in location 1. Press
saved earlier

3.1.5 Configuration menu introduction

Details on each channel menu function. For example, if you don't want the 3
channel to work with other channels synchronously, you can switch to channel
3 on the main frame, press
VFD views <SYNC ON SET> ，press
the same method to setup other functions in the configuration menu.

3.1.6 Module keyboard lock

Press
and knobs of the current channel panel, press
unlock.

3.2 Module operation

IT8700 modules have 2 kinds input: one is single input module and the other is
dual-input module. There are 6 keys and a knob on the front panel for each
module. Below are the detail introduction of module panel keys and functions.

3.2.1 Single channel module panel

Fig 3-2 single channel module panel
Module's panel view ： high-brightness VFD display show module 's
1.
working mode.
2. Module's panel keyboard:
Button
Switch A/B transient preset value
A/B A/B
Re call Re call
key to recall, and then press key 1 to recall the file
Shift Shift
8 8
Shift
+ key to lock the Short、 Tran、 Mode、 On/Off operation keyboard
Copyright © Itech Electronic Co., Ltd.
5 5
+ key to enter module configuration menu,
Enter Enter
key to enter, setup OFF state. In
Description
Panel function introduction
8 8
Shift Shift
+ key again to
