6.3.12 Water Application Functions, 29-**
The group contains parameters used for monitoring water/wastewater applications.
29-00 Pipe Fill Enable
Option:
[0] * Disabled
[1] Enabled
29-01 Pipe Fill Speed [RPM]
Range:
Speed Low [Speed Low Limit - Speed High Lim-
Limit* it]
29-02 Pipe Fill Speed [Hz]
Range:
Motor [Speed Low Limit - Speed High Lim-
Speed Low it]
Limit*
29-03 Pipe Fill Time
Range:
0 s* [0–3600 s]
29-04 Pipe Fill Rate
Range:
0.001 units/ [0.001–999999.999 units/s]
s*
29-05 Filled Setpoint
Range:
0 s* [0–999999,999 s]
Function:
Select Enabled to fill pipes at a user-specified rate.
Select Enabled to fill pipes with a user specified rate.
Function:
Set the filling speed for filling horizontal pipe systems. The speed can be selected in Hz or RPM
depending on the choices made in par. 4-11 / par. 4-13 (RPM) or in par. 4-12 / par. 4-14 (Hz).
Function:
Set the filling speed for filling horizontal pipe systems. The speed can be selected in Hz or RPM
depending on the choices made in par. 4-11 / par. 4-13 (RPM) or in par. 4-12 / par. 4-14 (Hz).
Function:
Set the specified time for pipe filling of horizontal pipe systems.
Function:
Specifies the filling rate in units/second using the PI controller. Filling rate units are feedback units/
second. This function is used for filling vertical pipe systems but will be active when the filling time
has expired, no matter what, until the pipe fill setpoint set in par. 29-05 is reached.
Function:
Specifies the filled setpoint at which the pipe fill function will be disabled and the PID controller will
take control. This function can be used both for horizontal and vertical pipe systems.
®
