Page 1 Planmeca Sovereign Classic ® user's manual 10032652...
Page 2 IEC 60364 - equipment is used according to the operating instructions. Planmeca pursues a policy of continual product development. Although every effort is made to produce up-to-date product documentation this publication should not be regarded as an infallible guide to current specifications. We reserve the right to make changes without prior notice.
Page 3: Table Of Contents
Planmeca Romexis connection....................28 8.11 Planmeca ProX X-ray unit......................29 8.12 Planmeca intraoral scanner......................30 8.13 Zeiss OPMI pico microscope......................31 Planmeca Solanna and Planmeca Solanna Vision operating lights............32 Instrument system............................ 33 10.1 Over-the-Patient (OP) delivery arm....................33 10.2 Instrument console........................34 10.2.1 Instrument console with balanced instrument arms.............
Page 4 Transferring user settings......................94 18.5.1 Transferring user settings to USB................94 18.5.2 Transferring user settings from USB................95 18.5.3 Transferring user settings to Romexis................. 95 18.5.4 Transferring user settings from Romexis..............96 18.6 Resetting personal settings......................97 Planmeca Sovereign Classic User's manual...
Page 5 Adjustments....................... 117 23.3 Timer............................117 23.4 Door open...........................117 23.5 Assistant call..........................118 23.6 Planmeca Solanna and Planmeca Solanna Vision operating light..........118 23.6.1 Indicator lights......................119 23.6.2 Enabling gesture sensor.................... 121 23.6.3 Switching operating light on/off.................. 121 23.6.4 Switching composite mode on/off................122 23.6.5...
Page 6 LM scaler........................165 24.5.5 EMS No Pain scaler....................165 24.5.6 Instrument light......................165 24.6 Planmeca Lumion Plus polymerisation light................165 24.7 Intraoral camera and Planmeca Romexis.................. 167 24.7.1 Intraoral camera placed in instrument console............167 24.7.2 Intraoral camera placed in suction holder..............169 24.8...
Page 7 26.7.1 Adjusting cup fill and bowl rinse flow rates..............188 26.7.2 Duration of bowl rinsing....................189 26.7.3 Duration of cup filling....................189 26.8 Planmeca Solanna and Planmeca Solanna Vision operating lights........... 191 26.8.1 Intensity........................191 26.8.2 Colour temperature and brightness................192 26.8.3 Gesture sensor......................193 26.9 Door open / assistant call......................
Page 8 EU Declaration of Conformity for PlanID RFID-reader............... 284 35.3 FCC Class B Notice for wireless foot control................284 35.4 FCC Class B Notice for PlanID RFID-reader................284 35.5 Industry Canada (IC) Compliance Statement................285 35.6 Industrie Canada (IC) Déclaration de conformité............... 285 Planmeca Sovereign Classic User's manual...
Page 9 Table of contents 35.7 RF Exposure..........................285 User's manual Planmeca Sovereign Classic...
Page 10 Table of contents Planmeca Sovereign Classic User's manual...
Page 11: Introduction
The Planmeca dental unit is an electrically controlled dental device that consists of a patient chair, cuspidor, delivery arm, dental instruments, operating light and a foot control. The Planmeca dental unit is meant to be used for dental treatment by dental care professionals.
Page 12: Associated Documentation
The intraoral X-ray unit Planmeca ProX can be installed to the Planmeca dental unit. Planmeca ProX is an option that is available in selected market areas. Please contact your local sales representative for details. Planmeca ProX is delivered with the following manuals: •...
Page 13 (30007097). The document can be found in the Planmeca Material bank. Before using an instrument, read the instrument’s user’s manual. For a full list of accessories, refer to the Planmeca product price list. User's manual Planmeca Sovereign Classic...
Page 14: Training
3 Training 3 Training A hands-on user’s training is given in connection with the installation of this device. Planmeca Sovereign Classic User's manual...
Page 15: Registering Your Product
4 Registering your product 4 Registering your product About this task Before you start using your Planmeca product, you must register it to activate the warranty. NOTE As an alternative to navigating to the registration website as described below, you can enter www.planmeca.com/register/...
Page 16: Annual Maintenance
5 Annual maintenance To guarantee the dental unit’s proper operation, the unit must be checked and serviced by a qualified Planmeca service technician according to the maintenance schedule that has been set for your dental unit. In the annual maintenance, the service technician replaces all parts specified by the maintenance kit.
Page 17: Symbols On Product Labels
Type B applied part (Standard IEC 60417). Type BF applied part for specified dental instruments (Standard IEC 60417). Alternating current (Standard IEC 60417) On/Off switch (Standard IEC 60417). Refer to instruction manual/booklet (Standard ISO 7010). General warning (Standard ISO 7010). User's manual Planmeca Sovereign Classic...
Page 18 Strong magnet. Remove the tray mounting arm when treating patients who have a cardiac pacemaker. (Standard ISO 7010.) Planmeca PlanClear is a disinfectant for the water and waterlines. Only put Planmeca PlanClear in the container. The container must be filled with Planmeca approved suction disinfectant.
Page 19 The fuse or main switch must be lockable into off-position. Turning off the unit from its own mains switch DOES NOT cut off the mains voltage from all internal nodes. CAUTION Only connect equipment approved by Planmeca to the multiple socket outlet. User's manual Planmeca Sovereign Classic...
Page 20: For Your Safety
7 For your safety 7.1 Safety precautions WARNING No modification of this dental unit is allowed. WARNING Only instruments or equipment approved by Planmeca may be connected to this dental unit. WARNING Do not simultaneously touch the patient and the PC. WARNING Do not simultaneously touch the patient and the USB ports, or any electrical connectors of external instrument modules.
Page 21 The worm screw securing nut in the chair lift motor must always be attached to the worm screw and must not be removed. If the securing nut is faulty or displaced, immediately stop using the dental unit and contact your Planmeca dealer.
Page 22 CAUTION Make sure that the cup fill tube is always properly in its position by the cup holder. Planmeca Sovereign Classic User's manual...
Page 23 Planmeca dealer. CAUTION When a water leak is detected, help message HE4004 is displayed. Turn off the clinic’s main water tap and contact your Planmeca dealer. CAUTION For surgical procedures, use sterile irrigating solutions, such as sterile water or saline.
Page 24 7 For your safety NOTE If a method such as electro-chemical activation is used to disinfect the dental unit water and waterlines, disinfection with Planmeca PlanClear is not necessary. For more information, please contact your Planmeca dealer. NOTE If using air abrasives, please consult instructions for use given by the air polisher manufacturer.
Page 25: Safety Switches
Remove the obstruction to resume normal operation. 5. OP delivery arm An obstruction between the OP delivery arm and the chair when driving up/down the chair stops up-/downwards chair movements. Remove the obstruction to resume normal operation. User's manual Planmeca Sovereign Classic...
Page 26: Chair Movement Restrictors
Depending on the chair swivel angle, the up-/downwards movements of the chair and backrest might be restricted. Swivel the chair back to its home position to resume normal operation. The home position is presented in section "Chair swivel" on page 55. Planmeca Sovereign Classic User's manual...
Page 27 7 For your safety User's manual Planmeca Sovereign Classic...
Page 28: Planmeca Sovereign Classic Dental Unit
8 Planmeca Sovereign Classic dental unit 8 Planmeca Sovereign Classic dental unit 8.1 Dental unit configurations 8.1.1 Over-the-patient delivery with balanced instrument arms 1. Cuspidor 8. Balanced instrument arms 2. Suction arm 9. Operating light 3. Foot control 10. Over-the-patient (OP) delivery arm 4.
Page 29: Over-The-Patient Delivery With Hanging-Tube Instruments
8 Planmeca Sovereign Classic dental unit 8.1.2 Over-the-patient delivery with hanging-tube instruments 1. Cuspidor 8. Patient chair 2. Suction arm 9. Operating light 3. Foot control 10. Over-the-patient (OP) delivery arm 4. Hanging-tube instruments 11. Monitor 5. Control panel 12. ProX X-ray unit (optional, not available in all market areas) 6.
Page 30 8 Planmeca Sovereign Classic dental unit Balanced instrument arms Headrest The following detachable components are not critical to operation. The user can perform dental treatment even if a wrong, similar part is fitted. Hygienic membrane Top tray (size 1 and 2)
Page 31 8 Planmeca Sovereign Classic dental unit Armrests Instrument flushing holder Suction tube cleaning holder Cup fill tube Bowl, filter and filter cap User's manual Planmeca Sovereign Classic...
Page 32 8 Planmeca Sovereign Classic dental unit Coarse filters Dentist’s instruments and hoses Suction tubes Assistant’s instruments and hoses Planmeca Sovereign Classic User's manual...
Page 33: Applied Parts
8 Planmeca Sovereign Classic dental unit Adapter for Luzzani Minibright syringe Adapter for DCI syringe Water container and cap Foot cover 8.3 Applied parts Applied parts are parts of the dental unit that in normal treatment situations come into contact with the patient.
Page 34 8 Planmeca Sovereign Classic dental unit NOTE Always place the bowl in home position. NOTE Make sure that the bowl is not above the patient chair when you drive the chair upward. The glass bowl is attached to the top of the cuspidor.
Page 35: Monitor
Ensure that the tablet is protected from splashes. NOTE Planmeca is not liable for damages caused to the tablet caused by negligence, including but not limited to dropping the tablet on the floor. The tablet can be charged from the USB port on the cuspidor, see section "USB connectivity"...
Page 36 (either the instrument console or USB port 2) and the port that is selected is linked to the external PC. NOTE Connect only intraoral cameras supplied by Planmeca to the dental unit. Planmeca Sovereign Classic User's manual...
Page 37: Unit Swivel
8 Planmeca Sovereign Classic dental unit 8.8 Unit swivel The Planmeca Sovereign Classic dental unit can be swivelled manually ±120°. Pull the lever on the unit base to unlock the base and swivel the dental unit to the desired position. Lock the base by pushing the lever back in.
