Enter
press
key to confirm
Tran A Width
0.003S
▼ ▼
9.
Press
key to enter B level setting <TRANb>， such as 2.00A， press
Enter
key to confirm
Transition
B
Level = 2.00A
▼ ▼
10. Press
key to enter B level width setting <Tb>，such as 0.002S，
Enter
press
key to confirm
Tran. B Width=
0.002S
▼ ▼
11. Press
key to set transient operation mode <Tmode>，such as
continuous mode, press
CH01
>Continuous
Pulse
Toggle
Esc
Esc
12. Press
key to exit
4 4
Shift
13. Press
+
to select <Trigger source>，such as select <Manual> on the front panel,
Enter
press
key to confirm
Manual
External
Hold
Bus
Timer
Esc
Esc
14. press
key to confirm.
On/Off
On/Off
15. Press
to open the load's input.
Tran
Tran
16. Press
to enable transient operation.
Trig
Trig
17. Press
key to trigger.
If in the remote control mode（USB / RS232 / Ether-net） ，you can refer to the
following example to edit transient operation(refer to IT8700 programming
guide to get more).
CURRent:TRANsient:MODE CONTinous
CURRent:TRANsient:ALEVel 5
CURRent:TRANsient:AWIDth 0.6mS
CURRent:TRANsent:BLEVel 10
CURRent:TRANsient:BWIDth 0.7mS
TRANsient ON
TRIGger:IMMediate
NOTE
The transient function of IT8700P+ series load supports CC mode only.
Copyright © Itech Electronic Co., Ltd.
Enter
key to confirm
keys to enter system menu function, press
Operations introduction
▼ ▼
key
