7 Installing OP delivery arm
Steps
7.6 Connecting water and air tubes
About this task
34
Planmeca Compact i3
1. Place the cover plug over the operating light opening on the delivery arm
so that the fastening screw hits opening on the cover plug.
Before connecting the air and water tubes make sure that you have correctly
identified the floor tubes. Even when they are already labelled it is good to
double-check them.
Installation manual