Page 38: Water And Air Quick-Connectors
135. 8.10 Planmeca Romexis connection The dental unit must be connected to Planmeca Romexis software when you want to use Planmeca Romexis Clinic Management, the intraoral camera, the touchpad functionality, or sign in with a PlanID card.
Page 39: Planmeca Prox X-Ray Unit
For information on how to use Planmeca Romexis Clinic Management Planmeca Romexis user’s manual . software, see 8.11 Planmeca ProX X-ray unit The Planmeca ProX X-ray unit can be mounted to the dental unit pylon. CAUTION Drive the chair carefully when positioning the ProX X-ray unit. User's manual...
Page 40: Planmeca Intraoral Scanner
Move the ProX X-ray unit behind the pylon when it is not being used. NOTE The Planmeca ProX X-ray unit is an option and is not available in all market areas. For more information about Planmeca ProX, see Planmeca ProX User’s Manual.
Page 41: Zeiss Opmi Pico Microscope
Do not drive the chair when a patient is under the microscope. NOTE The Planmeca Intra X-ray unit and the Zeiss OPMI pico dental microscope can not simultaneously be attached to the dental unit. For more information about Zeiss OPMI pico, see the manufacturer’s own documentation.
Page 42: Planmeca Solanna And Planmeca Solanna Vision Operating Lights
Do not allow the patient to grab the operating light or its arm when getting seated or getting up from the patient chair. You can operate the Planmeca Solanna operating light either from the light itself, or from the dental unit’s control panel or foot control. It also features a “no touch”...
Page 43: Instrument System
The rotation area of the delivery arm, instrument console and the control panel are shown in the illustrations below. The items do not need to be locked into position. The following presents the OP delivery arm with balanced instrument arms. User's manual Planmeca Sovereign Classic...
Page 44: Instrument Console
10.2.1 Instrument console with balanced instrument arms The console can be equipped with up to six dynamic instruments. A special feature of the Planmeca Sovereign Classic dental unit is that the syringe can be right- or leftmounted. Labels mark the positions of the Bien-Air MX2 micromotor, the apex micromotor (Morita TORX), the syringe and the USB-device.
Page 45: Instrument Console With Hanging-Tube Instruments
10.2.2 Instrument console with hanging-tube instruments The console can be equipped with up to six dynamic instruments. A special feature of the Sovereign Classic dental unit is that the syringe can be right- or left-mounted. Labels mark the positions of the Bien-Air MX2 micromotor, the apex micromotor (Morita TORX), the syringe and the USB-device.
Page 46 The instrument holders can be removed by pulling them out from their openings, for example for cleaning. The holders are replaced simply by pushing them firmly into their places. The angle of the instrument holder can be slightly adjusted. Planmeca Sovereign Classic User's manual...
Page 47: Quick-Connector Hoses
10.3 Quick-connector hoses The instruments are equipped with quick-connector hoses to be connected to the instrument console. If a syringe and/or a polymerisation light are placed in the Flexy-holder, they are connected to the cuspidor. User's manual Planmeca Sovereign Classic...
Page 48 Always make sure that the instrument hose is correct for the used instrument. The control system identifies the instrument hose, not the instrument. The control system does not recognise if an instrument has been changed on the instrument hose. Planmeca Sovereign Classic User's manual...
Page 49: Instruments
The tray table is attached to the mounting arm with a magnetic connector and can easily be attached and detached. You can rotate the table 360° to the desired position. The maximum weight limit on the tray is 2 kilograms (4.4 lbs). User's manual Planmeca Sovereign Classic...
Page 50 The tray mounting arm is attached to the instrument console with a quick- connector. The tray assembly can be removed from the instrument console as follows. Pull the ring of the locking mechanism outwards (1) and pull the tray arm away from its position (2). Planmeca Sovereign Classic User's manual...
Page 51: Tray Table For Hanging-Tube Instrument Console
(2) (when the tray table is placed on the left side of the console) or counter-clockwise (when the tray table is placed on the right side of the console). Detach the tray table by pulling the arm out from the instrument console (3). User's manual Planmeca Sovereign Classic...
Page 52: Sterile Water System
The instrument must have an externally mounted spray nozzle on which the sterile water tube is fitted. CAUTION Before using an instrument with sterile water, make sure water comes out from the instrument. Planmeca Sovereign Classic User's manual...
Page 53 Before using sterile water, you need to set up the sterile water system as described below and edit the instrument spray settings so that sterile water is used (see section "Enabling/disabling sterile water mode" on page 182). User's manual Planmeca Sovereign Classic...
Page 54: Setting Up Sterile Water System
Make sure that the sterile water tube is inserted so that water is pumped from the sterile water bag to the instrument. The arrow on the pump indicates the direction of the water flow, away from the bag and toward the instrument. Planmeca Sovereign Classic User's manual...
Page 55 10 Instrument system 4. Close the lid of the pump. 5. Connect the nozzle to the sterile water bag. 6. Route the long end of the tube to the instrument hose. User's manual Planmeca Sovereign Classic...
Page 56 7. Connect the water tube to the instrument by sliding the tube over the externally mounted spray nozzle as shown in the figure below. 8. Balanced instrument arms: Attach the sterile water tube to the instrument hose with small clips provided with the instrument. Planmeca Sovereign Classic User's manual...
Page 57: Adjusting Sterile Water Flow Rate
181. 10.6.4 Adjusting sterile water volume Use the clamp on the sterile water tube to adjust the water volume. Push the slide forward to reduce the volume, and backward to increase the volume. User's manual Planmeca Sovereign Classic...
Page 58: Suction System
USB intraoral camera or a polymerisation light. The picture shows the default positions for the suction handpieces and syringe. To change the positions, please contact a qualified Planmeca service technician. 1. Saliva suction handpiece 2.
Page 59 Remove the suction tube holder by pulling it downward from the Flexy- holder. To replace it, push it firmly into its place. Remove the roller from the suction tube holder by pulling it away from the holder. To replace it, push it firmly into its place. User's manual Planmeca Sovereign Classic...
Page 60 Remove the holder for the intraoral scanner by pressing the trigger (see arrow in picture) and pulling the holder out from the Flexy-holder. To replace the holder for the intraoral scanner, push it firmly into its place. Planmeca Sovereign Classic User's manual...
Page 61: Removing And Replacing Suction Tubes
You can grease the securing ring with non-toxic vaseline to make it easier to remove. 4. Remove the suction tube (2) from the suction tube connector. 5. Replace the suction tubes in the reverse order. User's manual Planmeca Sovereign Classic...
Page 62: Patient Chair
12.1 Introduction The Planmeca Sovereign Classic patient chair is integrated with the floor- mounted unit which gives plenty of room under the chair allowing the dentist and the assistant to move their legs freely while sitting down.
Page 63: Patient Recognition
12.2 Patient recognition A sensor in the patient chair recognises if there is a patient in the chair and forwards information about this to Planmeca Romexis Clinic Management software. When a patient is in the chair, a Patient icon is displayed on the control panel.
Page 64 Support the legrest with your other hand when locking or unlocking it. Notice that the backrest will move upward and downward when the legrest is locked. 1. Approx. 18° from the horizontal position 2. Legrest lock/unlock button Planmeca Sovereign Classic User's manual...
Page 65: Trendelenburg Position
12.5 Chair swivel The patient chair can be swivelled manually. Press either of the buttons on the chair underside (marked with arrows in picture) to release the lock and turn the chair to the desired position. User's manual Planmeca Sovereign Classic...
Page 66: Armrests
12.6 Armrests Both armrests can be moved 90° outwards. Before you move the armrest horizontally you must lift it slightly to unlock it. The armrest can be locked into the positions presented in the picture. Planmeca Sovereign Classic User's manual...
Page 67: Headrest
12 Patient chair 12.7 Headrest 12.7.1 Adjusting height of headrest The height of the headrest can be adjusted by sliding it manually. NOTE The headrest can only be pulled out as far as to the MAX mark. User's manual Planmeca Sovereign Classic...
Page 68: Adjusting Headrest Angle
The headrest can be turned around and repositioned for better head support for children or short patients. Pull the headrest out. Turn it around so that the cushion faces backward and push the headrest back into the chair. Planmeca Sovereign Classic User's manual...
Page 69 12 Patient chair Turn the cushion around (180° counter-clockwise). Press the bar on the side of the headrest support to release the locking mechanism and position the headrest at the top of the chair. User's manual Planmeca Sovereign Classic...
Page 70 The headrest is now repositioned. To adjust the angle of the headrest, press the locking bar. Manually set the headrest into the required position and release the bar. When adjusting, support the headrest with your other hand. Planmeca Sovereign Classic User's manual...
Page 71: Control Panel
13 Control panel 13 Control panel 13.1 Two control panels The Planmeca dental unit has two control panels. The main control panel is located on the instrument console and the other one on the Flexy-holder. 13.2 Control panel on instrument console 13.2.1 Overview...
Page 72 (when the control panel is placed on the left side of the console) until you hear a click (2). CAUTION Ensure that the dental unit works correctly after attaching the control panel. If needed, restart the dental unit. Planmeca Sovereign Classic User's manual...
Page 73: Detaching Control Panel
The control panel shows information related to the current operation and changes accordingly. Some of the buttons have indicator lights that show the status of that specific function. When the unit is in programming mode, the Program button is blue. User's manual Planmeca Sovereign Classic...
Page 74 19. Wireless foot control button to right, display only): (optional) Wireless foot control battery • Container for Planmeca (optional, displayed only if approved suction available) disinfectant • PlanClear container • Bottle water -mode, water container Planmeca Sovereign Classic User's manual...
