a) Use two-prong shield wires to connect Analog terminals.
b) Connect DUT. Refer to
method. To ensure the safety of the test, use a separate red and black
test line to connect the input terminals of each instrument to the
terminals of the object to be tested.
2. After the wiring is completed as shown above, configure one module (CH1)
as Master and the other modules (CH3, CH5) as Slave.
Shift
a) Press +
▼ ▼
key to select < Parallel Set >, press
>NOP
Enter
b) Press
Master Select
□7□5□3□1
Enter Esc
c) Press the number key 1 to select CH1 module as the master, and
Enter
press the
Master Select
□7□5□3□Y
Enter Esc
d) Press the number keys 3 and 5 to select CH3 and CH5 modules as
slaves, and press the
Slave Select
□7□Y□Y□□
Enter Esc
e) After the master-slave is configured, the interface is displayed as
follows.
>Group CH01
NOP
3. After making the master-slave setting, to ensure normal operation, you
need to restart the electronic loads.
Copyright © Itech Electronic Co., Ltd.
1.6 Connecting the DUT
4 4
(System) keys to enter system menu function, press
key.
key to confirm.
Enter
key to confirm.
Operations introduction
for detailed wiring
Enter
key to confirm.
