type connectors are mounted on the rear panel that provides REMOTE-INPUT-OUTPUT control and information. • These connectors mate with standard 9 pin D-sub-miniature connector provided by the user. • The output mates to a male (plug) connector while the input mates to a female (receptacle) connector. •...

  • Page 21: Signals On Remote I/O

    Signals on Remote I/O REMOTE INPUT/OUTPUT Remote Output Output Signal Pins Description PASS 1 and 2 The relay contact closes after detecting that the device under test passed all tests. The connection is opened when the next test is initiated or the reset function is activated.

  • Page 22: Using The Tester Accessories

    Using the Tester Accessories NEVER CONNECT THE ADAPTER BOX OR TEST LEADS TO THE TESTER WHILE THE HIGH WARNING CURRENT OUTPUTS ARE ENERGIZED. Using the Test Leads RESET TEST RETURN POWER Hook the black return lead 99-10725-01 (Model 264) or 99-10238-01 (Model 266) to the black return terminal on the front panel of the tester.

  • Page 23: Appendix A - Installation And Test Operator Information

    Appendix A - Installation and Test Operator Information Installation 1. Unpacking and Inspection Your tester was shipped in a custom foam insulated container that complies with ASTM D4169-92a Assurance Level II Distribution Cycle 13 Performance Test Sequence. If the shipping carton is damaged, inspect the contents for visible damage such as dents, scratches, or broken meters. If the tester is damaged, notify the carrier and the Slaughter Company customer support department immediately.

  • Page 24: Preparation For Use

    WARNING ONLY ACCESSORIES WHICH MEET THE MANUFACTURER’S SPECIFICATION SHALL BE USED. 4. Preparation for Use Power Requirements and Line Voltage Selection This tester requires a power source of either 100 – 120 / 200 – 240 volts AC ± 10%, 47-63 Hz CAUTION single phase (Model 264) or 100 - 240 volts AC ±10%, 47-63 Hz single phase (Model 266).

  • Page 25: Storage And Shipment

    Storage and Shipment Environment This tester may be stored or shipped in environments with the following limits: Temperature ................-40° - 167° F (-40° - 75°C) Altitude .................. 50,000 feet (15,240 meters) The tester should also be protected against temperature extremes which may cause condensation within the tester. Packaging Contact our customer support department (1-847-932-3662) for an RMA (return materials authorization) number.

  • Page 26: Test Operator And Safety Considerations

    Test Operator and Safety Considerations 1. Qualifications This tester generates voltages and currents which can cause harmful or fatal electric shock and must only be operated by a skilled worker trained in its use. The operator should understand the electrical fundamentals of voltage, current, and resistance. 2.

  • Page 27: Test Station

    6. Test Station Location Select an area away from the main stream of activity which employees do not walk through in performing their normal duties. If this is not practical because of production line flow, then the area should be roped off and marked for HIGH CURRENT TESTING.

  • Page 28: Appendix B - 260 Series Tester Specifications

    Appendix B - 260 Series Tester Specifications Why use the term “Counts”? Slaughter publishes some specifications using COUNTS which allows us to provide a better indication of the tester’s capabilities across measurement ranges. A COUNT refers to the lowest resolution of the display for a given measurement range. For example, if the resolution for voltage is 1V then 2 counts = 2V.
  • Page 29 Memory 5 memories, All memories are linkable Security Run Only Mode (RUN) - To avoid unauthorized access to test parameters and memory locations. Memory Mode (MEM)- Allows access to memory locations but restricts any changes in test parameters. Line Cord Detachable 6 ft.
  • Page 30 Model 266 Functional Specifications Unless otherwise stated, accuracy’s are relative to a laboratory standard measurement. INPUT Voltage 100 - 240V ± 10% variation Frequency 50 / 60 Hz ± 5% Fuse 12A / 250V AC Slow Blow GROUND BOND TEST MODE Output Voltage Range: 12 V AC, Fixed...
  • Page 31 Line Cord Detachable 6 ft. (1.8 m) power cable terminated in a three-prong grounding plug. Terminations 6 ft. (1.8 m) ground bond test and return leads (2) with clips. An optional remote receptacle box may be purchased for testing items terminated with a line cord. International receptacles are also available.