Page 75: Touchpad Functionality
The touchpad function requires that the dental unit is connected to Planmeca Romexis software. The software version must be 4.1 or later. If there is no Planmeca Romexis connection, the function is disabled and the Touchpad button is grey. Using control panel as computer mouse In the the touchpad-view, press Touchpad to open the mouse-view on the control panel.
Page 76 To return to the normal view without entering a letter, press the symbol again. To display special characters, press Alt. Press Alt again to return to the normal view. Planmeca Sovereign Classic User's manual...
Page 77: Control Panel On Flexy-Holder
• turn Planmeca Solanna Vision video streaming on/off • start/stop Planmeca Solanna Vision video recording • capture an image with the Planmeca Solanna Vision camera • open/close the Planmeca Solanna Vision window. NOTE Sign in window is When you are not signed in to the dental unit and the displayed, pressing the Flexy button signs you in as a guest user.
Page 78: Foot Control
Do not use the foot control in areas where liquids are likely to be present on the floor. NOTE All the foot control functions except instrument drive and manual chip blow can be performed on the control panel, too. Planmeca Sovereign Classic User's manual...
Page 79: Foot Control Pedal
NOTE If you want to change from a standard pedal to the wide pedal, or vice versa, contact your Planmeca dealer. The two foot control pedals function differently. For example, to increase the instrument speed, you must push the standard pedal horizontally, either to the left or to the right.
Page 80 Composite mode Stream on/off (Vision) on/off Manual chip blow Automatic position A Capture image (Vision) Instrument light on/off Automatic position B Recording on/off (Vision) Power limit on/off Automatic position C Change Solanna operating light's light tone Planmeca Sovereign Classic User's manual...
Page 81: Centre Knob Functions
Extended view: Chair to selected automatic position Centre knob up, long activation Chair up Centre knob down Standard view: Chair to automatic position D Extended view: Chair to selected automatic position Centre knob down, long activation Chair down User's manual Planmeca Sovereign Classic...
Page 82: Side Knob Functions
Planmeca Solanna operating light’s composite mode on/off • Activate/deactivate apex locator • Change light tone of operating light • Turn Planmeca Solanna Vision video streaming on/off • Start/stop Planmeca Solanna Vision video recording • Capture image with Planmeca Solanna Vision camera •...
Page 83 Change spray 1 / 2 / OFF • Automatic chip blow on/off • Instrument light on/off • Speed/power limit on/off • Instrument quickstart on/off • Cup fill • Bowl rinse and cup fill • Open/close Planmeca Solanna Vision window User's manual Planmeca Sovereign Classic...
Page 84 Drive chair to selected automatic position • Door open • Operating light on/off • Turn suction on/off • Freeze/unfreeze image • Save still image • Cup fill • Bowl rinse and cup fill • Open/close Planmeca Solanna Vision window Planmeca Sovereign Classic User's manual...
Page 85: Pedal Functions
Open/close Planmeca Solanna Vision window 14.3.4 Pedal functions Possible pedal functions Instrument Function No instrument is activated (idle • None state) • Assistant call • Door open • Cup fill • Bowl rinse and cup fill User's manual Planmeca Sovereign Classic...
Page 86: Factory Default Functions
Left-side knob down No instrument in use: Activate intraoral scanner Micromotor: Open preset list / exit list without selecting preset Intraoral scanner: Deactivate instrument view Right-side knob up Assistant call Right-side knob down Chair to rinsing position Planmeca Sovereign Classic User's manual...
Page 87: Wireless Foot Control
When the wireless foot control has been idle for 2 hours (default value), it goes into sleep mode. To change the value, please contact your Planmeca dealer. You can also put the wireless foot control into sleep mode by pressing the foot control handle.
Page 88 Do not charge the foot control battery while treating a patient. CAUTION The battery charging area must be dry. Do not expose the charger to liquids. NOTE The power supply is marked and specified as a part of the Planmeca dental unit. Planmeca Sovereign Classic User's manual...
Page 89 14 Foot control NOTE The batteries must be replaced only by a qualified Planmeca service technician. NOTE The foot control batteries must be removed whenever the foot control is stored for a longer period. The batteries must be removed only by a qualified Planmeca service technician.
Page 90: Switching Unit On And Off
At start-up, with the exception of start-up during maintenance procedures, instruments and suction tubes have to be in their holders. NOTE After the unit is switched on, it will take a few seconds until the dental unit is ready for use. Planmeca Sovereign Classic User's manual...
Page 91: Standby Mode
You can now sign in to the dental unit. For instructions, see section "Signing in" on page 83. NOTE If the dental unit’s Romexis user logs in to Planmeca Romexis, the dental unit will wake up from the standby mode. User's manual...
Page 92 This feature requires Planmeca Romexis software version 4.5 and Planmeca Romexis Clinic Management. If your dental unit is connected to Planmeca Romexis, it is possible to schedule times when the dental unit or a group of dental units is in standby mode.
Page 93: Signing In And Out
If you have a PlanID card and the dental unit is equipped with a PlanID reader, sign in by showing the PlanID card to the PlanID reader on the instrument console. When the PlanID card is at reading distance, a rotating PlanID symbol shows on the display. User's manual Planmeca Sovereign Classic...
Page 94 Planmeca Romexis and the settings in Planmeca Romexis are newer than the settings on your dental unit, you will be asked whether you want to download the newer settings from Planmeca Romexis when you sign in to the dental unit.
Page 95: Signing Out
When you are signed in to the dental unit, your user name is displayed on the control panel. The Sign out button indicates where the user profile was loaded from: the dental unit, Planmeca Romexis or the USB memory stick. 1. User name 2.
Page 96 (the minimum being 15 minutes). Automatic user sign-out is disabled by default. To take it into use, contact your Planmeca dealer. Planmeca Sovereign Classic...
Page 97: Managing Users And Personal Settings
When you sign in to the dental unit, you can start using the unit with your own personal settings. The settings are stored in the dental unit and/or in Planmeca Romexis software. For more information, contact your Planmeca dealer. Your personal settings include the following: •...
Page 98: Deleting User
3. Confirm the deletion by pressing OK. Sign in window. Your user name is deleted from the user list in the NOTE The user profile optionally saved in Planmeca Romexis is not deleted. For more information, contact your Planmeca dealer. Planmeca Sovereign Classic User's manual...
Page 99: Editing User Settings
About this task NOTE Users who have configured a Romexis username to their personal settings and whose user profile is stored in Planmeca Romexis do not have to edit their user name, as it is downloaded from Planmeca Romexis. Steps Sign in window, press Edit next to the user whose settings you 1.
Page 100: Editing Language
Sign in window, press Edit next to the user whose settings you 1. In the want to edit. User settings window opens. User settings window, press Edit next to Language . 2. In the Program - Language window opens. Planmeca Sovereign Classic User's manual...
Page 101 The available languages are: • English • Finnish • German • Spanish • French • Italian • Swedish • Hungarian • Czech • Danish • Norwegian • Russian • Japanese • Polish • Traditional Chinese • Simplified Chinese User's manual Planmeca Sovereign Classic...
Page 102: Editing Colour Theme
Sign in window, press Edit next to the user whose settings you want to edit. User settings window opens. User settings window, press Edit next to Color theme . 2. In the Program - Theme window opens. Planmeca Sovereign Classic User's manual...
Page 103: Editing Romexis Username
NOTE One Romexis username can be connected to only one user profile. Steps Sign in window, press Edit next to the user whose settings you 1. In the want to edit. User settings window opens. User's manual Planmeca Sovereign Classic...
Page 104: Transferring User Settings
4. Edit the Romexis username and save the changes by pressing OK. NOTE The Romexis username must be the same that is entered in the User window in Planmeca Romexis. NOTE Only letters A-Z and a-z, period (.), hyphen (-), underscore (_) and the “at”...
Page 105: Transferring User Settings From Usb
A help message is displayed when the settings have been transferred. 18.5.3 Transferring user settings to Romexis About this task The user settings can be transferred from the dental unit to Planmeca Romexis. NOTE This feature requires that the Romexis username is in use. If the user does not have a Romexis username, the settings can not be transferred.
Page 106: Transferring User Settings From Romexis
User settings window, see section "Editing Romexis username" on page 18.5.4 Transferring user settings from Romexis About this task The user settings can be transferred from Planmeca Romexis to the dental unit. Steps Sign in window, press Edit next to the user onto whose profile you 1.
Page 107: Resetting Personal Settings
The user profile optionally saved in Planmeca Romexis is not affected by the reset. The reset profile must be explicitly loaded to Planmeca Romexis. Thus, if you do not want to reset the settings in Planmeca Romexis, make sure you do not upload your reset settings to Romexis when you sign out from the dental unit.
Page 108 18 Managing users and personal settings 2. Press Reset. A confirmation message is displayed. 3. Confirm the reset by pressing OK. Planmeca Sovereign Classic User's manual...
Page 109: Assigning Planid Card To User
Last Name These will be shown in the dental unit as your user name. NOTE If you have stored a picture of yourself in Planmeca Romexis software, the User settings window and in the picture will show in the dental unit’s Welcome-message that is displayed when you sign in to the dental unit.
Page 110 19 Assigning PlanID card to user Steps Sign in window. 1. Press New user in the User settings window opens. 2. Press Assign PlanID tag. Assign PlanID tag window opens. Planmeca Sovereign Classic User's manual...
Page 111 4. Enter your Romexis username and save the changes by pressing OK. Add User The username must be the same that you entered in the window in Planmeca Romexis. Only letters A-Z and a-z, period (.), hyphen (-), underscore (_) and the “at” sign (@) are allowed.
Page 112: Checking Dental Unit Details
2. Press About this unit. About this unit window opens. NOTE The following is an example only and does not necessarily portray the actual situation. > means that more information can be opened to a new window. Planmeca Sovereign Classic User's manual...
