4 How to Install

4.3.5 Terminal Locations - Frame size D

Take the following terminal positions into consideration when you design for cable access.
4
Figure 4.12: Terminal locations D6 - filter
Figure 4.13: Terminal locations D6 - drive
Be aware that the power cables are heavy and hard to bend. Give thought to the optimum position of the adjustable frequency drive for ensuring easy
installation of the cables.