  • Page 32: Appendix C - 264/266 Options

    Appendix C - 264/266 Options Introduction This section contains a list and descriptions of available factory installed options at the time of this printing. The list of options contains an option code number which can be referenced on the model option label on the rear panel of the unit when options are present.
  • Page 33 Optional Rear Outputs This section contains a list and descriptions of available factory installed options at the time of this printing. The list of options contains an option code number which can be referenced on the model option label on the rear panel of the unit when options are present.
  • Page 34 Model 264 SETTINGS Offset Range: 0.00 – 4.00 VAC Resolution: 0.01 V Accuracy: ± (2% of setting + 2 count) Hi and LO-Limit Volt Range: 0.00 – 6.00 V AC (3.0 - 40.0 A) Resolution: 0.01 V Accuracy: ± (2%of setting + 2 count) Dwell Timer Range: 0, 0.5 - 240.0 sec...
  • Page 35 Optional Additional Parameter Description Adjust the high limit setting for the applied voltage. Displayed if the voltage exceeds the high limit trip setting, but do not exceed the metering range. Displayed if the voltage does not exceed the low limit setting. Optional Updated BUS Commands The following commands are used to create or modify Test Setup at each Memory Locations.
  • Page 36 Optional Updated Query Commands These query commands will retrieve data from the tester. These commands include functions for retrieving test data, test results and remote hardware. Command Name Value List Testing Data Data from test in Process RD <memory location>? Result Data Query by memory location List Step Parameters...

  • Page 37: Appendix D - Remote Bus Interface: Usb

    Appendix D - Remote BUS Interface: USB This section provides information on the proper use and configuration of bus remote interface. The USB remote interface is optional on all 260 models. Please see the OPTIONS section of the manual for details. USB Interface This interface provides all of the control commands and parameter setting commands.
  • Page 38 Memory Location Edits and Companion Queries The following commands are used to create or modify Test Setup at each Memory Locations. Command Description Value FL <memory location number> Load Test Located at Memory location number = 1-5 Memory Location Query Memory Location Add GND Test With Default Parameters...
  • Page 39 Test Parameter Editing Commands These commands are used to modify the test parameter within each memory. These commands require a parameter value to be included with the command. The companion query command will read the parameter. The writing of the parameter requires that the unit not be included with the value, only the numeric value should be included with the command.
  • Page 40 Query Commands These query commands will retrieve data from the tester. These commands include functions for retrieving test data, test results and remote hardware. Command Name Value List Testing Data Data from test in Process RD <memory location>? Result Data Query by memory location Read Reset Query 1=Open, 0=Closed...
  • Page 41 IEEE 488.2 Common Commands These commands are required by the IEEE-488.2 standard with the exception of *PSC, *PSC?. Most of these commands are not available over the RS-232 bus except for the *IDN? command which can be used to retrieve the tester identification information, and the four status reporting commands *ESR?, *ESE, *ESE? and *STB?.
  • Page 42 *IDN? - Read the tester identification string. Company =SLA. *RST - Reset the tester to original power on configuration. Does not clear Enable register for Standard Summary Status or Standard Event Registers. Does not clear the output queue. Does not clear the power-on-status-clear flag. *TST? - Performs a self test of the tester data memory.

  • Page 43: Appendix E - Replacement Parts List - Model 264/266

    Appendix E - Replacement Parts List - Model 264/266 Part Number Reference Description Designator Supplied Accessories 99-10040-01 Interlock Connector 99-10783-01 Fuse 10A Slow-Blow 20mm 99-10791-01 Fuse 12A Slow-Blow 30mm 99-10724-01 Cable Assembly High Current Red 99-10725-01 Cable Assembly High Current Black 99-10239-01 Cable Assembly High Current Red 99-10238-01...

  • Page 44: Appendix F - Service And Maintenance

    Appendix F - Service and Maintenance User Service To prevent electric shock do not remove the tester cover. There are no user serviceable parts inside. Routine maintenance or cleaning of internal parts is not necessary. Any external cleaning should be done with a clean dry or slightly damp cloth. Avoid the use of cleaning agents or chemicals to prevent any foreign liquid from entering the cabinet through ventilation holes or damaging controls and switches, also some chemicals may damage plastic parts or lettering.

  • Page 45: Appendix G - Calibration Procedure

    Appendix G – Calibration Procedure This tester has been fully calibrated at the factory in accordance to our published specifications. It has been Calibrated using standards with accuracies traceable to the National Institute of Standards and Technology (NIST). You will find in this manual a copy of the “Certificate of Calibration”.
  • Page 46 3. To calibrate Ground Bond test current Please connect the standard 40A AC Ammeter across the CURRENT and RETURN connectors of the tester. Rotate the yellow knob until the display shows: Then press the TEST button on the front panel. The tester will generate an output of about 40 A and the display will show: Then the display will show a value around 40 A.
  • Page 47 2. To calibrate Ground Bond test voltage Please connect a standard 12V AC Voltmeter across the CURRENT and RETURN connectors of the tester. Rotate the yellow knob until the display shows: Then press the TEST button on the front panel. The tester will generate an output of about 12 VAC and the display will show: Then the display will show a value around 12 Volts.
