- Page 1 User’s Guide XR40...
-
Page 2: Silencing An Alarm
© 1999 - 2006 Digital Monitoring Products, Inc. Information furnished by DMP is believed to be accurate and reliable. This information is subject to change without notice. The XR40 panel is UL listed for Grade A Household Service and Commercial Burglary Service. -
Page 3: Table Of Contents
Security Command User’s Guide ™ for XR40 Command Processor™ Panels Table of Contents Section Page Section Page Silencing an Alarm......Inside Front Cover User Menu ...............20 Accessing the User Menu ..........20 Introduction ..............1 User Menu Options............20 About Your Security System ..........1 User Check-in.............. - Page 4 Supervisory Event Displays ..........36 System Monitor Event Displays........36 Wireless Jamming Event Displays ........36 Wireless Trouble Event Displays........36 Appendix B ..............37 DMP Wireless Description ..........37 Appendix C ..............38 Easy Entry™ User’s Guide ..........38 XR40 User’s Guide...
-
Page 5: Introduction
Security Security Command™ system operation. Command™ can protect both the interior and perimeter of your home or business while you are away or just the perimeter when Note: There may be a 30-second alarm communication delay you are inside giving you a wall of security and peace of mind. -
Page 6: Emergency Evacuation Plans
A fire alarm system installation, with smoke and carbon authorities. Never enter a building to look for someone. monoxide detectors in each room, can greatly decrease your risk of loss or injury. XR40 User’s Guide... -
Page 7: Dmp Keypads
� � • Thinline™ or Aqualite™ Keypads • Clear Touch™ Keypads ����������� � � � � � Security Command™, Thinline™, Aqualite™ Keypads � � � � � � � � �� � �� � � � � � � �... - Page 8 The Back Arrow (<—) key is used to go back through the keypad displays while operating your system. You can press the Back Arrow Touch Select Areas key to back up through the list of functions in the User Menu or to erase the last character you entered. XR40 User’s Guide Introduction...
- Page 9 Security Command™, Thinline™, Aqualite™ Keypads Security Command™ Keypad Panic Keys 7/0 Panic Function Security Command™, Thinline™, and Aqualite™ Keypads may also be programmed at installation to allow the user to initiate an optional Top Row Select Keys Panic alarm by simultaneously pressing and holding the 7 and 0 (zero) keys.
-
Page 10: 32-Character User Options
Select key to make the tone lower. Use best fit your environment and needs. the right Select key to make the tone higher. On Security Command™, Thinline™, or Aqualite™ keypads to Volume level access the User Options portion of the keypad, press and hold the Back Arrow and COMMAND keys for two seconds. -
Page 11: Special Security Command™ Displays
Special Security Command™ Displays Burglary alert: A siren tone from LCD keypads only that continues until the alarm is silenced. This is in addition to the bell output As you use your system, you may occasionally see a keypad display from the alarm panel. -
Page 12: Special Wireless Displays
For example, the windows on the east side of the premises programmed for wireless interference detection and, if displayed, can all be grouped together in a zone named E. WINDOWS. your wireless receiver has detected an interfering signal while the system is disarmed. XR40 User’s Guide Introduction... -
Page 13: Instant Zone
Also, for keypads that include an Armed LED, the Armed LED is ON steady anytime a burglary protection area is armed and OFF when ALL areas are disarmed. Introduction XR40 User’s Guide... -
Page 14: Dmp Wireless
For best operation, allow the LED to turn on and then turn off before pressing another button. The key fob may not complete sending the signal for the button press if another button is pressed too soon. XR40 User’s Guide Introduction... -
Page 15: How Your System Operates
Regardless of which mode is programmed, much of the operation is similar. Throughout this guide, any differences between the systems are noted for your convenience. Introduction XR40 User’s Guide... -
Page 16: Arming And Disarming
For All/Perimeter systems the keypad briefly displays ALL SYSTEM make sure the door is securely closed. ON if all areas in the system are arming or PERIMETER ON if only selected areas are arming. XR40 User’s Guide Arming and Disarming... -
Page 17: Key Fob Arming
(Arm/Disarm) button. A Green LED two-second acknowledgement indicates All System Off. Note: Disarming authority needs to be enabled for the User Code assigned to the Key Fob. Refer to Adding User Codes later in this document. Arming and Disarming XR40 User’s Guide... -
Page 18: Arming The System
The keypad sounds the exit delay alert when 20 prior to arming and any faulted 24 hour zones. No action is seconds remain, and when the delay expires, all zones are required. armed. XR40 User’s Guide Arming and Disarming... -
Page 19: Area System Disarming
3 below. through an exit/entry delay door without causing an alarm. After opening the door, the Security Command keypad sounds a prewarn 2. Select DISARM to disarm areas. tone to remind you to disarm the system. You must disarm the 3. -