Page 113: Unit Type
• when the yearly maintenance was last performed • how many days are left until the next yearly maintenance. Confirm yearly maintenance , is for qualified Planmeca service The last item, technicians only. 20.5.3 Storage information Storage information contains details on the mainboard SD card and control panel SD card.
Page 114: Gui Diagnostics
GUI Diagnostics shows the current hardware revision of the control panel and also contains tools for finding possible errors in the touch display. CAUTION GUI diagnostics is only meant to be used by a qualified Planmeca service technician. 20.5.5 PlanID...
Page 115: Message History
Network mask • Gateway CAUTION The network settings may only be edited by a qualified Planmeca service technician. 20.7 Message history Message history displays help and error messages when you press >. For information on how to use the message log, see section "Viewing help and error message history"...
Page 116: Switching Dental Unit Handedness
12. If needed, move the control panel to the other side of the instrument console. 13. If needed, move the syringe to the other end of the instrument console. What to do next Also watch the Planmeca video Planmeca Sovereign® Classic Left/right conversion. Planmeca Sovereign Classic...
Page 117: Operating Patient Chair
To drive the backrest down, press the Backrest down button until the chair reaches the required position. NOTE If the chair is equipped with an optional automatic legrest, the legrest position is adjusted simultaneously with the backrest position. User's manual Planmeca Sovereign Classic...
Page 118 To drive the chair up, press the Chair up button until the chair reaches the required position. NOTE Make sure that the bowl is not above the patient chair when driving the chair Planmeca Sovereign Classic User's manual...
Page 119 Push and hold the centre knob in the desired direction (see picture below). When the chair reaches the desired position, release the centre knob. You can steer the chair only in one direction at a time. User's manual Planmeca Sovereign Classic...
Page 120: Automatic Operation
Also, automatic positions A - G can be renamed, the order of the automatic positions on the list can be rearranged, automatic positions can be hidden from the list, and automatic positions can be programmed to the foot control. For instructions, see sections "Extended view" on Planmeca Sovereign Classic User's manual...
Page 121: Selecting Automatic Position
"Foot control functions" on page 69 and "Foot control functions" on page 200. When the chair is in an automatic position, the current position is displayed on the Chair positions button in the main window. User's manual Planmeca Sovereign Classic...
Page 122: Automatic Positions
In the standard view, only automatic positions A - D and rinsing position are available. The chair can be driven manually to the Trendelenburg position. Automatic position A - G Rinsing position For more information, see section "Rinsing position" on page 113. Cleaning position Consultation position Entry-Exit position Planmeca Sovereign Classic User's manual...
Page 123 Alternatively, you can program the dental unit so that the chair moves to the preprogrammed rinsing position when you press the Flexy button. NOTE The water in the dental unit is intended for rinsing only, not for drinking. User's manual Planmeca Sovereign Classic...
Page 124: Stopping Chair Movements
Next time you press Rinsing position, the chair will move to the rinsing position. Contact your Planmeca dealer. NOTE The Drive chair to rinsing position -function is a factory default function on the foot control.
Page 125: Specialist Mode
2 seconds, the speed increases. The automatic chair positions are not available in the specialist mode. The speed of the chair movements in the specialist mode can be programmed, see section "Specialist mode" on page 179. User's manual Planmeca Sovereign Classic...
Page 126: Operating Dental Unit
If automatic cup fill is enabled, the cup will fill automatically when you place it underneath the tap. A built-in sensor makes sure the cup is filled correctly. To take this feature into use, contact your Planmeca dealer. 23.2.2 Manual cup fill...
Page 127: Adjustments
188. 23.4 Door open When the door open -function is enabled, the Door open button is displayed on the control panel and you can open the door from the control panel or the foot control. User's manual Planmeca Sovereign Classic...
Page 128: Assistant Call
The duration of the signal can be programmed, see section "Door open / assistant call" on page 194. 23.6 Planmeca Solanna and Planmeca Solanna Vision operating light CAUTION Do not allow the patient to grab the operating light or its arm when getting seated or getting up from the patient chair.
Page 129: Indicator Lights
23.6.1 Indicator lights The indicator lights on the operating light’s handle buttons indicate the current state of the operating light. Indicator lights Colour Meaning White The operating light is on and the colour temperature is neutral. User's manual Planmeca Sovereign Classic...
Page 130 Yellow When the indicator light blinks yellow, the operating light is not functioning properly and full luminosity can not be reached. You can also hear a warning sound. Please contact your local Planmeca service technician. Planmeca Sovereign Classic User's manual...
Page 131: Enabling Gesture Sensor
Briefly press the handle button on either handle to switch the light on. Press the handle button a second time to switch the light off. You will hear a clicking sound when you press the button. User's manual Planmeca Sovereign Classic...
Page 132: Switching Composite Mode On/Off
The composite mode allows you to work with composite materials with minimal risk of pre-polymerisation caused by the operating light. The composite mode turns off automatically when another instrument than the polymerisation light is picked up from the instrument console. Planmeca Sovereign Classic User's manual...
Page 133 From dental unit When you switch the composite mode on, the indicator light on the Composite mode button is lit. Control panel: Press Composite mode to switch the operating light’s composite mode on or off. User's manual Planmeca Sovereign Classic...
Page 134: Adjusting Intensity Of Operating Light
The operating light intensity can also be programmed, see section "Planmeca Solanna and Planmeca Solanna Vision operating lights" on page 191. NOTE The operating light intensity will decrease to 30% of the maximum intensity when the chair is moving.
Page 135: Adjusting Intensity Of Operating Light In Composite Mode
You will hear short successive clicking sounds while the intensity is being adjusted and a long signal tone when the maximum/minimum intensity is reached. The operating light intensity can also be programmed, see section "Planmeca Solanna and Planmeca Solanna Vision operating lights" on page 191. User's manual Planmeca Sovereign Classic...
Page 136 The light intensity of the composite mode is displayed on the Composite mode button. When you change the intensity, the information on the button changes accordingly. Control panel: Press and hold the Composite mode button to adjust the light intensity of the composite mode. Planmeca Sovereign Classic User's manual...
Page 137: Changing Light Tone Of Operating Light
"Colour temperature and brightness" on page 192. 23.7 Planmeca Solanna Vision camera Prerequisites • Planmeca Romexis software version 6.0 or later must be installed. When Planmeca Romexis is running, the camera is continuously connected to the software. User's manual Planmeca Sovereign Classic...
Page 138 23 Operating dental unit • Planmeca Romexis and the dental unit have been paired by a Planmeca service technician. • The connection between Planmeca Romexis and the dental unit has been enabled by a Planmeca service technician. Solanna Vision button...
Page 139: Starting To Use Cameras
Solanna Vision window in the dental unit. This does not open the To switch full screen mode on/off, press the f key on the Planmeca Romexis keyboard. To switch low latency mode on/off, press the l key on the Planmeca Romexis keyboard 23.7.1.2 Activating camera from dental unit...
Page 140: Adjusting Camera Settings From Dental Unit
How to open Solanna Vision window on dental unit Interface Action Planmeca dental unit: Foot Planmeca Sovereign Classic: You can program the foot control so Solanna Vision window opens when you push one of the control that the side knobs. For instructions, see section "Foot control functions" on page 200.
Page 141 23.7.2.2 Adjusting video settings Steps Solanna Vision window in the dental unit. 1. Open the For instructions, see section "Activating camera from dental unit" on page 129. Solanna Vision window, press Settings. 2. In the User's manual Planmeca Sovereign Classic...
Page 142: Switching Video Streaming On/Off
23.7.3 Switching video streaming on/off Solanna When video streaming is on, the live video stream is played in the Vision window in Planmeca Romexis. Solanna Vision window in Planmeca When you turn streaming off, the Romexis closes. The window opens again when you turn streaming on.
Page 143: Recording Video
Solanna Vision window, press Microphone to mute/unmute the microphone. Planmeca dental unit: Planmeca Sovereign Classic: You can program the dental unit so that Control panel on Flexy- video streaming is switched on/off when you press the Flexy button. For holder instructions, see section "Flexy button functions"...
Page 144: Capturing Image
Solanna Vision button in the main window blinks to indicate that recording is going on. Planmeca Romexis: When recording is going on, a red recording icon in the Solanna Vision window indicates that recording is going top left corner of the...
Page 145: Water And Air Quick-Connectors
How to capture image Interface Action Planmeca dental unit: Planmeca Sovereign Classic: You can program the dental unit so Control panel on Flexy- that an image is captured when you press the Flexy button. For holder instructions, see section "Flexy button functions" on page 198.
Page 146: Operating Instruments
Intelligent four-handed dentistry In four-handed dentistry it is important to enable a smooth preparation and exchange of instruments between the dentist and the assistant. Therefore, Planmeca Sovereign Classic User's manual...
Page 147: Micromotor
24 Operating instruments an alternative instrument logic can be taken into use for four-handed dentistry. Please contact your Planmeca dealer. In intelligent four-handed dentistry one instrument can be left waiting in a queue so that it is ready for use when the dentist returns the active instrument to the instrument console.
Page 148 Always check the preset settings before using the micromotor. 24.2.1.1 Presets for Planmeca Minendo and Bien-Air MX2 brushless micromotors 15 presets are available for the Planmeca Minendo and the Bien-Air MX2 brushless micromotor: The presets are user- and instrument model -specific. For usage examples, see section "Using micromotor presets"...
Page 149 24 Operating instruments Factory presets for Planmeca Minendo and Bien-Air MX2 Setting Preset 1 - Preset i1 - Preset e1 Preset e2 Preset e3 Preset e4 Preset e5 Automatic chip blow Water: 0 Water: 0 Air: 60 Air: 60 Manual...
Page 150 Power curve Linear Linear Linear Full Full Range: 300 - Range: 15 - 2 Range: 15 - 2 Range: N/A Range: N/A 40 000 Limit: 15 Limit: 15 Limit: 35 000 Limit: 1 200 Limit: 800 Planmeca Sovereign Classic User's manual...
