- Page 1 TruVision Outdoor IP Cameras Quick Start Guide P/N 1072588A-EN • REV 1.0 • ISS 27AUG12...
- Page 2 © 2012 UTC Fire & Security. All rights reserved. Copyright See www.interlogix.com or Contact www.utcfssecurityproducts.eu. information...
-
Page 3: Table Of Contents
Network and streaming configuration 9 Specifications 11 Introduction This pocket guide provides basic information on installing the TruVision Outdoor IP dome and bullet cameras. For detailed information on installing and using the cameras, please refer to the user manual. -
Page 4: Installation Environment
User manual Quick start guide CD with user manual and TruVision Device Finder. Installation environment Refer to the user manual for detailed information. Camera descriptions Figure 1: Outdoor IP dome cameras 1. Video output interface 2. LINK LED: The yellow LED is lit when the network is connected. -
Page 5: Setting Up The Camera
3. Mount the camera on the mounting surface using the appropriate fasteners. 4. Set up the camera’s network and streaming parameters so that the camera can be controlled over the network. 5. Program the camera to suit its location. TruVision Outdoor IP Cameras 5 EN... -
Page 6: Connecting The Devices
2. Ethernet RJ45 PoE port: Connect to network devices. Accessing the SDHC card Insert an SDHC card up to 32GB for local storage in the dome cameras (see Figure 1, item 5). The card is not supplied with the camera. EN 6 TruVision Outdoor IP Cameras... -
Page 7: Accessing The Camera Over The Internet
Video and log files stored on the SDHC card can only be accessed via the Web browser. You cannot access the card using TruVision Navigator or a recording device. Note: There is no SDHC card slot in the bullet cameras. -
Page 8: Overview Of The Camera Web Browser
Viewer Click to view live or play back video. Current user Displays current user logged on. Exit Click to log out from the system. Full screen Click to view as full screen. EN 8 TruVision Outdoor IP Cameras... -
Page 9: Network And Streaming Configuration
Refer to the User Manual for detailed information on configuring the cameras. See Table 1 on page 10 for an overview of the configuration parameters. Note: The On-screen display (OSD) menus are in English only. TruVision Outdoor IP Cameras 9 EN... - Page 10 HDD management Defines how to format the SDHC card used in the camera. Remote upgrade Defines how to upgrade the camera’s firmware. Default Restores default settings. Reboot device Reboots the camera. EN 10 TruVision Outdoor IP Cameras...
-
Page 11: Specifications