Page 20: All/Perimeter System Arming
PERIMETER ON for perimeter arming and ALL SYSTEM ON for perimeter and interior arming. 2. Select PERIM to arm the Perimeter area only. 3. Select ALL to arm both the Perimeter and Interior areas. XR40 User’s Guide Arming and Disarming... -
Page 21: All/Perimeter System Disarming
CODE:. Enter your user code. premises through an entry/exit delay door without causing an alarm. After opening the door, the Security Command™ keypad The keypad displays any zones that went into alarm and any sounds a prewarn tone to remind you to disarm the system. You... -
Page 22: Home/Away System Arming
4. Select AWAY to arm the Perimeter, Interior, and Bedroom. 5. The keypad displays zones that have been bypassed prior to arming and zones that are in a faulted condition. No action is required by you. XR40 User’s Guide Arming and Disarming... -
Page 23: Home/Away System Disarming
This feature SILENCE to only turn off the alarm bells. allows you to get the paper, let your pet out, or leave for work without having to disarm and then rearm the system. Arming and Disarming XR40 User’s Guide... -
Page 24: User Menu
Many of your system features have been put into a User Menu that ZONE MONITOR Allows you to add or remove a zone from you can access from any Security Command™ keypad. The menu the monitor mode. requires you to enter your user code. Only those functions to which... -
Page 25: User Check-In
Activity Check Disabled message to the central station. 3. When YES is selected, the keypad displays CHECK ENABLED for four seconds and then sends the Activity Check Enabled message to the central station. User Menu XR40 User’s Guide... -
Page 26: Sensor Reset
To exit the Output menu option, press the Back Arrow key until you Note: This feature only operates on All/Perimeter or Home/Away return to the keypad Status List. systems. This also activates the door strike if your system has an Easy Entry™ access control keypad. XR40 User’s Guide User Menu... -
Page 27: Bypass Zones
5. To Bypass a zone, enter the zone number and Select BYPS. system. The keypad should beep to confirm their operation. If at any time during your weekly testing a device does not cause the keypad to beep, call the service department for assistance. User Menu XR40 User’s Guide... -
Page 28: Using The Zone Monitor Function
See step 7. mode. This allows you to open and then close each protected door and window while listening for the keypad to beep confirming its operation. See Zone Monitor. XR40 User’s Guide User Menu... -
Page 29: User Codes
Note: A User Code cannot begin with zero and cannot be left Zone Monitor blank. System Test User Codes Users enter only their own user code when operating the system. Schedules Extend Set Time Display Events Service Request? User Menu XR40 User’s Guide... -
Page 30: Adding User Codes
(1 to 250) that the temporary use code can operate. Default is seven days. Temporary users are deleted from the system at 12:00 AM on the last day. You can delete a Temporary user code at any time before the programmed period ends. XR40 User’s Guide User Menu... -
Page 31: Ambush Code
Ambush. If your system is programmed they are still user number 2. for Ambush and you expect to use the Ambush function, the code you enter for user number 1 is the Ambush code. User Menu XR40 User’s Guide... -
Page 32: Schedules
6. To clear a schedule, press DELETE and then AM when the and always occur at the same time until you change or delete opening time is requested. Press the Back Arrow key to exit them. the User Menu. XR40 User’s Guide User Menu... -
Page 33: Extending Schedules
4. At the OUTPUT NO: – display, enter the output number you want to program. Press the COMMAND key. 5. The keypad displays SUN MON TUE WED. Press the COMMAND key to display THU FRI SAT. User Menu XR40 User’s Guide... -
Page 34: Date And Time
Press COMMAND. assistance. YEAR: - Enter up to two digits for the year. Press COMMAND. The display returns to TIME DAY DATE. Press the Back Arrow key to exit the User Menu. Display Events XR40 User’s Guide User Menu... -
Page 35: System Setup
Your system is monitored by a central station. r Yes r No r Yes r No Your system sends Abort reports. C/S Name: _____________________________________________ r Yes r No Address: _______________________________________________ City/State: _____________________________________________ Emergency Phone: _______________________________________ Service Phone: __________________________________________ Service Manager: ________________________________________ System Setup XR40 User’s Guide... -
Page 36: Protection Areas
As you add new users or change current user codes, you can keep track of their name, user number, and other information here in this section. Use a pencil to allow for changes in the table on the next page. XR40 User’s Guide System Setup... - Page 37 1 2 3 4 * Master (MST) Standard (STD) 1 2 3 4 Limited (LTD) Scheduled (SCH) 1 2 3 4 (Photocopy this page before using.) 1 2 3 4 Circle Your Selections System Setup XR40 User’s Guide...