Page 151 <15%. If another handpiece than those listed above is used for endodontic treatment with the Implantmed surgical micromotor, the accuracy of the torque limit displayed on the control panel cannot be guaranteed. CAUTION Always check the preset settings before using the micromotor. User's manual Planmeca Sovereign Classic...
Page 152 Morita TORX micromotor. CAUTION Endodontic treatment must only be performed using the Morita TORX micromotor's a1 - a3 presets and the Morita CA-10RC-ENDO 10:1 handpiece. CAUTION Always check the preset settings before using the micromotor. Planmeca Sovereign Classic User's manual...
Page 153 Default: Full Default: Full Default: Linear Value range: Value range: Value range: Value range: Value range: 100 - 40 000 100 - 1000 100 - 1000 100 - 1000 100 - 2000 Default: 40 000 User's manual Planmeca Sovereign Classic...
Page 154 The button always shows the current apical action (thus, the symbol on the button changes according to the selected apical action). NOTE Also reaching the torque limit can make the micromotor to rotate counter- clockwise. Planmeca Sovereign Classic User's manual...
Page 155 When the apical action autoforward is selected and the flash bar is reached, the micromotor will rotate counter-clockwise (reverse) until it has reversed three segments on the apex meter and then return to clockwise rotation. User's manual Planmeca Sovereign Classic...
Page 156 Example - two Planmeca Minendo micromotors The following cases describe how the presets can be used in a situation where two Planmeca Minendo brushless micromotors are in use. Both micromotors use the same presets. Micromotor 1 is installed to instrument slot 1 and micromotor 2 to instrument slot 2.
Page 157: Handpiece Selection
Press on the correct handpiece to select it. The window closes and the instrument settings and the handpiece information on the control panel change accordingly. To close the window without selecting a handpiece, press Close. User's manual Planmeca Sovereign Classic...
Page 158: Speed/Power
Reverse button indicates in which direction you must push the pedal to start reverse rotation. When the right half of the indicator light is lit, push the pedal to the right to start reverse rotation. When the left half is lit, push the pedal to the left. Planmeca Sovereign Classic User's manual...
Page 159: Speed/Power Limit
Quickstart disabled Quickstart enabled NOTE Quickstart and instrument speed reduction can be enabled at the same time. When both are enabled, the micromotor immediately starts with the maximum rpm defined by the speed reduction setting. User's manual Planmeca Sovereign Classic...
Page 160: Torque
The instrument cooling spray setting can be selected to be water & air, air or no spray. NOTE As a default, dry spray is enabled for Planmeca Minendo and Bien-Air MX micromotors. This means that you can only select between spray settings 'air' or 'no spray'. To disable dry spray, see section "Enabling/disabling dry spray"...
Page 161: Automatic Chip Blow
The instrument spray operated with the foot control can be disabled in the service mode, in which case you can switch the spray on and off only from the control panel. Contact your Planmeca dealer. 24.2.9 Automatic chip blow When the automatic chip blow is on, the indicator light on the control panel button is on and two short blows of water, air, or both will occur after the instrument is stopped.
Page 162: Manual Chip Blow
The type of manual chip blow does not depend on the type of the automatic chip blow, but is always dry. The manual chip blow can be set to be dependent on programming; contact your Planmeca dealer. 24.2.11 Instrument light When the instrument light is on, the indicator light on the control panel button is green.
Page 163: Before Using Apex Locator
CA-10RC-ENDO 10:1 handpiece with the apex locator, do not use the file holder. Leave the grey female connector on the probe cord hanging. 3. Contrary electrode Insert the contrary electrode into the white female connector on the probe cord. User's manual Planmeca Sovereign Classic...
Page 164 Check that all the meter Apex locator window light up. indicator bars in the If the indicator bars do not appear normally, stop using the device and contact your Planmeca dealer. Planmeca Sovereign Classic User's manual...
Page 165: Using Apex Locator
Check that all the meter indicator bars in the window light up. If the indicator bars do not appear normally, stop using the device and contact your Planmeca dealer. 24.3.2 Using apex locator The Morita Root ZX mini U apex locator can be used both with hand files and with the Morita TORX micromotor and the CA-10RC-ENDO 10:1 handpiece.
Page 166 When you insert the file into the root canal, the flash bar starts blinking. When the file tip reaches the point in the root canal designated by the flash bar, the flash bar stops blinking and stays on. Planmeca Sovereign Classic User's manual...
Page 167 If the flash bar has been set within the 5 bars below 2 on the meter scale, the beep signal is slow at first and becomes continuous when the file tip reaches the flash bar. There is no fast beep signal. 1. Slow beep signal 2. Continuous signal User's manual Planmeca Sovereign Classic...
Page 168: Testing Apex Locator Function
Apex locator window either by pressing the Apex locator button 1. Open the or by activating the Morita TORX micromotor and selecting one of the apex presets (a1 - a3). 2. Insert the tester into the jack on the back of the instrument console. Planmeca Sovereign Classic User's manual...
Page 169: Turbine
1 3 bars above 1 2 3 bars below 1 24.4 Turbine The turbines supplied by Planmeca have a built-in backflow prevention system, which protects the water used in the instrument from contamination. CAUTION A power cut will shut down the software-controlled backflow prevention system.
Page 170: Speed/Power
Press Turbine speed/power limit again to switch the speed/power limit off. Foot control: The speed/power limit can be programmed to be activated from the foot control. For programming instructions, see section "Foot control functions" on page 200. Planmeca Sovereign Classic User's manual...
Page 171: Instrument Spray
Press Instrument spray a second time to switch the air spray on. A yellow indicator light shows that the air spray is switched on. Press Instrument spray a third time to switch off the instrument cooling spray. The indicator light goes out. Foot control: User's manual Planmeca Sovereign Classic...
Page 172: Automatic Chip Blow
The instrument spray operated with the foot control can be disabled in the service mode, in which case you can switch the spray on and off only from the control panel. Contact your Planmeca dealer. 24.4.5 Automatic chip blow When the automatic chip blow is on, the indicator light on the control panel button is on and two short blows of water, air, or both will occur after the instrument is stopped.
Page 173: Scaler
When sterile water is used, the sterile water symbol is displayed on the control panel in addition to the water amount and spray water number. For instructions on how to enable/disable the sterile mode, see section "Enabling/disabling sterile water mode" on page 182. Control panel: User's manual Planmeca Sovereign Classic...
Page 174: Satelec Newtron Scaler
The instrument spray operated with the foot control can be disabled in the service mode, in which case you can switch the spray on and off only from the control panel. Contact your Planmeca dealer. 24.5.3 Satelec Newtron scaler The Satelec Newtron scaler and the Satelec Newtron LED scaler have four modes: •...
Page 175: Lm Scaler
200. The instrument light intensity can be programmed, see section "Instrument light" on page 187. 24.6 Planmeca Lumion Plus polymerisation light CAUTION The polymerisation light generates optical radiation and proper safety measures should be taken when using the instrument. For detailed information, please refer to OEM documentation.
Page 176 5 seconds. The progress of the polymerisation cycle is displayed on the control panel. Independent mode The Planmeca Lumion Plus polymerisation light can also be operated in the independent mode. The independent mode is typically used when the Planmeca Lumion Plus polymerisation light is attached to the assistant...
Page 177: Intraoral Camera And Planmeca Romexis
After you have saved the images Once you have saved the images, you can browse through them in the Planmeca Romexis Image browser. Press the Done button at the bottom of the intraoral camera window in Planmeca Romexis to move to the Image Planmeca browser.
Page 178 • you will hear a short sound signal, • the Planmeca Romexis intraoral camera view is displayed on the monitor, • the text “Intraoral camera active” is displayed on the dental unit's control panel.
Page 179: Intraoral Camera Placed In Suction Holder
Starting intraoral camera Before you turn on the intraoral camera, first select the patient and the 2D module in Planmeca Romexis. Then, start the camera from the dental unit. 1. Pick up the camera from the Flexy-holder. 2. Activate the intraoral camera with the foot control according to how you have programmed it.
Page 180 Saving image A frozen image can be saved from the dental unit, the handpiece and Planmeca Romexis. From the handpiece you can save an image also without freezing the image first. A long sound signal indicates that an image is saved. When the image is being saved, the indicator light on the handpiece blinks orange.
Page 181: Planmeca Intraoral Scanner
24.8 Planmeca intraoral scanner The Planmeca intraoral scanner is used together with Planmeca Romexis and Planmeca PlanCAD Easy software. The scanner is mainly operated with the software, but to make the scanning procedure easier, some of the operations can also be performed from the dental unit’s foot control.
Page 182 "Foot control functions" on page 69. NOTE In addition, you can program the dental unit so that the intraoral scanner is activated/deactivated when you press the Flexy button. For instructions, see section "Flexy button functions" on page 198. Planmeca Sovereign Classic User's manual...
Page 183: Operating Suction Handpieces
The duration of this post-suction delay is configurable, contact your Planmeca dealer. This feature is not available for the tilting high-volume suction handpiece.
Page 184: Tilting High-Volume Suction
You can stop the suction temporarily by “straightening” the suction handpiece with your thumb and forefinger. If you temporarily put the suction handpiece down during dental treatment, the suction will automatically stop as the force of the suction will straighten the handpiece. Planmeca Sovereign Classic User's manual...
Page 185: Programming
5. Press OK to store the new setting into memory. The pop-up window closes. NOTE Alternatively, you can store the new setting by pushing the foot control pedal down. When you press Program, you will also see the following symbols on the control panel: User's manual Planmeca Sovereign Classic...
Page 186: Organising Items On Control Panel
4. Press OK to confirm the new order. If you do not wish to save the new order, press Close. Planmeca Sovereign Classic User's manual...
