Transition Networks PointSystem CPSMC0100-226 User Manual

Single-slot chassis
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

Enlarged version
redundant power option provides the means to power the chassis from two independent
power supplies.
Part Number
Description
CPSMC0100-226
Single-Slot Point System chassis with two power supplies (one
grounded and one ungrounded).
The following media converters are not compatible with the CPSMC0100-226
Note:
chassis: C4TEF, CAPTF, CBFTF 120 & 140, CEMTF, CGFEB, and CMEFG.
Optional Accessories (sold separately)
Part Number
Description
SPS-1872-SA
Optional External Power Supply; 18-60VDC Stand-Alone
Output: 12.6VDC, 1.0 A
WMBP
Optional Wall Mount Bracket; 5.0 in.
WMBV
Optional Vertical Mount Bracket; 5.0 in.
WMBD
Optional DIN Rail Mount Bracket; 5.0 in.
User's Guide
CPSMC0100-226
Single-Slot Point System™
Chassis
The Transition Networks
CPSMC0100-226 series single-slot,
redundant power input option
PointSystem™ chassis is designed for
installation of a single, selectable
Transition Networks PointSystem™
media converter slide-in-module. The
(127 mm)
(127 mm)
(127 mm)
Installation . . . . . . . . . . . . . . . . . .2
Technical Specifications . . . . . . . .4
Troubleshooting . . . . . . . . . . . . . .5
Compliance Information . . . . . . . .6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PointSystem CPSMC0100-226 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Transition Networks PointSystem CPSMC0100-226

Summary of Contents for Transition Networks PointSystem CPSMC0100-226

  • Page 1 CPSMC0100-226 Single-Slot Point System chassis with two power supplies (one grounded and one ungrounded). The following media converters are not compatible with the CPSMC0100-226 Note: chassis: C4TEF, CAPTF, CBFTF 120 & 140, CEMTF, CGFEB, and CMEFG. Optional Accessories (sold separately)

  • Page 2: Installation

    Failure to observe this caution could result in damage or failure of the media converter slide-in-module. The maximum power delivery capacity for the CPSMC0100-226 is 6 watts. To install a slide-in-module into the single-slot chassis: 1. Refer to the user’s guide that comes with the slide-in-module to ensure that any switches or jumpers on the module’s circuit board are set correctly for the site...

  • Page 3: Technical Specifications

    -- Click the “Transition Now” link for a live Web chat. For use with Transition Networks Model CPSMC0100-226 or equivalent. Note: The CPSMC0100-226 single-slot chassis is Class B compliant ONLY if Class B compliant media converters are installed. Installation of a Class A compliant media converter reduces the chassis to Class A compliance.

  • Page 4: Troubleshooting

    CPSMC0100-226 Regulation: EMC Directive 89/336/EEC Purpose: To declare that the CPSMC0100-226 to which this declaration refers is in conformity with the following standards. EN 55022:1998 Class A&B; EN 55024:1988; FCC Part 15 Subpart B; EN 61000-3-2:1995; EN 61000-3-3:1995 I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s) and Standard(s).

  • Page 5: Compliance Information

    Compliance Information CISPR/EN55022 Class A & B + EN55024 CE Mark FCC Regulations This equipment has been tested and found to comply with the limits for a Class A & B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
