Danfoss VLT AQUA Drive FC 200 Instruction Manual page 68

VLT AQUA Low Harmonic Drive Instruction
Manual
Frame size
F
Table 4.13: Safety Relay Coil Fuse with PILS Relay
4.6.15 Line Power Disconnectors - Frame Size D, E and F
Frame size
D
E
E
F
F
4.6.16 F Frame circuit breakers
Frame size
F
F
4.6.17 F Frame Line Power Contactors
Frame size
F
F
4.6.18 Motor Insulation
For motor cable lengths ≤ than the maximum cable length listed in the
General Specifications tables, the following motor insulation ratings are
recommended because the peak voltage can be up to twice the DC link
voltage, 2.8 times the AC line voltage due to transmission line effects in
the motor cable. If a motor has lower insulation rating, it is recommended
to use a du/dt or sine-wave filter.
Bussmann PN*
LP-CC-6
Power & Voltage
P160-P250 380–480 V
P315 380–480 V
P355-P450 380–480 V
P500 380–480 V
P560-P710 380–480 V
Power & Voltage
P500 380–480 V
P560-P710 380–480 V
Power & Voltage
P500-P560 380–480 V
P 630-P710 380–480 V
®
MG.20.T1.22 - VLT is a registered Danfoss trademark
Rating
6 A, 600 V
Type
OT400U12-91
ABB OETL-NF600A
ABB OETL-NF800A
Merlin Gerin NPJF36000S12AAYP
Merlin Gerin NRK36000S20AAYP
Type
Merlin Gerin NPJF36120U31AABSCYP
Merlin Gerin NRJF36200U31AABSCYP
Type
Eaton XTCE650N22A
Eaton XTCEC14P22B
Nominal AC Line Voltage Motor Insulation
≤ 420 V
U Standard U
N
≤ 500 V
420 V < U Reinforced U
N
4 How to Install
Alternative Fuses
Any listed Class CC, 6 A
= 1300 V
LL
= 1600 V
LL
4-51
4
