6.3.6 5-** Digital In/Out
Parameter group for configuring the digital input and output.
5-01 Terminal 27 Mode
Option:
[0] * Input
[1] Output
Please note that this parameter cannot be adjusted while the motor is running.
6.3.7 5-1* Digital Inputs
Parameters for configuring the input functions for the input terminals.
The digital inputs are used for selecting various functions in the adjustable frequency drive. All digital inputs can be set to the following functions:
Digital input function
No operation
Reset
Coast inverse
Coast and reset inverse
DC brake inverse
Stop inverse
External interlock
Start
Latched start
Reversing
Start reversing
Jog
Preset reference on
Preset ref bit 0
Preset ref bit 1
Preset ref bit 2
Freeze reference
Freeze output
Speed up
Slow
Set-up select bit 0
Set-up select bit 1
Pulse input
Ramp bit 0
Line failure inverse
Run Permissive
Hand start
Auto-start
DigiPot Increase
DigiPot Decrease
DigiPot Clear
Counter A (up)
Counter A (down)
Reset Counter A
Counter B (up)
Counter B (down)
Reset Counter B
Sleep Mode
Reset Maintenance Word
Lead Pump Start
Lead Pump Alternation
Pump 1 Interlock
Pump 2 Interlock
Pump 3 Interlock
All = Terminals 18, 19, 27, 29, 32, X30/2, X30/3, X30/4. X30/ are the terminals on MCB 101.
Function:
Defines terminal 27 as a digital input.
Defines terminal 27 as a digital output.
Select
[0]
[1]
[2]
[3]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[32]
[34]
[36]
[52]
[53]
[54]
[55]
[56]
[57]
[60]
[61]
[62]
[63]
[64]
[65]
[66]
[78]
[120]
[121]
[130]
[131]
[132]
®
