9.2.1 Fault messages
WARNING 1, 10 volts low
The control card voltage is below 10 V from terminal 50.
Remove some of the load from terminal 50, as the 10 V supply is over-
loaded. Max. 15 mA or minimum 590 Ω.
WARNING/ALARM 2, Live zero error
The signal on terminal 53 or 54 is less than 50% of the value set in par.
6-10, 6-12, 6-20 or 6-22 respectively.
WARNING/ALARM 4, Mains phase loss
A phase is missing on the supply side, or the line voltage imbalance is too
high.
WARNING 5, DC link voltage high
The intermediate circuit voltage (DC) is higher than the high voltage
warning limit. The unit is still active.
WARNING 6, DC link voltage low
The intermediate circuit voltage (DC) is below the undervoltage limit of
the control system. The unit is still active.
WARNING/ALARM 7, DC overvoltage
If the intermediate circuit voltage exceeds the limit, the unit trips.
WARNING/ALARM 8, DC undervoltage
If the intermediate circuit voltage (DC) drops below the undervoltage
limit, the adjustable frequency drive checks if a 24 V backup supply is
connected. If not, the unit trips. Make sure the AC line voltage matches
the nameplate specification.
WARNING/ALARM 13, Overcurrent
the unit current limit has been exceeded.
ALARM 14, Ground fault
There is a discharge from the output phases to ground. Turn off the unit
and correct the ground fault.
ALARM 15, Incomp. Hardware
A mounted option is not handled by the present control card SW/HW.
ALARM 16, Short circuit
There is a short-circuit in the output. Turn off the unit and correct the
error.
WARNING/ALARM 17, Control word timeout
There is no communication to the unit.
The warning will only be active when par. 8-04
Function
is NOT set to OFF.
Possible correction: Increase par. 8-03. Change par. 8-04
WARNING 23, Internal fan fault
Internal fans have failed due to defect hardware or fans not mounted.
WARNING 24, External fan fault
External fans have failed due to defect hardware or fans not mounted.
ALARM 29, Heatsink temp
The maximum temperature of the heatsink has been exceeded. The tem-
perature fault will not be reset until the temperature falls below a defined
heatsink temperature.
ALARM 33, Inrush fault
Check whether a 24 Volt external DC supply has been connected.
WARNING/ALARM 34, Fieldbus communication fault
The serial communication bus on the communication option card is not
working.
WARNING/ALARM 35, Option Fault:
Contact your supplier.
ALARM 38, Internal fault
Contact your Danfoss supplier.
ALARM 39, Heatsink sensor
No feedback from the heatsink temperature sensor.
WARNING 40, Overload of Digital Output Terminal 27
Check the load connected to terminal 27 or remove short-circuit connec-
tion.
WARNING 41, Overload of Digital Output Terminal 29
Check the load connected to terminal 29 or remove short-circuit connec-
tion.
WARNING 42, Overload of Digital Output on X30/6 or Overload
of Digital Output on X30/7
For X30/6, check the load connected to X30/6 or remove short-circuit
connection.
For X30/7, check the load connected to X30/7 or remove short-circuit
connection.
WARNING 43, Ext. Supply (option)
The external 24 V DC supply voltage on the option is not valid.
ALARM 46, Power card supply
The supply on the power card is out of range.
WARNING 47, 24 V supply low
Contact your Danfoss supplier.
WARNING 48, 1.8 V supply low
Contact your Danfoss supplier.
WARNING/ALARM/TRIP 65, Control card overtemperature
Control card overtemperature: The cutout temperature of the control
card is 176°F [80°C].
WARNING 66, Heatsink temperature low
Control Word Timeout
This warning is based on the temperature sensor in the IGBT module.
Troubleshooting:
The heatsink temperature measured as 32°F [0°C] could indicate that the
temperature sensor is defective causing the fan speed to increase to the
maximum. If the sensor wire between the IGBT and the gate drive card
is disconnected, this warning would result. Also, check the IGBT thermal
sensor.
ALARM 67, Option module configuration has changed
One or more options have either been added or removed since the last
power-down.
®
MG.20.T1.22 - VLT
is a registered Danfoss trademark
9 Troubleshooting
