Technical Specifications

For use with Transition Networks Model CPSMC18xx-xxx or equivalent.
Dimensions
Weight
MTBF
(Mean Time Before Failure)
CPSMC1800 + CPSMP-200
CPSMC1800 + CPSMP-200 + CPSMM-200
CPSMC1800 + CPSMP-210
CPSMC1800 + CPSMP-210 + CPSMM-200
CPSMP-200
Power Input:
Power Output:
CPSMP-210
Power Input:
Power Output:
Environment
Tmra*:
Storage Temperature:
Humidity
Altitude
Compliance
Warranty
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR, Subchapter J applicable at the date
of manufacture.
The fiber optic transmitters on this device meets Class I Laser safety requirements per IEC-825/CDRH standards
and complies with 21 CFR1040.10 and 21CFR1040.11.
CAUTION: Visible and Invisible Laser Radiation When Open. Do Not Stare Into Beam Or View Directly
With Optical Instruments.
CAUTION: Use of controls, adjustments or the performance of procedures other than those specified herein
may result in hazardous radiation exposure.
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
17 x 14.3 x 3.5 inches (430 x 363 x 89 mm)
17.5 lbs. (8.0 kg)
MIL217F2 V5.0 (hrs)
82,539
52,564
166,283
77,383
100-240 V, 50/60 Hz, 0.62-1.5 Amp (typical with a fully-loaded chassis)
+12 VDC at 10.83 Amp maximum.
48-VDC (38 to 58 VDC) @ 4.0 Amp (typical with a fully-loaded chassis)
+12 VDC at 12.5 Amp maximum.
0 to 50°C (32 to 122°F) (*Manufacturer's rated ambient temperature)
0 to 60°C (32 to 140°F) (when redundant power or fan module is used)
-40 to 80°C (-40 to 176°F)
5 to 95%, non condensing
0 to 10,000 feet
EN 55022:1998+A1:2000 Class A & B; EN 55024:1998; UL Listed;
FCC Part 15 Subpart B; CE Mark; 21 CFR Subpart J
Lifetime
CPSMC18xx-xxx PointSystem ™ Chassis
Bellcore7 V5.0 (hrs)
223,289
170,073
385,512
250,295