Page 187: Automatic Chair Positions
A list of automatic positions opens. 6. Select the wanted chair position by pressing it on the list. The field of the position that you have selected from the list (position C in picture) turns blue. User's manual Planmeca Sovereign Classic...
Page 188: Traditional View
2. If you want the operating light or its composite mode to be on (off) in this position, turn it on (off). 3. Adjust the intensity of the operating light and/or its composite mode as described in section "Intensity" on page 191. 4. Press Program. Planmeca Sovereign Classic User's manual...
Page 189: Specialist Mode
This means that whenever you sign in to the dental unit, you will use your last saved instrument settings. User's manual Planmeca Sovereign Classic...
Page 190: Instrument Speed/Power Limit
The pop-up window closes. 26.5.2 Quickstart for micromotor Steps 1. Activate the instrument. 2. Press Program. 3. Press Instrument speed/power limit. NOTE This button looks different depending on whether quickstart is enabled or disabled. A pop-up window opens. Planmeca Sovereign Classic User's manual...
Page 191: Instrument Spray
26.5.4 Enabling/disabling dry spray About this task As a default, the dry spray is enabled, which means that no water comes out from the instrument. The dry spray is available only for Planmeca Minendo and Bien-Air MX micromotors, and for the turbine. Steps 1.
Page 192: Enabling/Disabling Sterile Water Mode
5. Press OK. The pop-up window closes. 26.5.5 Enabling/disabling sterile water mode About this task If the dental unit is equipped with the Planmeca Sterile water system or Steripump, enable/disable the sterile water mode as described below. Steps 1. Activate the instrument.
Page 193: Automatic Chip Blow
If no drive mode is displayed on the screen, press Torque. Then, toggle between the drive modes by pressing the current drive mode -button. Toggle between the drive modes by pressing the current drive mode - button. User's manual Planmeca Sovereign Classic...
Page 194 20 000 - 38 000 2 000 (e.g. 22 000, 24 000 etc..) 3.d. Press OK. The pop-up window closes and the new value is displayed on the control panel. 4. Adjust the torque limit rate. 4.a. Press Program. Planmeca Sovereign Classic User's manual...
Page 195: Modifying And Saving Micromotor Presets
The procedure for saving the modified preset settings is explained in section "Modifying and saving micromotor presets" on page 185. 26.5.8 Modifying and saving micromotor presets About this task For information on how to use presets, see section "Micromotor presets" on page 137. User's manual Planmeca Sovereign Classic...
Page 196 Pressing Close exits the preset name window without saving the preset name. 8. Press OK. The pop-up window closes and the new settings are stored to your user profile. Planmeca Sovereign Classic User's manual...
Page 197: Instrument Light
100%, and the adjustment step is 2. 5. Press OK. The pop-up window closes and the new values are displayed on the control panel. 26.5.10 Planmeca Lumion Plus polymerisation light About this task NOTE The duration of the polymerisation cycle can be programmed only for the Planmeca Lumion Plus polymerisation light.
Page 198: Timer Settings
26.7 Bowl rinse and cup fill 26.7.1 Adjusting cup fill and bowl rinse flow rates The flow rates of the bowl flush and cup fill can be adjusted with the two black knobs located inside the dental unit. Planmeca Sovereign Classic User's manual...
Page 199: Duration Of Bowl Rinsing
About this task NOTE By default, the cup fill is not activated unless the cup is positioned in its place under the cup fill tube. To change this setting, contact your Planmeca dealer. NOTE The water in the dental unit is intended for rinsing only, not for drinking.
Page 200 2 seconds. The pedal can be released and then pushed again, and the time continues to increase. Continue until the cup is filled to the desired level. 5. Press Program. Planmeca Sovereign Classic User's manual...
Page 201: Planmeca Solanna And Planmeca Solanna Vision Operating Lights
26 Programming 26.8 Planmeca Solanna and Planmeca Solanna Vision operating lights 26.8.1 Intensity About this task NOTE The light intensity can also be adjusted from the operating light, see sections "Adjusting intensity of operating light" on page 124 and "Adjusting intensity of operating light in composite mode"...
Page 202: Colour Temperature And Brightness
Colour temperature tab. 3. Open the 4. Select the white light tone by pressing it. The selected tone is highlighted in blue. 5. Select the maximum brightness by pressing it. The selected brightness is highlighted in blue. Planmeca Sovereign Classic User's manual...
Page 203: Gesture Sensor
A grey button means that the function is disabled, and a blue button that the function is enabled. 5. Adjust the distance at which the gesture sensor on the operating light reads your hand movements by dragging the handles to a suitable position. 6. Press OK. User's manual Planmeca Sovereign Classic...
Page 204: Door Open / Assistant Call
NOTE If so configured, you can activate the disabled function from the foot control. Please contact your Planmeca dealer. 4. Optionally, adjust the door open / assistant call time. NOTE Only the value of the enabled function can be adjusted.
Page 205: Clock
About this task NOTE If Planmeca Romexis Clinic Management software is used together with this dental unit, you do not need to adjust the clock settings. The dental unit clock is synchronised with the Planmeca Romexis clock every time the dental unit is booted up.
Page 206: Water And Air Quick-Connectors
5. Adjust the day, month and year. 6. Press OK. The pop-up window closes and the new date is displayed on the control panel. 26.12 Water and air quick-connectors Steps 1. Press Program. 2. Press Quick-connector. A pop-up window opens. Planmeca Sovereign Classic User's manual...
Page 207: Bottle Water -Mode
When the bottle water -mode is enabled, the water container icon is displayed on the control panel. Alternatively, you can enable/disable the bottle water -mode as follows: Steps 1. Press Program. 2. Press Maintenance. User's manual Planmeca Sovereign Classic...
Page 208: Flexy Button Functions
About this task You can program which function is activated when you press the Flexy button. Steps 1. Press Program. 2. Press Suction holder in the top of the control panel. A pop-up window opens. Planmeca Sovereign Classic User's manual...
Page 209 Drive chair to rinsing position • Lock/unlock touch display • Turn suction on/off • Turn Planmeca Solanna operating light's composite mode on/off and adjust its intensity • Open/close Planmeca Solanna Vision window • Turn Planmeca Solanna Vision video streaming on/off •...
Page 210: Foot Control Functions
NOTE The intraoral scanner activation is programmed in the idle view and deactivation in the instrument view. Steps 1. If you are programming foot control functions for an instrument, activate the instrument. 2. Press Program. Planmeca Sovereign Classic User's manual...
Page 211: Wireless Foot Control
If no wireless foot control is connected to your dental unit, or if you want to change the current wireless foot control to another, you must pair the dental unit and the foot control. Steps 1. Press Program. User's manual Planmeca Sovereign Classic...
Page 212 5. Press and hold down the handle of the foot control that you want to pair your dental unit with to select it. The selected foot control is shown with a black font on the list (marked with arrow in the picture below). Planmeca Sovereign Classic User's manual...
Page 213 If the pairing is not successful, you will receive a notification, after which you can retry to perform the pairing. 9. Press OK to close the window. User's manual Planmeca Sovereign Classic...
Page 214: Viewing Battery Charging Information
If no graph is displayed, press the foot control handle. 5. Press OK to close the window. 26.16.3 Adjusting radio settings About this task The following describes how to optimise the communication between the dental unit and the wireless foot control. Planmeca Sovereign Classic User's manual...
Page 215 Select the lowest power level and increase it, if needed. The value range is 1 (lowest) to 6 (highest). 6. Press OK to confirm your selections and exit the programming mode. To exit the programming mode without confirming, press Close. User's manual Planmeca Sovereign Classic...
Page 216: Cuspidor Parts
2. Instrument flushing holder 3. Coarse filters 4. Suction tube cleaning holder 5. PlanClear container 6. Suction disinfectant container 7. Amalgam collector / deposit cup (units with no suction system or with Dürr CAS1 or CS1 suction system) Planmeca Sovereign Classic User's manual...
Page 217: Maintenance
For more information on the flushing and cleaning programs, see section "Flushing and cleaning programs" on page 209. 28.2.1 Filling PlanClear container CAUTION The PlanClear container must be filled with Planmeca PlanClear disinfectant only. CAUTION Wear protective gloves and glasses when you fill the container.
Page 218: Filling Suction Disinfectant Container
Fill the container as follows: 1. Open the cap of the PlanClear container. 2. Fill the container with Planmeca PlanClear up to the maximum marking. 3. Close the cap of the PlanClear container. 28.2.2 Filling suction disinfectant container CAUTION The container must only be filled with Planmeca approved suction disinfectant.
Page 219: Flushing And Cleaning Programs
Duration: < 10 minutes in the disabled recommend evening + min. 8 hours affect that waterline time + < 30 minutes in the cleaning be morning performed once a week after the working day (but not over the weekend). User's manual Planmeca Sovereign Classic...
Page 220: Introduction
The water must flow properly through the cup fill line, otherwise the unit will not be flushed. Make sure that the cup fill line is not totally closed. The flow through the cup fill line is recommended to be approximately 1 dl/5 sec. Planmeca Sovereign Classic User's manual...
Page 221 They will still, however, be performed in sequence. • Cleaning For performing suction cleaning and waterline cleaning. • Maintenance demands Tells you when the different flushing and cleaning programs should be performed. User's manual Planmeca Sovereign Classic...
Page 222 Starts the cleaning function. When the instrument and/or suction handpiece is in the instrument console or the suction holder, the button is disabled. Displays additional information about the cleaning program when you press the button during the cleaning cycle. Planmeca Sovereign Classic User's manual...
Page 223 For instructions, see section "Weekly cleaning procedures" on page 248. NOTE Alternatively, you can program the dental unit so that the touch panel is locked/unlocked when you press the Flexy button. For instructions, see section "Flexy button functions" on page 198. User's manual Planmeca Sovereign Classic...
