ITech IT8700P+ Series User Manual page 38

Vd=0.000V
CV Rate
∫=2.500A/uS
∫=2.500A/uS
TRAN a=0.00A
Ta=0.0005S
TRAN b=0.00A
Tb=0.0005S
Tmode

Setup menu list of IT8731P+/IT8732P+/IT8733P+/IT8732BP+/IT8733BP+/
IT8722P+/IT8722BP+/IT8723P+:
Setup
MODE
CC/CV RANGE
I / V / R /
Vmax/Amax
Vmin/Amin
Alim
Vd=0.000V
CV Rate
∫=2.500A/uS
∫=2.500A/uS
TRAN a=0.00A
Ta=0.0005S
TRAN b=0.00A
Tb=0.0005S
Tmode
Configuration menu
Press

Configure menu list of IT8732B/IT8733/IT8733B/IT8731/IT8732/IT8722/
IT8723/IT8722B module:
MENU
SYNC ON SET
ON〈DEFAULT〉
OFF
VON
VON POINT
VON LATCH
EXIT
Set the break-over voltage value( Only for CR-LED mode)
Set CV loop speed. (Only for CV mode)
Set the up slope (only CC mode available)
Set the down slope(only CC mode available)
Setup level A value
Setup level A width
Setup level B value
Setup level B width
Setup the transient mode
Continuous
Pulse
Toggle
Select working mode
Const Current
Const Voltage
Const Resistance
Const Power
Switch the range
High Range
Middle Rang
Low Range
Pset Set the working current/voltage/resistance value
Setup the maximum voltage value/maximum current value
Setup the minimum voltage value/minimum current value
Set limited current value under CV/CR/CW mode.
Set the break-over voltage value( Only for CR-LED mode)
Set CV loop speed. (Only for CV mode)
Set the up slope (only CC mode available)
Set the down slope(only CC mode available)
Setup level A value
Setup level A width
Setup level B value
Setup level B width
Setup the transient mode
Continuous
Pulse
Toggle
5 5
Shift Shift
+ key to enter the channel configuration menu
Setup Synchronization ON / OFF function
Turn on synchronization function
Turn off synchronization function
Set the load's von point
Von point latch state, ON /OFF
Copyright © Itech Electronic Co., Ltd.
Continuous mode
Pulse mode
Toggle mode
Load works in CC mode
Load works in CV mode
Load works in CR mode
Load works in CW mode
(only CC mode available)
Continuous mode
Pulse mode
Toggle mode
Panel function introduction
29
