Parameter
Scene Mode
Video Standard
Capture Mode
10. Other
Local Output
Note: Click the Default

OSD (On Screen Display)

In addition to the camera name, the camera also displays the system date and time on
screen. You can also define how the text appears on screen.
To position the date/time and name on screen:
1. From the menu toolbar, click
2. Check the Display Name
modify the default name in the text box of
3. Check the Display Date
4. Check the Display Week
display.
5. In the Camera Name
6. Select the time and date formats from the
TruVision Series 4 IP Camera Configuration Manual
Description
Choose the scene as indoor or outdoor according to the current
environment.
50 Hz and 60 Hz are selectable. Choose according to the different
video standards; normally 50 Hz for PAL standard and 60 Hz for
NTSC standard.
Set the desired frame rate to meet the different demands of field of
view and resolution. A higher frame rate may be required in a
location with a lot of movement (such as a money depot).
Select ON or OFF to enable or disable the BNC output. Default is
ON.
button to default all the image settings.
Configuration
box to display the camera's name on screen. You can
box to display the date/time on screen.
box to include the day of the week in the on-screen
box, enter the camera name.
> Image > OSD
Camera Name.
Time format and Date format
Settings.
list boxes.
29
