Name
7. Recording type
8. Time moment
9. Timeline bar
10. Audio control
11. Control playback
To play back recorded video:
1. Select the date and click the
timeline.
2. Click Play to start playback. While playing back a video, the timeline bar displays
the type and time of the recording. The timeline can be manually scrolled using the
mouse.
Note: You must have playback permission to play back recorded images. See
"Modify user information" on page 69 for more information.
3. Select the date and click the
4. Click to search the video file.
5. In the pop-up window, check the box of the video file and click
download the video files.
To archive a recorded video segment during playback:
1. While playing back a recorded file, click
clipping. A video segment is created.
2. Repeat step 1 to create additional segments. The video segments are saved on
your computer.
TruVision Series 4 IP Camera Configuration Manual
Description
Enable digital zoom.
Capture a snapshot image of the playback video.
Start/Stop clipping video files.
The color code displays the recording type. Recording types are
schedule recording, alarms recording and manual recording.
The recording type name is also displayed in the current status
window.
Vertical bar shows the current position within the playback
recording. The current time and date are also displayed.
The timeline bar displays the 24-hour period of the day being
played back. It moves left (oldest) to right (newest). The bar is
color-coded to display the type of recording.
Click a location on the timeline to move the cursor to where you
want playback to start. The timeline can also be scrolled to
earlier or later periods for play back.
Click to zoom out/in on the timeline bar.
Control level of audio.
Click to control how the selected file is played back: play, stop,
slow, and fast forward playback.
Search button. The searched video is displayed in the
Search button to search for the required recorded file.
to start clipping. Click it again to stop
Download to
