Zone Status Browser
Access the User Menu. Press
ZONE STATUS?
COMMAND until ZONE
STATUS appears.
Press any SELECT key then
ARM BYPS ALR NBR
press the SELECT key under
NBR.
Press one of the left two
ZONE NO: -
SELECT keys to browse
through the names of zones.
SELECT ZONE . . .
When the correct zone name is
EAST DOOR
displayed, press any SELECT key.
Verify the zone number matches
ZONE NO : 0 1 2
the previously shown name.
Press COMMAND.
The system displays one of these
EAST DOOR - OKAY
zone status messages:
-OKAY = the zone is normal
-BYPAS = the zone is bypassed
-BAD O = the zone is open
-BAD S = the zone is shorted
Appendix B
This prompt allows you to search
SELECT AREA . . .
for a zone by area. Press the
COMMAND key to scroll through
the list of areas.
COMMAN
D
When the area where the zone is
FRONT OFFICE
located is displayed, press any
SELECT key.
COMMAN
D
After all the areas are
24 HOUR ZONES
displayed, the system allows
you to search through the 24
hour zones (Fire, Panic,
COMMAN
D
Supervisory, etc.).
SELECT ZONE . . .
Press the COMMAND key to scroll
through the list of all zone names.
COMMAN
COMMAN
D
D
When the correct zone name is
HALL SMOKE
displayed, press any SELECT key.
Verify the zone number matches
ZONE NO : 0 3 4
the previously shown name.
Press COMMAND.
COMMAND
COMMAN
D
The system displays one of these
HALL SMOKE - OKAY
zone status messages:
-OKAY = the zone is normal
Pressing COMMAND
-BYPAS = the zone is bypassed
COMMAND
COMMAN
allows you to enter
D
-BAD O = the zone is open
another zone number.
-BAD S = the zone is shorted
Appendix B
Bypass Zones Browser
Access the User Menu. Press
COMMAND until BYPASS ZONES
appears. Press any SELECT key.
Press either of the two left SELECT
keys.
This prompt allows you to search for a
zone by area. Press the COMMAND
key to scroll through the list of areas.
When the area where the zone is
located is displayed, press any SELECT
key.
The display shows the zone number.
Press the SELECT key under RST to
Reset the zone. Press the SELECT key
under BYP to Bypass the zone.
XR200 User's Guide
BYPASS ZONES?
ZONE: -
RST BYP
SELECT AREA . . .
COMMAN
D
FRONT OFFICE
Press the COMMAND key to scroll
SELECT ZONE . . .
through the list of all zone names.
COMMAN
D
When the correct zone name is
EAST DOOR
displayed, press any SELECT key.
ZONE:012 RST BYP
RST BYP The display returns to the ZONE:
ZONE: -
prompt allowing you to enter
another zone number.
39
