Cascading multiple CPSMC18xx-xxx chassis
To cascade two or more CPSMC18xx-xxx chassis:
1. Locate one (1) Transition Networks management module cascade cable (with
2. At the first chassis in the series: Plug the RJ-45 connector at one end of the
3. At the next chassis in the series: Plug the RJ-45 connector at the other end of the
4. At the same chassis as in step 3: Plug the RJ-45 connector at one end of the
5. At the next chassis in the series: Plug the RJ-45 connector at the other end of the
6. Repeat steps 4 and 5 until all chassis have been connected.
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
RJ-45 connectors installed at both ends) (P/N 6026) for each set of two (2)
chassis to be cascaded.
NOTE: Transition Networks management module cascade cables are one (1)
meter long. Ensure that the chassis are installed within one (1) meter of each
other.
cascade cable into the management module's RJ-45 port labeled "OUT".
cascade cable into the management module's RJ-45 port labeled "IN".
cascade cable into the management module's RJ-45 port labeled "OUT".
cascade cable into the management module's RJ-45 port labeled "IN".
