Summary of Contents for IKONIX TVB-2
- Page 1 TVB-2 INSTRUCTION SHEET Test Verification Box RoHS 3 COMPLIANT 39372 | V 1.10 | 04.2024 2015/863/EU...
-
Page 2: Declaration Of Conformity
Lead (Pb), Mercury (Hg), Cadmium (Cd), Hexavalent chromium (Cr (VI)), Polybrominated biphenyls (PBB), Polybrominated diphenyl ethers (PBDE), Bisphthalate (DEHP), Dibutyl phthalate (DBP), Benzyl butyl phthalate (BBP), Diisobutyl phthalate (DIBP), Deca-BDE included. The technical file and other documentation are on file with Ikonix. Adam Braverman President... -
Page 3: Specifications
TVB-2 Instruction Sheet TVB-2 Technical Specifications MODEL TVB-2 COMPONENTS RESISTOR SPECIFICATION 120kΩ 2.5KVAC / 50W / 1% ± 50ppm 1MΩ 3KVDC / 3W / 1% ± 50ppm 0.5Ω 350VDC / 2W / 5% ± 300ppm 49mΩ 100VDC / 50W / 1% ± 50ppm 100mΩ... - Page 4 Using the TVB-2 The TVB-2 load box consists of resistors of varying types that induce a PASS or FAIL condition depending on the test parameters that are set in your electrical safety tester. The 8 banana jacks located on the top of the box can be used to apply the corresponding load to the output of your tester.
- Page 5 Connect the high current lead from the Sense + and CURRENT terminals on the instrument to the PASS/FAIL terminal under the GC terminals on the TVB-2 box. Connect the return black alligator clip lead from the Sense and RETURN terminals on the instrument to the RETURN post on the TVB-2 box.
- Page 6 Continuous Power Limitations - See Specifications Connect the high voltage lead from instrument HV terminal to the PASS/FAIL terminal on the IR terminals on the TVB-2 box. Connect the return black alligator clip lead from the Sense – and RETURN terminals on the instrument to the RETURN post on the TVB-2 box.
- Page 7 Recommended Test Parameter Conditions The following table illustrates the resistor values and recommended test parameter settings for each type of test. Pay close attention to the duty cycle limitations in the specifications in order to avoid damaging the TVB-2 load box. PASS/FAIL Post...
-
Page 8: Maintenance
TVB-2 Instruction Sheet MAINTENANCE: To prevent electric shock do not remove the instrument cover. There are no user serviceable parts inside. Routine maintenance or cleaning of internal parts is not necessary. Any external cleaning should be done with a clean dry or slightly damp cloth. Avoid the use of cleaning agents or chemicals to prevent damage plastic parts or lettering.
