Zone Status Displays
Below is a list of the zone status displays:
-OKAY = the zone is in a normal condition
-BYPAS = the zone is bypassed
-FAULTED = the zone is in a bad or faulted condition
9. After displaying the zone status, ZONE: - returns for you to
enter another zone number.
Browser Feature
If you are unsure of the zone number or description, refer to
Appendix B at the back of this guide for a diagram showing you how
to use the built-in Zone Status browser.
18

Bypass Zones

User Code Level: 6 and above.
Function: Allows you to bypass a zone prior to arming.
Bypassing is usually done when a zone cannot be restored to
normal. A zone can be bypassed only while it is disarmed. Because
Þ re, panic, emergency, and supervisory type zones are always
armed, they can never be bypassed.
Bypass Zones can also be used to reset a zone that has been
bypassed and restore it back into the system. This can only be
done while the zone is dis armed.
When Bypass Zones is selected, a report can be transmit ted to your
central station.
Using the Bypass Zones Function
1. Access the User Menu.
2. Press COMMAND until BYPASS ZONES? displays.
3. Press any
ZONE: - RST BYPS.
4. To Bypass a zone, enter the zone number and select BYPS.
The zone number automatically disappears and a new zone
number can be entered. Refer back to step 3.
5. To Reset a zone, enter the zone number and select RST.
Browser Feature
If you are unsure of the zone number or description, refer to
Appendix B at the back of this guide for a diagram showing you how
to use the built-in Bypass Zones browser.
XR200 User's Guide
Select key. The keypad displays
User Menu