Page 224: Maintenance Protocol
Maintenance demands tab. However, the next time the dental unit connects with Planmeca Romexis, the maintenance protocol set in Planmeca Romexis is downloaded and taken into use. For information on Planmeca how to set the maintenance protocol in Planmeca Romexis, see Romexis technical manual , section Maintenance scheduling and Demands .
Page 225: Starting Cleaning Programs Remotely From Planmeca Romexis
This feature requires Planmeca Romexis software version 4.5 and Planmeca Romexis Clinic Management. If your dental unit is connected to Planmeca Romexis, it is possible to schedule the cleaning programs so that they start at a time convenient for you, for example, when you are not in the clinic. To schedule the remote start-up of cleaning programs for your dental unit or group of dental units, contact your Planmeca dealer.
Page 226: After Cleaning
The duration of short flushing is 30 seconds / instrument. NOTE The duration of the long flushing cycle is configurable. (The factory default is 2 minutes.) Please contact your Planmeca dealer. NOTE In units equipped with a water heater, the long flushing fills the water lines and water heater with cool water and switches the water heater off.
Page 227 29 Flushing and cleaning programs 2. Press Maintenance to go into maintenance mode. Flushing tab. 3. Open the 4. Remove the instrument handpieces from the instruments and clean them according to the manufacturer’s instructions. 5. Open the cuspidor door. User's manual Planmeca Sovereign Classic...
Page 228 Luzzani Ergo syringe: Remove the metallic syringe cover and place the syringe in the flushing holder. Note the orientation of the syringe. It does not require an adapter and must be placed in the holder as shown below. Planmeca Sovereign Classic User's manual...
Page 229 Depending on your dental unit configuration, this message may interrupt the cleaning program until you have inserted the required instruments. 10. When the flushing cycle is completed, help message HE5001 is displayed on the control panel. Remove the instruments from the User's manual Planmeca Sovereign Classic...
Page 230: Suction Flushing
The flushing cycle can be interrupted by pressing Cancel on the Flushing tab. After the interruption, the dental unit can be used normally if it has not been configured to be locked after an uncompleted flushing cycle. Planmeca Sovereign Classic User's manual...
Page 231 29 Flushing and cleaning programs Steps 1. Press Maintenance to go into maintenance mode. Flushing tab. 2. Open the 3. Remove the suction handpieces from the suction tubes and clean them according to the manufacturer’s instructions. User's manual Planmeca Sovereign Classic...
Page 232 5. Press Start next to 6. Follow the messages on the control panel that inform you of the flushing cycle progress. If you have not inserted all required suction tubes in the cleaning holder, help message HE5005 is displayed. Planmeca Sovereign Classic User's manual...
Page 233: Suction Cleaning
Results The dental unit is now ready for normal operation. NOTE Before attaching the handpieces back on the suction tubes, wipe the identification bushings (1) with Planmeca approved surface disinfectant. 29.8 Suction cleaning About this task NOTE Make sure there is a plug in the empty holder(s) in the cleaning holder to prevent water from spilling.
Page 234 Steps 1. Press Maintenance to go into maintenance mode. Cleaning tab. 2. Open the 3. Remove the suction handpieces from the suction tubes and clean them according to the manufacturer’s instructions. Planmeca Sovereign Classic User's manual...
Page 235 If you have not inserted all required suction tubes in the cleaning holder, help message HE5005 is displayed. The suction tubes are cleaned with Planmeca approved suction disinfectant. When suction disinfectant is pumped to the suction cleaning system, the yellow suction disinfectant icon is displayed on the control panel.
Page 236: Waterline Cleaning
• Continuous cleaning The dental unit’s waterlines are kept clean by continuously feeding Planmeca PlanClear disinfectant solution from the water container to the waterlines, instruments and cup fill. The user performs waterline cleaning once a month after the working day.
Page 237: Continuous Cleaning
About this task The disinfectant solution is mixed in the water container: A small amount of Planmeca PlanClear disinfectant concentrate is regularly dosed to the water container where it is mixed with water and fed further to the waterlines, the instruments and the cup fill.
Page 238: Cleaning Interval
The dental unit has a counter that keeps track of when to perform the next full cleaning, so Planmeca Sovereign Classic User's manual...
Page 239: Resetting Counter
Pressing the Now button does not start the waterline cleaning. For instructions on how to start the waterline cleaning, see section "Starting waterline cleaning cycle" on page 230. If you want to close the window without resetting the counter, press Close. User's manual Planmeca Sovereign Classic...
Page 240: Starting Waterline Cleaning Cycle
CAUTION The flushing cycle is performed using domestic water, which might reduce the effect of Planmeca PlanClear, if the domestic water is not clean. CAUTION Ensure that the suction hoses are NOT in the suction tube cleaning holder when you perform waterline cleaning.
Page 241 29 Flushing and cleaning programs Cleaning tab. 3. Open the 4. Remove the instrument handpieces from the instruments and clean them according to the manufacturer’s instructions. 5. Open the cuspidor door. User's manual Planmeca Sovereign Classic...
Page 242 Luzzani Ergo syringe: Remove the metallic syringe cover and place the syringe in the flushing holder. Note the orientation of the syringe. It does not require an adapter and must be placed in the holder as shown below. Planmeca Sovereign Classic User's manual...
Page 243 10. Help message HE4012 is displayed. Shut down the dental unit for the night. Also turn off the main water feed for the night. NOTE Planmeca PlanClear disinfection solution can be left in the dental unit waterlines over a weekend, but not for a longer period (not, for example, over a holiday).
Page 244: Extensive Flushing
For instructions, see section "Adjusting cup fill and bowl rinse flow rates" on page 188. NOTE The flushing cycle can be interrupted by pressing Close. After the interruption, make sure that the water is clean before using the dental unit again. Planmeca Sovereign Classic User's manual...
Page 245 1. Turn the cup fill tube so that it is above the bowl and not above the cup holder. 2. Press Program. 3. Press Maintenance. Program - Maintenance window opens. 4. Remove the instrument handpieces from the instruments and clean them according to the manufacturer’s instructions. 5. Open the cuspidor door. User's manual Planmeca Sovereign Classic...
Page 246 Luzzani Ergo syringe: Remove the metallic syringe cover and place the syringe in the flushing holder. Note the orientation of the syringe. It does not require an adapter and must be placed in the holder as shown below. Planmeca Sovereign Classic User's manual...
Page 247 11. Once the flushing cycle is finished, remove the instruments from the flushing holder and place them in the instrument console. Close the cuspidor door. Results The dental unit is now ready for normal operation. User's manual Planmeca Sovereign Classic...
Page 248: Cleaning And Disinfection
30 Cleaning and disinfection 30 Cleaning and disinfection 30.1 Introduction Planmeca approved surface disinfectants, upholstery disinfectants, dental unit water and waterline disinfectants, and suction disinfectants are listed in Planmeca approved disinfectants (30007097). The document the document can be found in the Planmeca Material bank.
Page 249 Suction Planmeca handpieces approved surface disinfectant Suction tubes Planmeca approved surface disinfectant Monitor Planmeca approved surface disinfectant Upholstery Mild soap- and water solution Bowl filter Mild soap- and water solution User's manual Planmeca Sovereign Classic...
Page 250: Instruments
Clean and service the instruments according to the information supplied with the instrument. NOTE After cleaning the instrument, let the oil run from it for at least 10 minutes before replacing it on the console. Planmeca Sovereign Classic User's manual...
Page 251: Instrument Console
You can check how full the oil collector is without removing it completely. Pull the oil collector downward from the attachment knob (1) and check the oil level in the narrower chamber (2). If it has started to fill, it is time to empty the oil collector. User's manual Planmeca Sovereign Classic...
Page 252: Cuspidor
2. Rinse the bowl by pressing the Bowl rinse button on the control panel (or by using the foot control). 3. The outside of the bowl can be wiped clean or disinfected with a cloth. Planmeca Sovereign Classic User's manual...
Page 253: Water Container
Do not empty the bowl filter to the drain. 30.5.2 Water container If continuous cleaning is disabled, disinfect the water container in a washer- disinfector once a week at 93°C. Otherwise, clean the water container once a month. User's manual Planmeca Sovereign Classic...
Page 254: Instrument Flushing Holder
CAUTION Be careful not to splash the contents of the water container when removing it, as it may contain traces of Planmeca PlanClear disinfectant. Immediately remove any Planmeca PlanClear splashes from the dental unit. When you place the water container back in the cuspidor, make sure to place the three adjacent openings in the container carefully over the three pipes in the cuspidor.
Page 255: Coarse Filters
30.5.4 Coarse filters Empty the coarse filters daily or when they are full. Replace them monthly. NOTE The coarse filter should be emptied into a separate amalgam container. User's manual Planmeca Sovereign Classic...
Page 256: Suction Tube Cleaning Holder And Separation Tank
93°C. 4. When the suction tube cleaning holder is removed you can access the separation tank. Clean the separation tank using water and a brush. Be careful not to dislocate the tubes in the tank. Planmeca Sovereign Classic User's manual...
Page 257: Suction System
Wet surfaces might disturb suction tube recognition. 30.6.1 In the morning Steps 1. Perform suction flushing. For instructions, see section "Suction flushing" on page 220. 2. Wipe the suction handpieces with Planmeca approved surface disinfectant. 30.6.2 After each patient Steps 1. Remove the used aspirating tips.
Page 258: Weekly Cleaning Procedures
30 Cleaning and disinfection 3. Flexy-holder: Disinfect the supplementary holders, suction tube holders (including rollers) and instrument holder in a washer-disinfector at 93°C. 4. Flexy-holder: Wipe the holder for the intraoral scanner with Planmeca approved surface disinfectant. 30.6.4 Weekly cleaning procedures 30.6.4.1 During working day...
Page 259: Cleaning Suction Handpieces
Planmeca approved suction disinfectant once a week. Steps 1. Mix 5 ml of Planmeca approved suction disinfectant with 250 ml water and stir well. 2. Open the bowl valve to remove any excess water by pressing the VS/A button in the Maintenance main menu.
