Interlogix TruVision 4 IP Series Configuration Manual page 20

Inner authentication
Anonymous identity
EAPOL version
CA certificate
Protocol
Identify
Private Key Password
EAPOL version
CA certificate
4. Click Save to save changes.
Note: The switch or router to which the camera is connected must support the IEEE
802.1X standard, and a server must be configured. Please apply and register a user
name and password for 802.1X in the server.
To define the QoS parameters:
1. From the menu toolbar, click
2. Configure the QoS settings, including Video / Audio DSCP, Event / Alarm DSCP
and Management DSCP. The valid value range of the DSCP is 0-63. The bigger the
DSCP value, the higher the priority.
3. Click Save to save changes.
To define the FTP parameters:
1. You must have an FTP server configured and available on the network in order to
use the FTP feature
2. From the menu toolbar, click
3. Configure the FTP settings, including server address, port, user name, password,
directory, and upload type.
Anonymous: Check the checkbox to enable the anonymous access to the FTP
server.
Directory: In the Directory Structure field, you can select the root directory, Main
directory and Subdirectory. When the Main directory is selected, you have the
option to use the Device Name, Device Number or Device IP for the name of the
18
MS-CHAPv2 - Microsoft Challenge-Handshake Authentication
Protocol version 2, defined in RFC 2759.
GTC - Generic Token Card, used when an automated device
generates ASCII data to input for authentication.
EAP - Extensible Authentication Protocol, defined in RFC 3748 and
RFC 5247.
Used so the authenticator can choose the correct authentication
server, with the actual identity sent in a second exchange (ex:
anonymous@test.com).
Indicate the version (1 or 2) that is being used; affects the format of
the exchange with the RADIUS server.
This should be obtained from the network administrator, as network
policies may differ.
EAP-TLS
Obtain this information from the network administrator, if any.
This should also be requested from the network administrator.
Indicate the version (1 or 2) that is being used; changes the format of
the exchange.
This should be obtained from the network administrator, as network
policies may differ.
Configuration
Configuration
> Network > QoS.
> Network > FTP.
TruVision Series 4 IP Camera Configuration Manual
