6 How to Program the Low Harmonic Drive
[1682] Serial com. bus REF 1
[1684] Comm. Option STW
[1685] ADF Port CTW 1
[1686] AFD Port REF 1
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1696] Maintenance Word
[1830] Analog Input X42/1
6 [1831] Analog Input X42/3
[1832] Analog Input X42/5
[1833] Analog Out X42/7 [V]
[1834] Analog Out X42/9 [V]
[1835] Analog Out X42/11 [V]
[2117] Ext. 1 Reference [Unit]
[2118] Ext. 1 Feedback [Unit]
[2119] Ext. 1 Output [%]
[2137] Ext. 2 Reference [Unit]
[2138] Ext. 2 Feedback [Unit]
[2139] Ext. 2 Output [%]
[2157] Ext. 3 Reference [Unit]
[2158] Ext. 3 Feedback [Unit]
[2159] Ext. Output [%]
[2230] No-Flow Power
[2580] Cascade Status
[2581] Pump Status
[2791] Cascade Reference
[2792] % Of Total Capacity
[2793] Cascade Option Status
0-21 Display Line 1.2 Small
Option:
[1662] * Analog input 53
0-22 Display Line 1.3 Small
Option:
[1614] * Motor Current
6-12
Main reference value sent with control word via the serial communications network, e.g., from the
BMS, PLC or other master controller.
Extended serial communication option status word.
Control word (CTW) received from the bus master.
Status word (STW) sent to the bus master.
One or more alarms in a Hex code (used for serial communications)
One or more alarms in a Hex code (used for serial communications)
One or more warnings in a Hex code (used for serial communications)
One or more warnings in a Hex code (used for serial communications)
One or more status conditions in a Hex code (used for serial communications)
One or more status conditions in a Hex code (used for serial communications)
The bits reflect the status for the preventive maintenance events programmed in parameter group
23-1*
Shows the value of the signal applied to terminal X42/1 on the Analog I/O card.
Shows the value of the signal applied to terminal X42/3 on the Analog I/O card.
Shows the value of the signal applied to terminal X42/5 on the Analog I/O card.
Shows the value of the signal applied to terminal X42/7 on the Analog I/O card.
Shows the value of the signal applied to terminal X42/9 on the Analog I/O card.
Shows the value of the signal applied to terminal X42/11 on the Analog I/O card.
The value of the reference for extended Closed-loop Controller 1
The value of the feedback signal for extended Closed-loop Controller 1
The value of the output from extended Closed-loop Controller 1
The value of the reference for extended Closed-loop Controller 2
The value of the feedback signal for extended Closed-loop Controller 2
The value of the output from extended Closed-loop Controller 2
The value of the reference for extended Closed-loop Controller 3
The value of the feedback signal for extended Closed-loop Controller 3
The value of the output from extended Closed-loop Controller 3
The calculated No-Flow Power for the actual operating speed
Status for the operation of the cascade controller
Status for the operation of each individual pump controlled by the cascade controller
Reference output for use with follower drives.
Readout parameter to show the system operating point as a % capacity of total system capacity.
Readout parameter to show the status of the cascade system.
Function:
Select a variable for display in line 1, middle position.
The options are the same as those listed for par. 0-20
Function:
Select a variable for display in line 1, right position.
The options are the same as those listed for par. 0-20
®