Page 260: Planmeca Prox
4. Dürr saliva suction 5. Dürr high-volume suction 30.7 Planmeca ProX For information on how to clean the Planmeca ProX X-ray unit, see Planmeca ProX user’s manual . 30.8 Planmeca ProSensor For information on how to clean the Planmeca ProSensor sensor, see Planmeca ProSensor user’s manual .
Page 261: Planmeca Intraoral Scanner
30 Cleaning and disinfection 30.9 Planmeca intraoral scanner For information on how to clean the Planmeca intraoral scanner, see Planmeca FIT user’s manual . 30.10 External PC The external PC together with its mouse and keyboard can be wiped with a dry cloth, or according to the manufacturer’s instructions.
Page 262: Help And Error Messages
Contact service in the help or error message, When you press the hyperlink the service contact details are displayed. The details are only to be changed by a qualified Planmeca service technician. Planmeca Sovereign Classic User's manual...
Page 263: Help Messages In Short Form
HE1047 Failed to copy user profile from Romexis. Failed to copy user profile from Romexis. HE1048 Failed to assign PlanID tag to user. Check if user already has another PlanID tag assigned. User's manual Planmeca Sovereign Classic...
Page 264 Check your user settings before continuing. HE1070 Wrong Romexis user name for the PlanID Correct the Romexis username. tag. HE1073 Assigning in progress, please wait. Assigning in progress, please wait. Planmeca Sovereign Classic User's manual...
Page 265 The slot is marked with a label. Consult the user's manual. HE2026 Reverse drive not possible because of Micromotor cannot be driven in reverse torque drive mode. direction because torque drive mode is either autoreverse or autoforward. User's manual Planmeca Sovereign Classic...
Page 266 Make sure that nothing blocks the movement. HE3021 Downward chair movement prevented. The chair cannot be driven down because a safety switch is activated. Make sure that nothing blocks the movement. Planmeca Sovereign Classic User's manual...
Page 267 Amalgam collector is full. Replace or empty the collector immediately. The suction system cannot be used before the collector is emptied or replaced. HE4050 Activation of suction tubes is prohibited. Return suction tubes to holders. User's manual Planmeca Sovereign Classic...
Page 268 HE6001 Foot control calibration 2/6, top centre. Move the foot control pedal to the top centre position, then push and release one of the foot control knobs. Planmeca Sovereign Classic User's manual...
Page 269 Make sure the touch screen is clean and to interference on touch screen. dry. If the problem continues, contact service. HE8000 Romexis connection lost. Make sure the Ethernet cable is attached and Romexis is running. HE8091 Romexis patient not selected. Select patient. User's manual Planmeca Sovereign Classic...
Page 270: Error Messages In Short Form
31.3 Error messages in short form The error messages are mainly intended to assist the technician. Planmeca For more detailed information on the error messages, see Sovereign Classic technical manual 31.3.1 General error messages General ERROR EXPLANATION CODE E1001 Failed to load settings.
Page 271: Instrument Error Messages
Spray water pressure too low. E2009 Drive air pressure too high. E2010 Spray air pressure too high. E2011 Spray water pressure too high. E2014 IPS voltage too low. E2015 AUX voltage too low. E2016 Proportional valve open error. User's manual Planmeca Sovereign Classic...
Page 272: Patient Chair Error Messages
CODE E3000 Chair lift position sensor error. E3001 Chair lift motor error. E3002 Chair lift movement error. E3005 Backrest position sensor error. E3006 Backrest motor error. E3007 Backrest movement error. E3010 Rotation position sensor error. Planmeca Sovereign Classic User's manual...
Page 273: Water System Error Messages
Control panel connection error. 31.3.7 CAN error messages ERROR EXPLANATION CODE E7001 Control panel CAN bus off error. E7002 Control panel CAN controller restarted. E7011 ACCU2 CAN bus off error. E7012 ACCU2 CAN controller restarted. User's manual Planmeca Sovereign Classic...
Page 274: Viewing Help And Error Message History
The dental unit keeps a log of all help and error messages. It can be viewed About this unit window. in the Steps 1. Press Program. 2. Press About this unit. NOTE The following is an example only and does not necessarily portray the actual situation. Planmeca Sovereign Classic User's manual...
Page 275 Messages related to cleaning cycles Error messages 4. Optional: Filter messages by toggling the Message type buttons. A grey button means that the message type is not listed, and a blue button that it is listed. User's manual Planmeca Sovereign Classic...
Page 276 A confirmation message is displayed. Confirm the deletion by pressing NOTE Carefully consider when the deletion of message history is appropriate as it contains information that is valuable to the Planmeca service technician. 6. Press OK to close the window.
Page 277: Consumables
POM, stainless steel Billund high-volume suction 10039176 PP, POM, handpiece assembly stainless steel Dürr high-volume suction 10039172 PSU, PP, handpiece assembly POM, stainless steel Tilting high-volume suction 10022870 PSU, PP, handpiece assembly POM, stainless steel User's manual Planmeca Sovereign Classic...
Page 278 10005741 Dürr coarse filter 0725-041-00, 12 pcs NOTE! 2 filters needed Filters retain solid particles with a diameter of ≥ 2 mm Handle of Planmeca Solanna 30005173 Silicone rubber operating light, 1 piece NOTE! 2 handles needed Hygiene membrane 30019621...
Page 279 Water container technical cap 10035657 Silicone rubber assembly Cover cap for bowl filter 10005746 Bowl filter 10005329 Filter retains solid particles with a diameter of >= 1.9 mm Extension for cup fill tube 10033868 Silicone rubber, ASA User's manual Planmeca Sovereign Classic...
Page 280 Order number Material Instrument flushing holder 10034033 Silicone rubber Suction tube cleaning holder 10033859 Silicone rubber Amalgam collector, Dürr 10013485 Dürr OroCup 00004883 Foot cover for Comfy upholstery 02500000 Foot cover for Ultra Relax 10009142 upholstery Planmeca Sovereign Classic User's manual...
Page 281 32 Consumables Disinfectants Part Order number Planmeca PlanClear water and 10034680 waterline disinfectant, 6 x 1 litre Test strips for measuring hydrogen 10035749 peroxide concentration, 100 pieces User's manual Planmeca Sovereign Classic...
Page 282: Disposal
33 Disposal 33 Disposal In order to reduce the environmental load over the product’s entire lifecycle, Planmeca products are designed to be as safe as possible to dispose of. Planmeca products fulfil the requirements of Directives 2011/65/EU (RoHS) and 2012/19/EU (WEEE).
Page 283: Technical Information
34 Technical information 34 Technical information 34.1 Technical specifications Original manufacturer PLANMECA Oy, Asentajankatu 6, 00880 Helsinki, FINLAND Phone: +358 20 7795 500, fax: +358 20 7795 555, www.planmeca.com Colours Painted parts: RAL-9016 Upholstery colours: Please consult your dealer for availability...
Page 284 Water filter: Camozzi 25 µm, material PE Air filter: Camozzi 5 µm, material PE Filter maintenance must be performed according to the manufacturer’s instructions. Suction connection Vacuum: ≥ 150 mbar Flow rate: ≥ 550 l/ min Planmeca Sovereign Classic User's manual...
Page 285 Suction disinfectant concentration Min. 2 minutes; can be is 3.6%. adjusted Planmeca approved disinfectants for the suction system are Dürr Orotol Plus and Orbis Evacuation System Disinfection Concentrate (193087, 193088). For more information on these disinfectants, please refer to the manufacturer’s documentation.
Page 286: Dimensions
34.2.2 Patient area The patient area is 1.5 m (59.1”) in each direction from the dental unit. The external PC, its keyboard and mouse, as well as Planmeca ProSensor’s power supply and the Planmeca ProX generator assembly must be located outside the patient area.
Page 287 34 Technical information CAUTION The floor of the patient area must be dry. NOTE Connect only Planmeca specified devices to the dental unit. NOTE The external PC must be protectively earthed and IEC 60950 -approved (CE marked). NOTE The monitor must fulfil IEC 60601-1 ed.3 requirements.
Page 288 1. Dental unit 9. Planmeca ProSensor PoE port and power cable 2. Planmeca monitor 10. Planmeca ProX generator assembly 3. Planmeca ProX X-ray tube head and arm 11. Foot control battery charger assembly 4. Planmeca operating light 12. External PC 5.
Page 289: Cuspidor Positions
34 Technical information 34.2.3 Cuspidor positions 34.2.4 Space requirements Minimum space requirements 2200 mm x 2000 mm x 2700 mm (H x D x W) User's manual Planmeca Sovereign Classic...
Page 290: Side View
34 Technical information Optimal space requirements 34.2.5 Side view Planmeca Sovereign Classic User's manual...
Page 291: Top View
34 Technical information 34.2.6 Top view User's manual Planmeca Sovereign Classic...
Page 292 34 Technical information Planmeca Sovereign Classic User's manual...
Page 293: Patient Chair
34 Technical information 34.2.7 Patient chair Adaptive legrest Automatic legrest User's manual Planmeca Sovereign Classic...
Page 294: Certifications
Consult the dealer or an experienced radio/television technician for help. Modifications: Any modifications made to this device that are not approved by Planmeca may void the authority granted to the user by the FCC to operate this equipment. 35.4 FCC Class B Notice for PlanID RFID-reader This device complies with Part 15 of the FCC Rules.
Page 295: Industry Canada (Ic) Compliance Statement
Consult the dealer or an experienced radio/television technician for help. Modifications: Any modifications made to this device that are not approved by Planmeca may void the authority granted to the user by the FCC to operate this equipment. 35.5 Industry Canada (IC) Compliance Statement This device complies with Industry Canada licence-exempt RSS standard(s).
