VLT AQUA Low Harmonic Drive Instruction
Manual
6.1.3 Q1 My Personal Menu
Parameters defined by the user can be stored in Q1 My Personal Menu.
My Personal Menu
Select to display only the parameters, which have been pre-selected and programmed as personal parameters. For example, a pump
or equipment OEM may have pre-programmed these to be in My Personal Menu during factory commissioning to make on-site commissioning / fine tuning
simpler. These parameters are selected in par. 0-25
20-21 Setpoint 1
20-93 PID Proportional Gain
20-94 PID Integral Time
6.1.4 Q2 Quick Set-up
The parameters in Q2 Quick Set-up are the basic parameters which are always needed to set up the adjustable frequency drive for operation.
Parameter number and name
0-01 Language
1-20 Motor Power
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
3-41 Ramp 1 Ramp-up Time
3-42 Ramp 1 Ramp-down Time
4-11 Motor Speed Low Limit
4-13 Motor Speed High Limit
1-29 Automatic Motor Adaptation (AMA)
My Personal Menu . Up to 20 different parameters can be defined in this menu.
Q1 My Personal Menu
Q2 Quick Set-up
Unit
kW
V
Hz
A
RPM
s
s
RPM
RPM
®
