7. OPTIONS

Introduction
This section contains a list and descriptions of available factory installed options at the
time of this printing. The list of options contains an option code number that can be
referenced on the data plate on the rear panel of the unit.
Option Label
On the rear panel of the instrument, you will find a label that contains the option code.
For example, your options code would appear as follows:
Fitted with option 04 ...............................................
Fitted with option 01and04......................................
HYAMP III Options
Option List
Description
02 Continuous Output with PASS Buzzer
The Continuous Output with PASS Buzzer option allows the user to perform multiple
Ground Bond tests without the need to repeatedly energize and de-energize the
output. All of the standard specifications for output ratings are the same as in the
standard instrument. The operation of the failure judgment and the FAIL indication
are the fundamental differences in the operation of the instrument.
To make the best use of the Continuous Output feature, the Dwell timer should be set
to 0.0. If the Dwell timer is set to any value other than 0.0 s, the test results will be
captured when the timer has completed until the test is restarted.
To start the Ground Bond test, the TEST button on the front panel can be pressed
with the test leads connected or disconnected from the DUT. Once the test leads are
connected to the DUT and the measured resistance is less than the Max Lmt setting
and greater than the Min Lmt setting, the instrument will indicate a PASS condition. A
PASS condition is represented by an audible alarm and the illumination of the green
PASS light on the front panel.
When continuity is broken, the instrument measures a resistance value greater than
the Max-Limit setting, or lower than the Min Lmt setting, the red FAIL indicator will
illuminate and the alarm will turn OFF. The FAIL condition will remain until the
CODE DESCRIPTION
02 Continuous Output with PASS
Buzzer
04 PLC Power Indicator
05 External RS-232 Converter
