Easy Entry™ User's Guide
DOOR STRIKE
From the Status List, present your card to the reader. Once it is validated by the system,
the Door Strike relay activates. If you are entering an armed area which you are assigned,
accessing the area will automatically cause it to be disarmed.
While the keypad is in the Status List, present your access card. The relay activates momentarily
during which you must open the door. Once you open the door, you have 30 seconds to exit and
close the door before the zone 2 Soft-Shunt expires.
ARMING AND DISARMING AN AREA SYSTEM
Press Command. The keypad displays ARM
Select key under either option. The keypad displays ENTER CODE: -.
Present your card to the reader. Once it is validated by the system,
all areas accessible by you arm or disarm automatically. Select NO to
arm or disarm individual areas. Select YES, or simply wait, and the
keypad will automatically arm or disarm all areas for which you are
authorized.
DISARMING WITH ENTRY DELAY
Once the protected door is opened and the entry delay starts, the keypad displays
ENTER CODE: -. Present your card to the reader. Once it is validated, the system
disarms all areas accessible by you. Area systems provide a delay to allow selected
areas only to be disarmed. See Arming and Disarming above.
Using the access reader for user menu access
You can also use a card reader to access the User Menu when the MENU? NO YES
display is shown and a code is requested.
Appendix C
Appendix C
ABC SECURITY
DISARM. Press the
ARM
POWER
XR200 User's Guide
ABC SECURITY
DISARM
ENTER CODE: –
POWER
ABC SECURITY
ALL?
NO
YES
POWER
43
