Danfoss VLT AQUA Drive FC 200 Instruction Manual page 196

VLT AQUA Low Harmonic Drive Instruction
Manual
No. Description
1 10 Volts low
2 Live zero error
4 Mains phase loss
5 DC link voltage high
6 DC link voltage low
7 DC overvoltage
8 DC undervoltage
13 Overcurrent
14 Ground fault
15 Hardware mismatch
16 Short Circuit
17 Control word timeout
23 Internal Fan Fault
24 External Fan Fault
29 Heatsink temp
33 Inrush fault
34 Fieldbus fault
35 Option fault
38 Internal fault
39 Heatsink sensor
40 Overload of Digital Output Terminal 27
41 Overload of Digital Output Terminal 29
42 Overload of Digital Output On X30/6
42 Overload of Digital Output On X30/7
46 Pwr. card supply
47 24 V supply low
48 1.8 V supply low
65 Control Board Over-temperature
66 Heatsink Temperature Low
67 Option Configuration has Changed
68 Safe Stop Activated
69 Pwr. Card Temp
70 Illegal FC configuration
72 Dangerous Failure
73 Safe Stop Aut Re
76 Pwr Unit Setup
79 Ill. PS config
80 Drive Initialized to Default Value
244 Heatsink temp
245 Heatsink sensor
246 Pwr.card supply
247 Pwr.card temp
248 Illegal PS config
250 New spare part
251 New Type Code
300 Line Power Cont. fault
301 SC Cont. Fault
302 Cap. Overcurrent
303 Cap. Ground Fault
304 DC Overcurrent
305 Line Power Freq. Limit
306 Compensation Limit
308 Resistor temp
309 L-Pwr Grnd Fa
311 Switch. Freq. Limit
312 CT Range
314 Auto CT Interrupt
315 Auto CT Error
316 CT Location Error
317 CT Polarity Error
318 CT Ratio Error
Table 9.4: Alarm/Warning code list
A trip is the action when an alarm has appeared. The trip will coast the motor and can be reset by pressing the reset button or make a reset by a digital
input (Par. 5-1* [1]). The original event that caused an alarm cannot damage the adjustable frequency drive or cause dangerous conditions. A trip lock
is an action that occurs in conjunction with an alarm, which may cause damage to the adjustable frequency drive or connected parts. A trip lock situation
can only be reset by power cycling.
