Installation manual
3. Move the junction box into position and attach it to the clamp with two
nuts.
4. Loosen two magnetic valve/pressure regulator assembly attachment
screws (1) and lift the assembly from its position (2).
5 Installing junction box
Planmeca Compact i3
17
