NOTE!
Note the plinth is provided in the same packaging as the adjustable frequency drive but is not attached to frame size F during shipment.
The plinth is required to allow airflow to the drive to provide proper cooling. The F frames should be positioned on top of the plinth in
the final installation location. The angle from the top of the drive to the lifting cable should be 60° or greater.
In addition to the drawing above, a spreader bar is an acceptable way to lift the F frame.
NOTE!
The F size will be shipped as 2 pieces. Instructions on how to assemble the pieces can be found in the "Mechanical Installation" chapter.
®
