- Page 1 TruVision HD-TVI Series 4 PTZ Dome Camera Configuration Manual P/N 1073207-EN • REV C • ISS 03FEB17...
- Page 2 Copyright © 2017 United Technologies Corporation. Interlogix is part of UTC Climate, Controls & Security, a unit of United Technologies Corporation. All rights reserved. Trademarks and Trade names used in this document may be trademarks or registered patents trademarks of the manufacturers or vendors of the respective products.
-
Page 3: Table Of Contents
Content Introduction 2 HD-TVI 1080P Non-IR Dome Cameras 2 HD-TVI 1080P IR Dome Cameras 2 Programming 3 Call up the camera OSD menu 3 Menu tree 4 Configuration 5 System Info 5 Dome Settings 5 System Settings 5 Camera Settings 8 Motion Parameter 11 Presets 12 Preset Tour 13... -
Page 4: Introduction
Introduction This is the configuration manual for following camera models: HD-TVI 1080P Non-IR Dome Cameras TVP-2401 (30X, Pendant /Wall mount, PAL) TVP-2402 (30X, Surface/Flush mount, PAL) TVP-4401 (30X, Pendant /Wall mount, NTSC) TVP-4402 (30X, Surface/Flush mount, NTSC) HD-TVI 1080P IR Dome Cameras ... -
Page 5: Programming
Programming Once the camera hardware has been installed, the camera can be configured using a HD-TVI DVR menu. You can also configure the camera settings via a DVR. Select the PTZ protocol TruVision Coax and click the menu button to call up the menu. Call up the camera OSD menu To set up the camera: 1. -
Page 6: Menu Tree
Menu tree The menu tree of the TruVision 1080P HD-TVI PTZ domes is shown below. TruVision HD-TVI Series 4 PTZ Dome Camera Configuration Manual... -
Page 7: Configuration
Note: As TruVision recorders do not support an address greater than 255, a soft address greater than 255 will not support any protocol even though the camera supports 8190 for UTC-RS485 (Interlogix-Protocol) and 512 for DIGIPLEX and ASCII. However, you can have an address greater than 255 for legacy products that supports UTC-RS-485 (Interlogix-Protocol), DIGIPLEX or ASCII. - Page 8 SET SOFT BAUD ON: The soft baud rate is the valid baud rate for the HD-TVI PTZ dome. Select 2400, 4800, 9600 or 19200. OFF: Use the DIP switch to set the baud rate. BROADCAST When set to ON, the control device with address 0 can control all ADDR domes connected to it.
- Page 9 P/T ANGLE ON: Enable the on screen display of P/T angle. OFF: Disable the on screen display of P/T angle. 2: The P/T angle will display on screen for 2 seconds. 5: The P/T angle will display on screen for 5 seconds.
-
Page 10: Camera Settings
PRESET FOCUS ON: Enable the preset direct focus function to also record the focus (F) value. OFF: Disable the preset direct focus function. PROTOCOL ON: The user-defined protocol is enabled. ENABLE OFF: The user-defined protocol is disabled. PROTOCOL Define the protocol: RS-485, PELCO-P, PELCO-D, DIGIPLEX, or ASCII. - Page 11 ZOOM LIMIT Set the user-defined limitation of the zoom amount. Zoom amount = Optical zoom× Digital zoom. If you set the zoom limit to its minimum value (22), digital zoom is disabled and optical zoom is at maximum value. If you set a lower zoom limit, digital zoom is enabled.
- Page 12 lower the amount of light entering per second, and the darker the image. Set the value to 1, 2, 4, 8, 15, 30, 50, 125, 180, 250, 500, 1000, 2000, 4000 or 10000. Note: The value of X indicates that the shutter speed is 1/X second. GAIN Gain value: The gain value is the amplification degree of the original...
-
Page 13: Motion Parameter
Note: This function is not supported by all PTZ dome cameras. CHROMA ON: Suppress color noise to obtain clear and high-quality images in SUPPRESS low light conditions. OFF: Disable the function. SATURATION Saturation indicates the brightness of the color. The higher the saturation, the brighter the color. -
Page 14: Presets
PARK TIME This is a period of inactivity after which the PTZ dome automatically starts a predefined action. Set it between 5 and 720 seconds. PARK This is a predefined action. It can be set as presets 1-8, shadow tours 1-5, preset tours1-10, pan scan, tilt scan, panoramic scan, day mode, night mode or none. -
Page 15: Preset Tour
If the preset has been defined, the preset label is displayed under the number. If it has not been defined, UNDEFINED is displayed under the number. SET PRESET Set the desired scene/position of the preset. CLEAR Clear the preset settings. Preset Tour A sequence of user-defined presets stored in the system memory and recalled when required, either upon an alarm trigger, when programmed, or on manual... -
Page 16: Timing Task
CLEAR PRESET Delete the current patrol. TOUR PRESET TOUR-D This is the time to switch from one preset to another. Select 5 s, 10 s, 20 s, 30 s, or 60 s. Timing Task A timing task is a preconfigured action that can be performed automatically at a specific date and time. -
Page 17: Shadow Tour
Shadow Tour A shadow tour is a recording of a user-defined movement of a PTZ dome camera. A shadow tour can be stored and replayed. SHADOW TOUR Select a shadow tour number between 1 and 5. EDIT SHADOW Use this menu to record a shadow tour. TOUR Click the PTZ control and directional buttons to operate the PTZ dome to draw a path, including pan scan, tilt scan, zoom in, zoom... -
Page 18: Alarm Input
Note: Occasionally portions of the masked area may be visible when quick pan- tilt-zoom commands are executed. It is recommended that privacy mask regions are configured to extend past the boundaries of the protected area to avoid inadvertent exposure. MASK NO. The privacy mask number, which ranges from 1 to 24. - Page 19 ALARM INPUT RESUME SEQUENCE DELAY TIME ALARM SETTING BACK EXIT RESUME ON: Enable the PTZ dome to resume its previous activity after the triggered actions finished. OFF: Disable the PTZ dome to resume its previous activity after the triggered actions finished. Note: ...
-
Page 20: Alarm Output
ALARM SETTING ALARM NO. PRIORITY HIGH LINK NONE ALARM OUTPUT NONE ALARM INPUT OPEN BACK EXIT Alarm Output An alarm output is a configurable alarm output interface on the PTZ dome back box which can connect and trigger another alarm device to operate. ALARM OUTPUT Set the alarm output type as OPEN (normally open) or CLOSE (normally closed). -
Page 21: Video Setting
ZONE NO. Select a zone number ranging between 1 and 8. <UNDEFINED> This is the zone label. If the zone has been defined, the zone label is displayed under the number. If it has not been defined, UNDEFINED is displayed under the number. EDIT ZONE Follow the prompts to set the left and right limits. -
Page 22: Restore Camera
When the zoom rate is less than the zoom limit, the IR switches to the near/medium-distance IR LED. LED CONTROL Set the LED control. Select one of the options: ON: Enable all IR LEDs ON: Enable long-distance IR LEDs NEAR ON: Enable near/medium-distance IR LEDs AUTO: Enable IR LED automatically depending on the light conditions...