-
Page 38: Appendix A
Any event older than 45 system to bypass a zone. days automatically clears from the system memory. Once the full 140 events are reached, any new event received clears the oldest event from the list. XR40 User’s Guide Appendix... -
Page 39: Zone Event Displays
FLT - Zone Fault SVC - Service Smoke Detector feature at 3:31 PM on Oct. 17. CHECKIN USER: 16 LOW - Low battery MIS - Missing wireless transmitter Note: LOW and MIS are for wireless systems only. Appendix XR40 User’s Guide... -
Page 40: User Code Change Event Displays
RST - Restore on October 17. AC POWER System Monitor Event Types - There are two event types: TBL - Trouble RST - Restore System Monitor Event Names - There are two system monitors: AC POWER BATTERY XR40 User’s Guide Appendix... -
Page 41: Appendix B
LED Color Duration Description 2.0 Seconds All System On Green 2.0 Seconds All System Off System On Green/Red 2.0 Seconds (Some Areas Armed) When a button is pressed that is not programmed, the LED does not operate. Appendix XR40 User’s Guide... -
Page 42: Appendix C
The keypad displays for All/Perimeter or Home/Away operation are dependent on how your keypad was programmed by your alarm dealer. Easy Entry™ is built into every Security Command ™... - Page 43 See Arming and Disarming above and on the previous page. Using the access reader for user menu access You can also use a card reader to access the User Menu when MENU? NO YES displays. Appendix XR40 User’s Guide...
-
Page 44: Appendix D
Zone Type Event Area Name Zone Types - BURG, FIRE, SUPV (Supervisory), PANC (Panic), EMRG (Emergency), AUX1, or AUX2 2. ________________________ 4. _________________________ Events - ALARM or TROUBLE The Security Command™ keypads emit a single beep to confirm the arming. XR40 User’s Guide Appendix... -
Page 45: Phoneaccess™ User's Guide
User’s Guide. keypad. This exciting feature allows you to call your XR40 system from any 4. Once the user code is accepted by the panel and the outside touch-tone phone to arm and disarm protection areas or armed status is given, you can enter arming and disarming turn panel relay outputs on or off. -
Page 46: Common Keypad Displays
The panel is unable to communicate with the wireless receiver. Verify the receiver is properly connected to the panel. WIRELESS TROUBLE Verify the correct House Code is programmed in System Options. The wireless receiver is missing. XR40 User’s Guide Appendix... -
Page 47: Index
How Your System Operates 11 Key Fob 13 Zone Bypass 34 Arming/Disarming Event Display 35 Zone Event 35 Instant Arming 16 DMP Wireless 10, 37 Instant Zone 9 Backlighting 6 Back Arrow (<—) Key 4 Easy Entry™ User’s Guide 38 Index XR40 User’s Guide... - Page 48 Changing 27 Output 29 Volume 6 Deleting 27 Permanent 28 Wireless Displays 8 Table 33 Security Command™ Keypad 1, 3 Key Fob 10, 32, 37 User Menu Options 20, 25 Arming 13 7/0 Panic Function 5 Button Layout 11 Displays 7...
-
Page 49: Quick Reference Wallet Cards
4 short beeps = restricted area arms. Use outputs 1, 2, 3, or 4 in place of n. Enter output descriptions below. Security Command™ 1. ________________________ 3. _________________________ Numeric Paging 2. ________________________ 4. _________________________ Cut along dotted lines. -
Page 50: Account Number
Account Number You will hear All areas are armed 3 short beeps This number is programmed into your Security Command™ Area 1 (Perimeter) is armed 1 short beep system as an identifier. Whenever the system sends a Any area is armed... - Page 51 .This page intentionally left blank.
