Inside patient area:
1. Dental unit
2. Planmeca monitor
3. Planmeca operating light
4. Foot control. Use only IEC 60601-1 approved
power source supplied by Planmeca
5. Tablet
6. Planmeca intraoral scanner

2.7 Fire stopping of installation site

Installation manual
NOTE
The pipe and cable penetrations must be sealed with fire stopping materials.
The products given in this section are only examples.
The fire stopping must be performed in accordance with the national
regulations.
NOTE
Follow the fire stopping products' installation instructions.
Add fire stopping laminate or mastic (e.g. Intumex LF, Intumex MG) to the
pipes as shown in the figure below.
2 Pre-installation requirements
Outside patient area:
7. External PC
Planmeca Compact i3 11
