Application Examples > Automatic Motor Adaptation
See section:
6.3.4 3-0* Reference Limits
Parameters for setting the reference unit, limits and ranges.
3-02 Minimum Reference
Range:
Application [Application dependant]
dependent*
3-03 Maximum Reference
Range:
Application [Application dependant]
dependent*
3-10 Preset Reference
Array [8]
Range:
0.00 %* [-100.00 - 100.00 %]
in the Design Guide.
Function:
Enter the Minimum Reference. The Minimum Reference is the lowest value obtainable by adding all
references together. The Minimum Reference value and unit matches the configuration choice made
Configuration Mode
in par. 1-00 and par. 20-12
NOTE!
This parameter is used in open-loop only.
Function:
Enter the maximum acceptable value for the remote reference. The Maximum Reference value and
unit matches the configuration choice made in par. 1-00
erence/Feedback Unit , respectively.
NOTE!
If operating with par. 1-00
Maximum Reference/Feedb.
par. 20-14
Function:
®
MG.20.T1.22 - VLT is a registered Danfoss trademark
6 How to Program the Low Harmonic Drive
Reference/Feedback Unit
, respectively.
Configuration Mode
Configuration Mode set for Closed-loop [3],
must be used.
6
and par. 20-12 Ref-
6-17
